STR-DA5400ES
158
Pin No. Pin Name I/O Description
56 DIRERROR I PLL lock error signal and data error fl ag input from the digital audio interface receiver
57 +3.3V - Power supply terminal (+3.3V)
58 GND - Ground terminal
59 DIR CKST I Clock selection signal input from the digital audio interface receiver
60 MCK_X1/X2_SEL O Master clock signal selection signal output terminal
61 232C-SEL1 O Data selection signal output terminal
62 DEV I2C2 SDA I/O
Two-way I2C data bus with the fi eld programmable gate array, D/A converter (for audio sec-
tion) and video input selector
63 DEV I2C2 SCL O
I2C clock signal output to the fi eld programmable gate array, D/A converter (for audio sec-
tion) and video input selector
64 D595 OE O Output enable signal output to the data decoder (for audio)
65 D595 LAT O Serial data latch pulse signal output to the data decoder (for audio)
66 COM1 CLK O
Serial data transfer clock signal output to the digital audio interface receiver, data decoder
(for audio section) and lip sync adjust
67 COM1 DATA O
Serial data output to the digital audio interface receiver, data decoder (for audio section) and
lip sync adjust
68 to 70 TRG-1 to TRG-3 O Trigger signal output terminal
71 CEC-M/DV O CEC serial data output to the HDMI connector
72 HDMI-ERROR I HDMI audio error signal input terminal
73 +3.3V - Power supply terminal (+3.3V)
74 GND - Ground terminal
75 4/8-RY O Speaker impedance 4/8 ohm selection signal output terminal "L": 4 ohm, "H": 8 ohm
76 D.MIX-LAT O Serial data latch pulse signal output to the audio switch
77 VOL LAT O Serial data latch pulse signal output to the electrical volume
78 CCD_RY O Relay drive signal (for CD direct) output terminal "H": relay on
79 PREOUT RY O Relay drive signal (for preout) output terminal "H": relay on
80 SP-A-RY O Relay drive signal (for front A) output terminal "H": relay on
81 SP-B-RY O Relay drive signal (for front B) output terminal "H": relay on
82 C-RY O Relay drive signal (for center) output terminal "H": relay on
83 SB-RY O Relay drive signal (for surround back) output terminal "H": relay on
84 SR-RY O Relay drive signal (for surround) output terminal "H": relay on
85 HP-RY O Relay drive signal (for headphone) output terminal "H": relay on
86 PROTECTOR I Protect detection signal input terminal
87 D_POWER O Power supply on/off control signal output terminal for DSP section "H": power on
88 GND - Ground terminal
89 +3.3V - Power supply terminal (+3.3V)
90 POW-RY O Relay drive signal (for main power) output terminal "H": relay on
91 STOP I AC off detection signal input terminal "L": AC off
92 3RD RELAY O Relay drive signal (for zone 3) output terminal "H": relay on
93 2ND RELAY O Relay drive signal (for zone 2) output terminal "H": relay on
94 FUNC LAT O Serial data latch pulse signal output to the audio input selector
95 COM2 CLK O
Serial data transfer clock signal output to the audio input selector and D/A converter (for XM
section)
96 COM2 DATA O Serial data output to the audio input selector and D/A converter (for XM section)
97 WDRESETX O Watch dog timer reset signal output terminal Not used
98 to 100 AD-KEY1 to AD-KEY3 I Front panel key input terminal (A/D input)
101 AD-KEY4 (NO USE) I Key input terminal (A/D input) Not used
102 FUNC2_LAT O Serial data latch pulse signal output to the audio input selector
103 VERSION I Destination setting terminal
104 FUNC3_LAT O Serial data latch pulse signal output to the audio input selector
105
SIRIUS POWER
ENABLE
O Sirius power detection signal output to the SIRIUS socket (US and Canadian models only)
106 TUNED I Tuned detection signal input from the tuner (FM/AM)
107 TUN_LAT O Serial data latch pulse signal output to the tuner (FM/AM)
108 TUN_DATA O Serial data output to the tuner (FM/AM)
109 TUN_CLK O Serial data transfer clock signal output to the tuner (FM/AM)
110 TUN_DO I Serial data input from the tuner (FM/AM)
