STR-DA2000ES/DB2000
SECTION 8
ELECTRICAL PARTS LIST
2CH. AU
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
•Abbreviation
CND : Canadian model
MY : Malaysia model
SP : Singapore model
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
A-4733-930-A 2CH. AU BOARD, COMPLETE (STR-DA2000ES)
A-4734-029-A 2CH. AU BOARD, COMPLETE
(STR-DB2000: SP, MY)
A-4734-059-A 2CH. AU BOARD, COMPLETE
(STR-DB2000: AEP, UK)
***********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C411 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C413 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C415 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C416 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C417 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C419 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C421 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C422 1-126-965-91 ELECT 22uF 20% 50V
C423 1-126-965-91 ELECT 22uF 20% 50V
C424 1-126-965-91 ELECT 22uF 20% 50V
C425 1-126-965-91 ELECT 22uF 20% 50V
C431 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C432 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
(STR-DB2000)
C433 1-126-961-11 ELECT 2.2uF 20% 50V
C434 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C435 1-126-934-11 ELECT 220uF 20% 16V
C436 1-125-896-91 MYLAR 0.0091uF 5% 50V
C437 1-136-159-00 MYLAR 0.033uF 5% 50V
C438 1-126-961-11 ELECT 2.2uF 20% 50V
C441 1-126-965-91 ELECT 22uF 20% 50V
(STR-DA2000ES)
C442 1-126-965-91 ELECT 22uF 20% 50V
(STR-DA2000ES)
C453 1-126-965-91 ELECT 22uF 20% 50V
(STR-DA2000ES)
C454 1-126-934-11 ELECT 220uF 20% 16V
(STR-DA2000ES)
C455 1-137-505-11 MYLAR 220PF 5% 50V
(STR-DA2000ES)
C456 1-126-965-91 ELECT 22uF 20% 50V
(STR-DA2000ES)
C457 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DA2000ES)
C472 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C473 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C474 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C475 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C476 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C477 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C478 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C479 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C485 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C486 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C487 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C488 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C511 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C513 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C515 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C516 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C517 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C519 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C521 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C522 1-126-965-91 ELECT 22uF 20% 50V
C523 1-126-965-91 ELECT 22uF 20% 50V
C524 1-126-965-91 ELECT 22uF 20% 50V
C525 1-126-965-91 ELECT 22uF 20% 50V
C531 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
