STR-DA5400ES
152
Pin No. Pin Name I/O Description
Y4 ADATA23 I Digital video signal input terminal Not used
Y23 IO_3.3V - Power supply terminal (+3.3V)
Y24 OCM_INT2 - Not used
Y25 VGA1_SDA - Not used
Y26 VGA1_SCL - Not used
AA1 NC - Not used
AA2 to
AA4
DGND_ADC - Ground terminal
AA23 MSTR0_SDA I/O Two-way data bus with the EEPROM
AA24 MSTR0_SCL O Serial clock signal output to the EEPROM
AA25 VGA0_SDA - Not used
AA26 VGA0_SCL - Not used
AB1 A1P I Video signal (PR/CR) input from the COMPONENT VIDEO IN jack
AB2 SV1P - Not used
AB3 AGND_ADC - Ground terminal
AB4 ADC_1.8V - Power supply terminal (+1.8V)
AB23 IO_3.3V - Power supply terminal (+3.3V)
AB24 IRO - Not used
AB25 MSTR2_SDA - Not used
AB26 MSTR2_SCL - Not used
AC1 C1P I Video signal (Y) input from the COMPONENT VIDEO IN jack
AC2 B1P I Video signal (PB/CB) input from COMPONENT VIDEO IN jack
AC3 AGND_ADC - Ground terminal
AC4, AC5 ADC_1.8V - Power supply terminal (+1.8V)
AC6 AGND_ADC - Ground terminal
AC7 VOUT2 - Not used
AC8 AGND_ADC - Ground terminal
AC9 LBADC_3.3V - Power supply terminal (+3.3V)
AC10 LBADC_IN4 - Not used
AC11 LBADC_GND - Ground terminal
AC12 AVSIN_DATA - Not used
AC13 EXTOSD_HS - Not used
AC14 IO_3.3V - Power supply terminal (+3.3V)
AC15 OCMADDR18 O Address signal output to the fl ash memory
AC16 IO_3.3V - Power supply terminal (+3.3V)
AC17 OCMADDR11 O Address signal output to the fl ash memory
AC18 IO_3.3V - Power supply terminal (+3.3V)
AC19 OCMADDR4 O Address signal output to the fl ash memory
AC20 IO_3.3V - Power supply terminal (+3.3V)
AC21 OCMDATA13 I/O Two-way data bus with the fl ash memory
AC22 IO_3.3V - Power supply terminal (+3.3V)
AC23 OCMDATA6 I/O Two-way data bus with the fl ash memory
AC24 OCM_CS2N O Chip select signal output terminal Not used
AC25 OCN_RE_N O Read enable signal output to the fl ash memory
AC26 OCN_WE_N O Write enable signal output to the fl ash memory
AD1 AN - Not used
AD2 AGND_ADC - Ground terminal
AD3 to
AD5
ADC1_3.3V - Power supply terminal (+3.3V)
AD6, AD7 ADC2_3.3V - Power supply terminal (+3.3V)
AD8 AGND_ADC - Ground terminal
AD9 RESET I Reset signal input from the video system controller "L": reset
AD10 LBADC_IN3 - Not used
AD11 LBADC_RETURN - Not used
AD12 AVSIN_WORDSEL - Not used
AD13 EXTOSD_VS - Not used
