STR-DA5400ES
150
Pin No. Pin Name I/O Description
D9 FSVREFVSS - Ground terminal
D10 to
D15
DDR_2.5V - Power supply terminal (+2.5V)
D16 FSADDR10 O Address signal output to the SD-RAM
D17, D18 DDR_2.5V - Power supply terminal (+2.5V)
D19 FSVREFVSS - Ground terminal
D20 DDR_2.5V - Power supply terminal (+2.5V)
D21 FSCS0 O Chip select signal output to the SD-RAM
D22, D23 DDR_2.5V - Power supply terminal (+2.5V)
D24 FSCAS O Column address strobe signal output to the SD-RAM
D25 NC - Not used
D26 RPLL_3.3V - Power supply terminal (+3.3V)
E1 to E3 BDATA9 to BDATA7 I Digital video signal input terminal Not used
E4 IO_3.3V - Power supply terminal (+3.3V)
E23, E24 PD22, PD23 O Digital video signal output terminal Not used
E25 LVDS_GND - Ground terminal
E26 LVDS_3.3V - Power supply terminal (+3.3V)
F1 to F3
BDATA12 to
BDATA10
I Digital video signal input terminal Not used
F4 IO_3.3V - Power supply terminal (+3.3V)
F23 to F26 PD18 to PD21 O Digital video signal output to the D/A converter (for video section)
G1 to G3 BDATA15 to BDATA13 I Digital video signal input terminal Not used
G4 IO_3.3V - Power supply terminal (+3.3V)
G23 to
G26
PD14 to PD17 O Digital video signal output to the D/A converter (for video section)
H1 to H3 BDATA18 to BDATA16 I Digital video signal input terminal Not used
H4 IO_3.3V - Power supply terminal (+3.3V)
H23 LVDS_PLL_GND - Ground terminal
H24 LVDS_PLL_3.3V - Power supply terminal (+3.3V)
H25 LVDS_GND - Ground terminal
H26 LVDS_3.3V - Power supply terminal (+3.3V)
J1 to J3 BDATA21 to BDATA19 I Digital video signal input terminal Not used
J4 IO_3.3V - Power supply terminal (+3.3V)
J23, J24 PD12, PD13 O Digital video signal output to D/A converter (for video section)
J25 LVDS_GND - Ground terminal
J26 LVDS_3.3V - Power supply terminal (+3.3V)
K1 BHREF_DE I Blanking period signal input terminal Not used
K2, K3 BDATA23, BDATA22 I Digital video signal input terminal Not used
K4 IO_3.3V - Power supply terminal (+3.3V)
K10, K11 CORE_1.8V - Power supply terminal (+1.8V)
K12 to K15 D_GND - Ground terminal
K16, K17 CORE_1.8V - Power supply terminal (+1.8V)
K23 to K26 PD8 to PD11 O Digital video signal output to the D/A converter (for video section)
L1 IPCLK3 I Clock signal input terminal Not used
L2 BVS I Vertical sync signal input terminal Not used
L3 BHS I Horizontal sync signal input terminal Not used
L4 IO_3.3V - Power supply terminal (+3.3V)
L10 D_GND - Ground terminal
L11 CORE_1.8V - Power supply terminal (+1.8V)
L12 to L15 D_GND - Ground terminal
L16 CORE_1.8V - Power supply terminal (+1.8V)
L17 D_GND - Ground terminal
L23 to L26 PD4 to PD7 O Digital video signal output terminal Not used
M1 DIP_CLEAN_HS_OUT O Horizontal sync signal output terminal Not used
M2 DIP_EXT_CLAMP - Not used
M3 DIP_EXT_COAST - Not used
M4 IPCLK2 I Clock signal input terminal Not used
