Sony STR-DB2000 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
104
STR-DA2000ES/DB2000
2CH. AU
R456 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
(STR-DA2000ES)
R457 1-216-049-11 RES-CHIP 1K 5% 1/10W
(STR-DA2000ES)
R461 1-216-089-11 RES-CHIP 47K 5% 1/10W
R462 1-216-073-00 RES-CHIP 10K 5% 1/10W
R463 1-216-073-00 RES-CHIP 10K 5% 1/10W
R464 1-216-073-00 RES-CHIP 10K 5% 1/10W
R465 1-216-073-00 RES-CHIP 10K 5% 1/10W
R485 1-216-013-00 RES-CHIP 33 5% 1/10W
R486 1-216-013-00 RES-CHIP 33 5% 1/10W
R487 1-216-295-00 SHORT CHIP 0
R488 1-216-295-00 SHORT CHIP 0
R489 1-216-295-00 SHORT CHIP 0
R491 1-216-097-11 RES-CHIP 100K 5% 1/10W
R492 1-216-097-11 RES-CHIP 100K 5% 1/10W
R493 1-216-097-11 RES-CHIP 100K 5% 1/10W
R494 1-216-097-11 RES-CHIP 100K 5% 1/10W
R510 1-216-049-11 RES-CHIP 1K 5% 1/10W
R511 1-216-198-00 RES-CHIP 1K 5% 1/8W
(EXCEPT STR-DB2000: AEP, UK)
R511 1-259-995-11 CARBON MELF 1K 2% 1/8W
(STR-DB2000: AEP, UK)
R512 1-216-049-11 RES-CHIP 1K 5% 1/10W
R513 1-216-049-11 RES-CHIP 1K 5% 1/10W
R514 1-216-049-11 RES-CHIP 1K 5% 1/10W
R515 1-216-049-11 RES-CHIP 1K 5% 1/10W
R516 1-216-049-11 RES-CHIP 1K 5% 1/10W
R517 1-216-049-11 RES-CHIP 1K 5% 1/10W
R518 1-216-049-11 RES-CHIP 1K 5% 1/10W
R519 1-216-049-11 RES-CHIP 1K 5% 1/10W
R520 1-216-049-11 RES-CHIP 1K 5% 1/10W
R521 1-216-049-11 RES-CHIP 1K 5% 1/10W
R522 1-216-238-91 RES-CHIP 47K 5% 1/8W
(EXCEPT STR-DB2000: AEP, UK)
R522 1-260-016-11 CARBON MELF 47K 2% 1/8W
(STR-DB2000: AEP, UK)
R523 1-216-089-11 RES-CHIP 47K 5% 1/10W
R524 1-216-089-11 RES-CHIP 47K 5% 1/10W
R525 1-216-089-11 RES-CHIP 47K 5% 1/10W
R526 1-216-089-11 RES-CHIP 47K 5% 1/10W
R527 1-216-089-11 RES-CHIP 47K 5% 1/10W
R528 1-216-089-11 RES-CHIP 47K 5% 1/10W
R529 1-216-089-11 RES-CHIP 47K 5% 1/10W
R531 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
(STR-DB2000)
R531 1-216-295-00 SHORT CHIP 0 (STR-DA2000ES)
R532 1-216-097-11 RES-CHIP 100K 5% 1/10W
R533 1-216-097-11 RES-CHIP 100K 5% 1/10W
R534 1-216-031-00 RES-CHIP 180 5% 1/10W
R535 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R536 1-216-097-11 RES-CHIP 100K 5% 1/10W
R537 1-216-025-11 RES-CHIP 100 5% 1/10W
R538 1-216-097-11 RES-CHIP 100K 5% 1/10W
R539 1-216-041-00 RES-CHIP 470 5% 1/10W
R541 1-216-089-11 RES-CHIP 47K 5% 1/10W
(STR-DA2000ES)
R544 1-216-093-11 RES-CHIP 68K 5% 1/10W
(STR-DA2000ES)
R545 1-216-025-11 RES-CHIP 100 5% 1/10W
(STR-DA2000ES)
R546 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
(STR-DA2000ES)
R547 1-216-049-11 RES-CHIP 1K 5% 1/10W
(STR-DA2000ES)
R552 1-216-049-11 RES-CHIP 1K 5% 1/10W
(STR-DA2000ES)
R553 1-216-097-11 RES-CHIP 100K 5% 1/10W
(STR-DA2000ES)
R554 1-216-093-11 RES-CHIP 68K 5% 1/10W
(STR-DA2000ES)
R555 1-216-025-11 RES-CHIP 100 5% 1/10W
(STR-DA2000ES)
R556 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
(STR-DA2000ES)
R557 1-216-049-11 RES-CHIP 1K 5% 1/10W
(STR-DA2000ES)
R561 1-216-089-11 RES-CHIP 47K 5% 1/10W
R562 1-216-073-00 RES-CHIP 10K 5% 1/10W
R563 1-216-073-00 RES-CHIP 10K 5% 1/10W
R564 1-216-073-00 RES-CHIP 10K 5% 1/10W
R565 1-216-073-00 RES-CHIP 10K 5% 1/10W
R585 1-216-013-00 RES-CHIP 33 5% 1/10W
R586 1-216-013-00 RES-CHIP 33 5% 1/10W
R587 1-216-295-00 SHORT CHIP 0
R588 1-216-295-00 SHORT CHIP 0
R589 1-216-295-00 SHORT CHIP 0
R591 1-216-097-11 RES-CHIP 100K 5% 1/10W
R592 1-216-097-11 RES-CHIP 100K 5% 1/10W
R593 1-216-097-11 RES-CHIP 100K 5% 1/10W
R594 1-216-097-11 RES-CHIP 100K 5% 1/10W
R631 1-216-001-00 RES-CHIP 10 5% 1/10W
(STR-DA2000ES)
R632 1-216-033-00 RES-CHIP 220 5% 1/10W
(STR-DA2000ES)
R633 1-216-049-11 RES-CHIP 1K 5% 1/10W
(STR-DA2000ES)
R644 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
(STR-DA2000ES)
R645 1-216-073-00 RES-CHIP 10K 5% 1/10W
(STR-DA2000ES)
0R646 1-249-393-11 CARBON 10 5% 1/4W F
(STR-DA2000ES)
R652 1-216-013-00 RES-CHIP 33 5% 1/10W
(STR-DA2000ES)
R653 1-216-013-00 RES-CHIP 33 5% 1/10W
(STR-DA2000ES)
R654 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
(STR-DA2000ES)
R655 1-216-073-00 RES-CHIP 10K 5% 1/10W
(STR-DA2000ES)
0R656 1-249-393-11 CARBON 10 5% 1/4W F
(STR-DA2000ES)
R657 1-216-295-00 SHORT CHIP 0 (STR-DA2000ES)
R658 1-216-295-00 SHORT CHIP 0 (STR-DA2000ES)
R659 1-216-295-00 SHORT CHIP 0 (STR-DA2000ES)
R681 1-216-073-00 RES-CHIP 10K 5% 1/10W
R682 1-216-073-00 RES-CHIP 10K 5% 1/10W
R685 1-216-013-00 RES-CHIP 33 5% 1/10W
(STR-DA2000ES)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
