STR-DA2000ES/DB2000
2. ELECTRICAL PARTS LIST
CIS DISPLAY
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4733-946-A CIS BOARD, COMPLETE (STR-DA2000ES)
*******************
< CAPACITOR >
C801 1-126-947-11 ELECT 47uF 20% 35V
C802 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C803 1-126-961-11 ELECT 2.2uF 20% 50V
C840 1-216-295-00 SHORT CHIP 0
C841 1-126-960-11 ELECT 1uF 20% 50V
C851 1-126-767-11 ELECT 1000uF 20% 16V
C852 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C871 1-216-295-00 SHORT CHIP 0
C872 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C873 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C874 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C875 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C876 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C877 1-126-947-11 ELECT 47uF 20% 35V
< CONNECTOR >
CN801 1-568-826-11 CONNECTOR, FFC 7P
< DIODE >
D801 8-719-988-61 DIODE 1SS355TE-17
D802 8-719-075-86 LED SID307BRTP19
(REMOTE CONTROL TRANSCEIVER)
D803 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB871 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC801 8-759-826-32 IC NJL72H400A
IC802 8-759-564-49 IC TC7W53FU (TE12R)
IC871 8-759-663-90 IC ADM3222ARU-REEL
< JACK >
J801 1-563-330-11 JACK (IR REMOTE OUT)
J802 1-563-330-11 JACK (IR REMOTE IN)
J841 1-563-330-11 JACK (TRIGGER OUT)
J871 1-815-737-11 CONNECTOR, (D) SUB 9P (RS232C)
< TRANSISTOR >
Q841 8-729-140-93 TRANSISTOR 2SB733-34
Q842 8-729-900-53 TRANSISTOR DTC114EK
< RESISTOR >
R801 1-216-073-00 RES-CHIP 10K 5% 1/10W
R802 1-216-001-00 RES-CHIP 10 5% 1/10W
R803 1-216-097-11 RES-CHIP 100K 5% 1/10W
R804 1-216-073-00 RES-CHIP 10K 5% 1/10W
R805 1-216-097-11 RES-CHIP 100K 5% 1/10W
R806 1-216-025-11 RES-CHIP 100 5% 1/10W
R807 1-216-025-11 RES-CHIP 100 5% 1/10W
R842 1-216-073-00 RES-CHIP 10K 5% 1/10W
R843 1-216-049-11 RES-CHIP 1K 5% 1/10W
R844 1-216-073-00 RES-CHIP 10K 5% 1/10W
R845 1-216-025-11 RES-CHIP 100 5% 1/10W
R846 1-216-049-11 RES-CHIP 1K 5% 1/10W
R871 1-216-025-11 RES-CHIP 100 5% 1/10W
R872 1-216-025-11 RES-CHIP 100 5% 1/10W
< THERMISTOR (POSITIVE) >
THP841 1-801-726-11 THERMISTOR, POSITIVE
************************************************************
A-4733-935-A DISPLAY BOARD, COMPLETE
************************
4-246-462-01 HOLDER (FL)
* 4-921-941-01 CUSHION (FL)
< CAPACITOR >
C1001 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1002 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1003 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1004 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1006 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1007 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1008 1-126-786-11 ELECT 47uF 20% 16V
C1009 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1010 1-126-796-11 ELECT 22uF 20% 50V
C1029 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1031 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1051 1-126-786-11 ELECT 47uF 20% 16V
C1071 1-124-596-11 ELECT 27uF 20% 16V
•Abbreviation
MY : Malaysia model
SP : Singapore model
To Next Page
