STR-DA5400ES
151
Pin No. Pin Name I/O Description
M10 to
M17
D_GND - Ground terminal
M23 IO_3.3V - Power supply terminal (+3.3V)
M24, M25 LVDS_GND - Ground terminal
M26 LVDS_3.3V - Power supply terminal (+3.3V)
N1 IPCLK0 I Clock signal input terminal Not used
N2 DIP_RAW_HS_CS - Not used
N3 DIP_AODD - Not used
N4 DIP_BODD - Not used
N10 to
N17
D_GND - Ground terminal
N23 to
N26
PD0 to PD3 O Digital video signal output terminal Not used
P1 to P3 ADATA2 to ADATA0 I Digital video signal input terminal Not used
P4 IPCLK1 I Clock signal input terminal Not used
P10 to P17 D_GND - Ground terminal
P23 IO_3.3V - Power supply terminal (+3.3V)
P24 DCLK O Output data clock signal output to the D/A converter (for video section)
P25 DHS O Horizontal sync signal output to the D/A converter (for video section)
P26 DEN O Data enable signal output to the D/A converter (for video section)
R1 to R4 ADATA6 to ADATA3 I Digital video signal input terminal Not used
R10 to
R17
D_GND - Ground terminal
R23 JTAG_BS_TDI - Not used
R24 JTAG_BS_RST - Not used
R25 JTAG_BS_TCK - Not used
R26 DVS O Vertical sync signal output to the D/A converter (for video section)
T1 to T4 ADATA10 to ADATA7 I Digital video signal input terminal Not used
T10 D_GND - Ground terminal
T11 CORE_1.8V - Power supply terminal (+1.8V)
T12 to T15 D_GND - Ground terminal
T16, T17 CORE_1.8V - Power supply terminal (+1.8V)
T23 IO_3.3V - Power supply terminal (+3.3V)
T24 JTAG_BS_TMS - Not used
T25 JTAG_BS_TDO - Not used
T26 GPIO_44 - Not used
U1 to U4 ADATA14 to ADATA11 I Digital video signal input terminal Not used
U10, U11 CORE_1.8V - Power supply terminal (+1.8V)
U12 to
U15
D_GND - Ground terminal
U16, U17 CORE_1.8V - Power supply terminal (+1.8V)
U23, U24 PWM1, PWM2 - Not used
U25 PPWR - Not used
U26 PBIAS - Not used
V1 to V4 ADATA18 to ADATA15 I Digital video signal input terminal Not used
V23 IO_3.3V - Power supply terminal (+3.3V)
V24 PWM0 - Not used
V25 SLAVE_SDA - Not used
V26 SLAVE_SCL - Not used
W1 to W4 ADATA22 to ADATA19 I Digital video signal input terminal Not used
W23 OCM_INT1 - Not used
W24 OCM_TIMER1 - Not used
W25 OCM_UDI_0 - Not used
W26 ODM_UDO_0 - Not used
Y1 AVS I Vertical sync signal input terminal Not used
Y2 AHS I Horizontal sync signal input terminal Not used
Y3 AHREF_DE I Data enable signal input terminal Not used
