Sony STR-DB2000 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
16
STR-DA2000ES/DB2000
IC912 8-759-231-53 IC TA7805S
* IC913 8-729-045-93 TRANSISTOR IMZ4T108
< COIL >
L901 1-421-967-11 INDUCTOR 100uH
L902 1-421-967-11 INDUCTOR 100uH
< TRANSISTOR >
Q905 8-729-216-31 TRANSISTOR 2SA1163-G
Q906 8-729-271-31 TRANSISTOR 2SC2713-G
Q908 8-729-271-31 TRANSISTOR 2SC2713-G
Q911 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q912 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q913 6-550-363-01 TRANSISTOR 2SB1690KT146
Q914 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R905 1-249-589-31 CARBON 36K 5% 1/4W
R906 1-216-025-11 RES-CHIP 100 5% 1/10W
R907 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R908 1-216-369-00 METAL OXIDE 1 5% 2W
R909 1-216-113-00 RES-CHIP 470K 5% 1/10W
R910 1-216-073-00 RES-CHIP 10K 5% 1/10W
R911 1-216-063-00 RES-CHIP 3.9K 5% 1/10W
R912 1-216-077-00 RES-CHIP 15K 5% 1/10W
R913 1-216-049-11 RES-CHIP 1K 5% 1/10W
R914 1-216-295-00 SHORT CHIP 0
R915 1-216-025-11 RES-CHIP 100 5% 1/10W
R916 1-216-073-00 RES-CHIP 10K 5% 1/10W
R917 1-215-869-11 METAL OXIDE 1K 5% 1W
R918 1-216-041-11 RES-CHIP 470 5% 1/10W
R919 1-216-049-11 RES-CHIP 1K 5% 1/10W
R920 1-216-049-11 RES-CHIP 1K 5% 1/10W
R921 1-216-073-00 RES-CHIP 10K 5% 1/10W
R922 1-249-607-31 CARBON 200K 5% 1/4W
R927 1-249-958-11 CARBON 30K 5% 1/4W
R928 1-249-937-11 CARBON 2.9K 5% 1/4W
R929 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R930 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R931 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
************************************************************
A-4733-944-A S-VIDEO BOARD, COMPLETE (STR-DA2000ES)
A-4734-037-A S-VIDEO BOARD, COMPLETE (STR-DB2000)
************************
< CAPACITOR >
C701 1-126-964-11 ELECT 10uF 20% 50V
C702 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C703 1-126-964-11 ELECT 10uF 20% 50V
C704 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C705 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C706 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C707 1-126-964-11 ELECT 10uF 20% 50V
C708 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C726 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C727 1-126-964-11 ELECT 10uF 20% 50V
C731 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C732 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C733 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C734 1-165-319-11 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
CN701 1-568-444-11 SOCKET, CONNECTOR 13P
CN753 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
< DIODE >
D701 8-719-801-78 DIODE 1SS184
D761 8-719-016-74 DIODE 1SS352
D766 8-719-016-74 DIODE 1SS352
< IC >
IC701 6-704-199-01 IC NJM2595M-TE2
IC702 6-704-199-01 IC NJM2595M-TE2
< JACK >
J701 1-764-676-11 CONNECTOR (ROUND TYPE)
(DVD S-VIDEO IN, TV/SAT S-VIDEO IN)
J705 1-764-676-11 CONNECTOR (ROUND TYPE)
(VIDEO1 S-VIDEO IN, VIDEO1 S-VIDEO OUT)
J709 1-537-943-11 TERMINAL, S (MONITOR S-VIDEO OUT)
J751 1-817-726-11 JACK, PIN 9P
(TV-SAT IN, DVD IN, MONITOR OUT)
< TRANSISTOR >
Q761 8-729-230-49 TRANSISTOR 2SC2712-YG
Q766 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R701 1-216-022-00 RES-CHIP 75 5% 1/10W
R702 1-216-022-00 RES-CHIP 75 5% 1/10W
R703 1-216-022-00 RES-CHIP 75 5% 1/10W
R704 1-216-022-00 RES-CHIP 75 5% 1/10W
R705 1-216-022-00 RES-CHIP 75 5% 1/10W
R706 1-216-022-00 RES-CHIP 75 5% 1/10W
R707 1-216-022-00 RES-CHIP 75 5% 1/10W
R708 1-216-022-00 RES-CHIP 75 5% 1/10W
R709 1-216-022-00 RES-CHIP 75 5% 1/10W
R710 1-216-022-00 RES-CHIP 75 5% 1/10W
R712 1-216-295-00 SHORT CHIP 0
R713 1-216-295-00 SHORT CHIP 0
R721 1-216-295-00 SHORT CHIP 0
R760 1-216-295-00 SHORT CHIP 0
R761 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R762 1-216-073-00 RES-CHIP 10K 5% 1/10W
R766 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R767 1-216-073-00 RES-CHIP 10K 5% 1/10W
< RELAY >
RY761 1-755-184-11 RELAY
RY762 1-755-184-11 RELAY
RY766 1-755-184-11 RELAY
RY767 1-755-184-11 RELAY
************************************************************
REG S-VIDEO
