Sony STR-DB2000 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
128
STR-DA2000ES/DB2000
DISPLAY FUNCTION HP-V3 MULTI-VIDEO
< VARIABLE RESISTOR >
RV1051 1-467-808-21 ENCODER, ROTARY (MENU)
RV1052 1-467-808-21 ENCODER, ROTARY (–/+)
< SWITCH >
S1041 1-762-875-21 SWITCH, KEYBOARD (INPUT MODE)
S1042 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S1043 1-762-875-21 SWITCH, KEYBOARD (MUSIC)
S1044 1-762-875-21 SWITCH, KEYBOARD (MOVIE)
S1045 1-762-875-21 SWITCH, KEYBOARD (A.F.D)
S1046 1-762-875-21 SWITCH, KEYBOARD (2CH)
S1047 1-762-875-21 SWITCH, KEYBOARD
(SURR BACK DECODING)
S1050 1-762-875-21 SWITCH, KEYBOARD (I/1)
S1051 1-762-875-21 SWITCH, KEYBOARD (TUNING +)
S1052 1-762-875-21 SWITCH, KEYBOARD (TUNING –)
S1053 1-762-875-21 SWITCH, KEYBOARD (PRESET TUNING +)
S1054 1-762-875-21 SWITCH, KEYBOARD (PRESET TUNING –)
S1056 1-762-875-21 SWITCH, KEYBOARD (MEMORY ENTER)
S1057 1-762-875-21 SWITCH, KEYBOARD (MAIN MENU)
S1065 1-762-875-21 SWITCH, KEYBOARD (SPEAKERS
(OFF/A/B/A+B))
< TRANSFORMER >
T1071 1-439-814-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
1-688-600-11 FUNCTION BOARD
***************
< VARIABLE RESISTOR >
RV1061 1-467-808-21 ENCODER, ROTARY (INPUT SELECTOR)
************************************************************
A-4733-939-A HP-V3 BOARD, COMPLETE (STR-DA2000ES)
A-4734-033-A HP-V3 BOARD, COMPLETE (STR-DB2000)
**********************
< CAPACITOR/SHORT >
C1081 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1086 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C1087 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C1088 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1089 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1091 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C1092 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C1096 1-216-295-00 SHORT CHIP 0
< CONNECTOR >
CN1081 1-784-922-11 PIN, CONNECTOR 5P
CN1091 1-784-926-11 PIN, CONNECTOR 11P
< EARTH TERMINAL >
* EP1086 1-537-738-21 TERMINAL, EARTH
* EP1091 1-537-738-21 TERMINAL, EARTH
< IC >
IC1081 6-600-219-01 IC GP1FM313RZ0F
(VIDEO 3 INPUT DIGITAL OPTICAL)
< JACK >
J1086 1-815-313-11 JACK (PHONES)
J1091 1-770-571-11 JACK BLOCK, PIN (L TYPE) 3P
(VIDEO 3 INPUT S-VIDEO)
J1092 1-784-808-11 TERMINAL, S (VIDEO 3 INPUT VIDEO,
VIDEO 3 INPUT AUDIO)
< SHORT >
JR1088 1-216-295-00 SHORT CHIP 0 (STR-DA2000ES)
JR1089 1-216-295-00 SHORT CHIP 0 (STR-DB2000)
< RESISTOR >
R1081 1-216-025-11 RES-CHIP 100 5% 1/10W
R1092 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1093 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1095 1-216-022-00 RES-CHIP 75 5% 1/10W
R1096 1-216-022-00 RES-CHIP 75 5% 1/10W
R1099 1-216-295-00 SHORT CHIP 0
************************************************************
A-4733-932-A MULTI-VIDEO BOARD, COMPLETE
(STR-DA2000ES)
A-4734-048-A MULTI-VIDEO BOARD, COMPLETE
(STR-DB2000: SP, MY)
A-4734-061-A MULTI-VIDEO BOARD, COMPLETE
(STR-DB2000: AEP, UK)
****************************
< CAPACITOR/SHORT >
C111 1-137-431-11 MYLAR 560PF 5% 50V
C112 1-126-965-91 ELECT 22uF 20% 50V
(STR-DA2000ES)
C112 1-128-858-11 ELECT 22uF 20% 50V
(STR-DB2000: SP, MY)
C112 1-135-744-91 ELECT 22uF 50V
(STR-DB2000: AEP, UK)
C113 1-126-965-91 ELECT 22uF 20% 50V
(STR-DA2000ES)
C113 1-128-858-11 ELECT 22uF 20% 50V
(STR-DB2000: SP, MY)
C113 1-135-744-91 ELECT 22uF 50V
(STR-DB2000: AEP, UK)
C116 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C117 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C121 1-126-965-91 ELECT 22uF 20% 50V
(STR-DA2000ES)
C121 1-128-858-11 ELECT 22uF 20% 50V
(STR-DB2000: SP, MY)
C121 1-135-744-91 ELECT 22uF 50V
(STR-DB2000: AEP, UK)
C122 1-126-965-91 ELECT 22uF 20% 50V
(STR-DA2000ES)
C122 1-128-858-11 ELECT 22uF 20% 50V
(STR-DB2000: SP, MY)
C122 1-135-744-91 ELECT 22uF 50V
(STR-DB2000: AEP, UK)
