Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
102
STR-DA2000ES/DB2000
2CH. AU
C532 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
(STR-DB2000)
C533 1-126-961-11 ELECT 2.2uF 20% 50V
C534 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C535 1-126-934-11 ELECT 220uF 20% 16V
C536 1-125-896-91 MYLAR 0.0091uF 5% 50V
C537 1-136-159-00 MYLAR 0.033uF 5% 50V
C538 1-126-961-11 ELECT 2.2uF 20% 50V
C541 1-126-965-91 ELECT 22uF 20% 50V
(STR-DA2000ES)
C542 1-126-965-91 ELECT 22uF 20% 50V
(STR-DA2000ES)
C553 1-126-965-91 ELECT 22uF 20% 50V
(STR-DA2000ES)
C554 1-126-934-11 ELECT 220uF 20% 16V
(STR-DA2000ES)
C555 1-137-505-11 MYLAR 220PF 5% 50V
(STR-DA2000ES)
C556 1-126-965-91 ELECT 22uF 20% 50V
(STR-DA2000ES)
C557 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DA2000ES)
C572 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C573 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C574 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C575 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C576 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C577 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C578 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C579 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DB2000)
C585 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C586 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C587 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C588 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C611 1-216-295-00 SHORT CHIP 0
C612 1-216-295-00 SHORT CHIP 0
C613 1-216-295-00 SHORT CHIP 0
C614 1-216-295-00 SHORT CHIP 0
C615 1-216-295-00 SHORT CHIP 0 (STR-DA2000ES)
C631 1-163-033-00 CERAMIC CHIP 0.022uF 50V
C632 1-163-033-00 CERAMIC CHIP 0.022uF 50V
C652 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
(STR-DA2000ES)
C653 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
(STR-DA2000ES)
C654 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(STR-DA2000ES)
C659 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
(STR-DA2000ES)
C661 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C662 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C663 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C664 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C665 1-126-933-11 ELECT 100uF 20% 16V
(STR-DA2000ES)
C665 1-127-718-11 ELECT 100uF 20% 16V
(STR-DB2000: SP, MY)
C665 1-135-709-11 ELECT 100uF 16V
(STR-DB2000: AEP, UK)
C666 1-126-933-11 ELECT 100uF 20% 16V
(STR-DA2000ES)
C666 1-127-718-11 ELECT 100uF 20% 16V
(STR-DB2000: SP, MY)
C666 1-135-709-11 ELECT 100uF 20% 16V
(STR-DB2000: AEP, UK)
C671 1-126-943-11 ELECT 2200uF 20% 25V
(EXCEPT STR-DB2000: AEP, UK)
C671 1-135-686-51 ELECT 2200uF 25V
(STR-DB2000: AEP, UK)
C672 1-126-943-11 ELECT 2200uF 20% 25V
(EXCEPT STR-DB2000: AEP, UK)
C672 1-135-686-51 ELECT 2200uF 25V
(STR-DB2000: AEP, UK)
C673 1-100-023-31 ELECT 39uF 20% 16V
C674 1-100-023-31 ELECT 39uF 20% 16V
C685 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
(STR-DA2000ES)
C686 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
(STR-DA2000ES)
C687 1-163-038-00 CERAMIC CHIP 0.1uF 25V
(STR-DA2000ES)
C688 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(STR-DA2000ES)
C691 1-126-968-11 ELECT 100uF 20% 50V
(EXCEPT STR-DB2000: AEP, UK)
C691 1-135-756-91 ELECT 100uF 50V
(STR-DB2000: AEP, UK)
C692 1-126-943-11 ELECT 2200uF 20% 25V
(EXCEPT STR-DB2000: AEP, UK)
C692 1-135-686-51 ELECT 2200uF 25V
(STR-DB2000: AEP, UK)
C693 1-126-943-11 ELECT 2200uF 20% 25V
(EXCEPT STR-DB2000: AEP, UK)
C693 1-135-686-51 ELECT 2200uF 25V
(STR-DB2000: AEP, UK)
C694 1-136-169-00 MYLAR 0.22uF 5% 50V
C695 1-136-169-00 MYLAR 0.22uF 5% 50V
C696 1-126-941-11 ELECT 470uF 20% 25V
(EXCEPT STR-DB2000: AEP, UK)
C696 1-135-684-91 ELECT 470uF 25V
(STR-DB2000: AEP, UK)
C697 1-136-169-00 MYLAR 0.22uF 5% 50V
< CONNECTOR >
CNP607 1-784-925-11 PIN, CONNECTOR 10P
CNP609 1-779-978-21 PIN, CONNECTOR 3P (STR-DB2000)
CNP609 1-784-923-11 PIN, CONNECTOR 7P (STR-DA2000ES)
CNP610 1-779-978-11 PIN, CONNECTOR 3P
< DIODE >
D641 8-719-988-61 DIODE 1SS355TE-17 (STR-DA2000ES)
D651 8-719-988-61 DIODE 1SS355TE-17 (STR-DA2000ES)
