STR-DA5400ES
159
Pin No. Pin Name I/O Description
111 RDS_DATA I
RDS serial data input from the tuner (FM/AM)
(AEP, Continental European, East European, Russian and UK models only)
112
IR-LEARNING UCOM
RESET
O Not used
113 IR OUT SWITCH O Not used
114 AD GND - Ground terminal (for A/D converter)
115 AD +3.3V - Power supply terminal (+3.3V) (for A/D converter)
116 AD Ref. Vdd I Reference voltage (+3.3V) input terminal (for A/D converter)
117
PNX SDA (IIC BUS
MONITOR DATA)
I/O Two-way I2C data bus terminal Not used
118
PNX SCL (IIC BUS
MONITOR CLK)
I/O Two-way I2C clock bus terminal Not used
119 SIRCS-IN I SIRCS signal input from the remote control receiver
120 DAC_ZERO_DATA I Zero data detection signal input from the D/A converter (for audio section)
121 CEC-DV/M I CEC serial data input from the HDMI connector
122 COMP_DET I Component video signal detection signal input terminal
123 ZONE_SEL I ZONE SELECT switch input terminal
124 9850 INIT O Reset signal output terminal Not used
125 NO USE - Not used
126 RST_TRG O Reset signal output terminal for system controller "L": reset
127 MD3 - Mode setting terminal Fixed at "L" in this set
128 MD2 I Serial data input terminal
129, 130 MD1, MD0 - Mode setting terminal Fixed at "L" in this set
131 INITX I
System reset signal input from the reset signal generator "L": reset
For several hundreds msec. after the power supply rises, "L" is input, then it changes to "H"
132 GND - Ground terminal
133 +5V - Power supply terminal (+3.3V)
134 232C-MIN I Serial data input from the RS-232C connector
135 232C-MOUT O Serial data input from the RS-232C connector
136 COMP2_DET I Component video signal (for ZONE 2) detection signal input terminal
137 XMUART-XM/M I Serial data input from the XM receiver (US and Canadian models only)
138 XMUART-M/XM O Serial data output to the XM receiver (US and Canadian models only)
139 MONI_MUTE O
Composite video monitor out muting on/off control signal output to the video amplifi er
(for composite video signal) "H": muting on
140 IR-LEARN-UART-IR/M I Not used
141 IR-LEARN-UART-M/IR O Not used
142 MONI2_MUTE O
Composite video zone 2 out muting on/off control signal output to the video amplifi er
(for composite video signal (for ZONE 2)) "H": muting on
143 DMUART2-DM/M I Serial data input from the DMPORT 2 connector
144 DMUART2-M/DM O Serial data output to the DMPORT 2 connector
145 DMPORT2_DETECT I
Digital media port adapter connection detection signal (for DMPORT 2 connector) input
terminal "L": digital media port adapter is connected
146 GND - Ground terminal
147 +5V - Power supply terminal (+3.3V)
148 SIRIUS_UART_SI/M I Serial data input from the SIRIUS socket (US and Canadian models only)
149 SIRIUS_UART_M/SI O Serial data output to the SIRIUS socket (US and Canadian models only)
150 FL_CLR O Blanking period signal output to the fl uorescent indicator tube
151 FL_LAT O Serial data latch pulse signal output to the fl uorescent indicator tube
152 FL_DATA O Serial data output to the fl uorescent indicator tube
153 FL_CLK O Serial data transfer clock signal output to the fl uorescent indicator tube
154 DMPORT_DM/M I Serial data input from the DMPORT 1 connector
155 DMPORT_M/DM O Serial data output to the DMPORT 1 connector
156 DMPORT DETECT I
Digital media port adapter connection detection signal (for DMPORT 1 connector) input
terminal "L": digital media port adapter is connected
157 COMP_MON_MUTE O
Component video monitor out muting on/off control signal output to the video amplifi er
(for component video signal) "H": muting on
158 COMP_MON2_MUTE O
Component video zone 2 out muting on/off control signal output to the video amplifi er
(for component video signal (for ZONE 2)) "H": muting on
