Sony STR-DB2000 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
127
STR-DA2000ES/DB2000
R2904 1-216-226-00 RES-CHIP 15K 5% 1/8W
(STR-DA2000ES)
R2905 1-216-222-00 RES-CHIP 10K 5% 1/8W
(STR-DA2000ES)
R2906 1-216-222-00 RES-CHIP 10K 5% 1/8W
(STR-DA2000ES)
R2920 1-216-246-00 RES-CHIP 100K 5% 1/8W
(STR-DA2000ES)
R2921 1-216-208-00 RES-CHIP 2.7K 5% 1/8W
(STR-DA2000ES)
R2922 1-216-218-91 RES-CHIP 6.8K 5% 1/8W
(STR-DA2000ES)
R2924 1-216-226-00 RES-CHIP 15K 5% 1/8W
(STR-DA2000ES)
R2925 1-216-222-00 RES-CHIP 10K 5% 1/8W
(STR-DA2000ES)
R2926 1-216-222-00 RES-CHIP 10K 5% 1/8W
(STR-DA2000ES)
< VIBRATOR >
X1101 1-781-465-21 VIBRATOR, CRYSTAL (12.288MHz)
X2201 1-781-527-21 VIBRATOR, CRYSTAL (13.5MHz)
X2601 1-795-179-21 VIBRATOR, CERAMIC (16.5MHz)
************************************************************
A-4733-935-A DISPLAY BOARD, COMPLETE
************************
4-246-462-01 HOLDER (FL)
* 4-921-941-01 CUSHION (FL)
< CAPACITOR >
C01 1-128-809-11 CERAMIC CHIP 100P 5% 50V
C1001 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1002 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1003 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1004 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1006 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1007 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1008 1-126-786-11 ELECT 47uF 20% 16V
C1009 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1010 1-126-796-11 ELECT 22uF 20% 50V
C1031 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1051 1-126-786-11 ELECT 47uF 20% 16V
C1071 1-124-596-11 ELECT 27uF 20% 16V
C1072 1-137-462-11 MYLAR 0.018uF 5% 100V
C1073 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1074 1-126-321-91 ELECT 12uF 20% 35V
C1075 1-126-321-91 ELECT 12uF 20% 35V
C1076 1-126-321-91 ELECT 12uF 20% 35V
C1077 1-165-319-11 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
CN1001 1-568-844-11 CONNECTOR, FFC 29P
< DIODE >
D1031 8-719-084-07 LED SEL5E20CTP15
(MULTI CHANNEL DECODING)
D1071 8-719-041-97 DIODE MA113- (TX)
D1072 8-719-041-97 DIODE MA113- (TX)
D1073 8-719-041-97 DIODE MA113- (TX)
D1074 8-719-041-97 DIODE MA113- (TX)
D1075 8-719-056-84 DIODE UDZ-TE-17-7.5B
< FILTER >
FL1001 1-518-870-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC1001 6-704-198-01 IC M66003-0121FP
IC1051 8-759-826-34 IC NJL74H400A
< COIL >
L1071 1-456-516-11 INDUCTOR 47uH
< TRANSISTOR >
Q1031 8-729-216-22 TRANSISTOR 2SA1162-G
Q1032 8-729-230-49 TRANSISTOR 2SC2712-YG
Q1033 8-729-900-53 TRANSISTOR DTC114EK
Q1071 8-729-808-42 TRANSISTOR 2SD1624-T
Q1072 8-729-808-42 TRANSISTOR 2SD1624-T
< RESISTOR >
R01 1-216-855-11 CARBON 10K 5% 1/4W
R1001 1-216-025-11 RES-CHIP 100 5% 1/10W
R1002 1-216-025-11 RES-CHIP 100 5% 1/10W
R1003 1-216-025-11 RES-CHIP 100 5% 1/10W
R1004 1-216-025-11 RES-CHIP 100 5% 1/10W
R1005 1-216-089-11 RES-CHIP 47K 5% 1/10W
R1006 1-216-077-00 RES-CHIP 15K 5% 1/10W
0R1011 1-249-381-11 CARBON 1 5% 1/4W F
0R1012 1-249-381-11 CARBON 1 5% 1/4W F
R1031 1-216-033-00 RES-CHIP 220 5% 1/10W
R1032 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1033 1-216-019-00 RES-CHIP 56 5% 1/10W
R1034 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1035 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1042 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1043 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R1044 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R1045 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1046 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1047 1-216-081-00 RES-CHIP 22K 5% 1/10W
R1052 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1053 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R1054 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R1055 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1056 1-216-073-00 RES-CHIP 10K 5% 1/10W
R1057 1-216-081-00 RES-CHIP 22K 5% 1/10W
R1058 1-216-001-00 RES-CHIP 10 5% 1/10W
R1059 1-216-025-11 RES-CHIP 100 5% 1/10W
R1071 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1073 1-216-081-00 RES-CHIP 22K 5% 1/10W
R1074 1-216-295-00 SHORT CHIP 0
R1075 1-216-025-11 RES-CHIP 100 5% 1/10W
R1076 1-216-025-11 RES-CHIP 100 5% 1/10W
DIGITAL DISPLAY
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
