Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
103
STR-DA2000ES/DB2000
2CH. AU
< EARTH TERMINAL >
* EPT601 1-537-738-21 TERMINAL, EARTH
< IC >
IC151 8-759-582-64 IC TC9273N-004
IC171 8-759-582-66 IC TC9273N-013 (STR-DA2000ES)
IC201 8-759-582-65 IC TC9273N-014
IC301 8-759-636-55 IC M5218AFP
IC604 8-759-636-55 IC M5218AFP
IC611 8-759-636-55 IC M5218AFP
IC612 8-759-636-55 IC M5218AFP
IC613 8-759-636-55 IC M5218AFP
IC614 8-759-636-55 IC M5218AFP
IC615 8-759-636-55 IC M5218AFP
IC616 8-759-636-55 IC M5218AFP
IC617 8-759-636-55 IC M5218AFP
IC618 8-759-636-55 IC M5218AFP
IC619 8-759-636-55 IC M5218AFP
IC620 8-759-636-55 IC M5218AFP
IC621 8-759-636-55 IC M5218AFP
IC622 8-759-636-55 IC M5218AFP
IC641 8-759-636-55 IC M5218AFP (STR-DA2000ES)
IC652 6-702-387-01 IC CXD9725M (STR-DA2000ES)
IC653 8-759-636-55 IC M5218AFP (STR-DA2000ES)
IC661 8-759-473-41 IC BA10T
IC662 8-759-604-50 IC M5F7910L
IC691 8-759-231-53 IC TA7805S
< JACK >
J605 1-774-411-11 JACK, PIN 6P (PHONO AUDIO IN, CD/SACD
AUDIO IN, MD/DAT AUDIO OUT)
J606 1-774-411-11 JACK, PIN 6P (MD/DAT AUDIO IN, TAPE
AUDIO OUT, TAPE AUDIO IN)
J607 1-774-411-11 JACK, PIN 6P (TV/SAT AUDIO IN, DVD AUDIO
IN, VIDEO2 AUDIO OUT)
J608 1-774-411-11 JACK, PIN 6P (VIDEO2 AUDIO IN, VIDEO1
AUDIO OUT, VIDEO1 AUDIO IN)
J609 1-695-188-31 JACK, PIN 4P (2ND ZONE OUT, PRE OUT
FRONT) (STR-DA2000ES)
< JUMPER RESISTOR >
JW621 1-216-295-00 SHORT CHIP 0
JW622 1-216-295-00 SHORT CHIP 0
JW624 1-216-295-00 SHORT CHIP 0
JW651 1-216-295-00 SHORT CHIP 0
< COIL >
L671 1-409-575-11 INDUCTOR 1mH
L672 1-456-520-11 INDUCTOR 1mH
< TRANSISTOR >
Q631 8-729-230-49 TRANSISTOR 2SC2712-YG
(STR-DA2000ES)
Q632 8-729-027-24 TRANSISTOR DTA114TKA-T146
(STR-DA2000ES)
Q641 8-729-230-49 TRANSISTOR 2SC2712-YG
(STR-DA2000ES)
Q651 8-729-230-49 TRANSISTOR 2SC2712-YG
(STR-DA2000ES)
Q662 8-729-027-24 TRANSISTOR DTA114TKA-T146
(STR-DA2000ES)
< RESISTOR >
R410 1-216-049-11 RES-CHIP 1K 5% 1/10W
R411 1-216-198-00 RES-CHIP 1K 5% 1/8W
(EXCEPT STR-DB2000: AEP, UK)
R411 1-259-995-11 CARBON MELF 1K 2% 1/8W
(STR-DB2000: AEP, UK)
R412 1-216-049-11 RES-CHIP 1K 5% 1/10W
R413 1-216-049-11 RES-CHIP 1K 5% 1/10W
R414 1-216-049-11 RES-CHIP 1K 5% 1/10W
R415 1-216-049-11 RES-CHIP 1K 5% 1/10W
R416 1-216-049-11 RES-CHIP 1K 5% 1/10W
R417 1-216-049-11 RES-CHIP 1K 5% 1/10W
R418 1-216-049-11 RES-CHIP 1K 5% 1/10W
R419 1-216-049-11 RES-CHIP 1K 5% 1/10W
R420 1-216-049-11 RES-CHIP 1K 5% 1/10W
R421 1-216-049-11 RES-CHIP 1K 5% 1/10W
R422 1-216-238-91 RES-CHIP 47K 5% 1/8W
(EXCEPT STR-DB2000: AEP, UK)
R422 1-260-016-11 CARBON MELF 47K 2% 1/8W
(STR-DB2000: AEP, UK)
R423 1-216-089-11 RES-CHIP 47K 5% 1/10W
R424 1-216-089-11 RES-CHIP 47K 5% 1/10W
R425 1-216-089-11 RES-CHIP 47K 5% 1/10W
R426 1-216-089-11 RES-CHIP 47K 5% 1/10W
R427 1-216-089-11 RES-CHIP 47K 5% 1/10W
R428 1-216-089-11 RES-CHIP 47K 5% 1/10W
R429 1-216-089-11 RES-CHIP 47K 5% 1/10W
R431 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
(STR-DB2000)
R431 1-216-295-00 SHORT CHIP 0 (STR-DA2000ES)
R432 1-216-097-11 RES-CHIP 100K 5% 1/10W
R433 1-216-097-11 RES-CHIP 100K 5% 1/10W
R434 1-216-031-00 RES-CHIP 180 5% 1/10W
R435 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R436 1-216-097-11 RES-CHIP 100K 5% 1/10W
R437 1-216-025-11 RES-CHIP 100 5% 1/10W
R438 1-216-097-11 RES-CHIP 100K 5% 1/10W
R439 1-216-041-00 RES-CHIP 470 5% 1/10W
R441 1-216-089-11 RES-CHIP 47K 5% 1/10W
(STR-DA2000ES)
R444 1-216-093-11 RES-CHIP 68K 5% 1/10W
(STR-DA2000ES)
R445 1-216-025-11 RES-CHIP 100 5% 1/10W
(STR-DA2000ES)
R446 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
(STR-DA2000ES)
R447 1-216-049-11 RES-CHIP 1K 5% 1/10W
(STR-DA2000ES)
R452 1-216-049-11 RES-CHIP 1K 5% 1/10W
(STR-DA2000ES)
R453 1-216-097-11 RES-CHIP 100K 5% 1/10W
(STR-DA2000ES)
R454 1-216-093-11 RES-CHIP 68K 5% 1/10W
(STR-DA2000ES)
R455 1-216-025-11 RES-CHIP 100 5% 1/10W
(STR-DA2000ES)
