STR-DA2000ES/DB2000
• D-AMP BOARD IC1800 MB89537APFM-G-461-BNDE1 (SUB SYSTEM CONTROLLER)
Pin No. Pin Name I/O Description
1I LIMIT I Current detection signal input from the protect circuit
2MOD2 I Not used
3 TEMP I Thermistor connection terminal for abnormal temperature detection (A/D input)
4 to 10 — — Not used
11 AVCC — Power supply terminal (+3.3V) (for analog system)
12 AVR I Reference voltage (+3.3V) input terminal
13 AVSS — Ground terminal (for analog system)
14 U-MAIN I Clock signal input from main system controller
15 AC-OFF I AC off detection signal input terminal “L”: AC off
16 +B I +B power supply abnormal detection signal input terminal
17, 18 — — Not used
19 RST I Reset signal input from the main system controller “L”: reset
20, 21 MOD0, MOD1 I Setting terminal for memory access mode Normally: fixed at “L”
22 X0 I System clock input terminal (8 MHz)
23 X1 O System clock output terminal (8 MHz)
24 VSS — Ground terminal
25 VOL-CLK O Serial data transfer clock signal output to the data decoder
26 VOL-DATA O Serial data output to the data decoder
27 VOL-LAT O Serial data latch pulse signal output to the data decoder
28 DAC-MUTE O Muting on/off control signal output terminal Not used
29, 30 (P23), (P22) — Not used
31 4I-LIMIT I Not used
32 DC I DC offset detection signal input from the protect circuit
33 — — Not used
34 4/8OUT O Not used
35 DIAG I Thermistor connection terminal for abnormal temperature detection (A/D input)
36 EN O Enable/Disable control signal output terminal
37 MODE1 O Mode signal output to PCM/PWM processor
38 INIT O Initialize signal output to the PCM/PWM processor
39 NSP-MUTE O Muting on/off control signal output terminal Not used
40 (P10) — Not used
41 — — Not used
42 U-SUB1 I Serial data input from main system controller
43 LAT4 O Serial data latch pulse signal (for surround back) output to the PCM/PWM processor
44 LAT3 O Serial data latch pulse signal (for surround) output to the PCM/PWM processor
45 LAT2 O Serial data latch pulse signal (for center) output to the PCM/PWM processor
46 LAT1 O Serial data latch pulse signal (for front) output to the PCM/PWM processor
47 F-B RY O Relay drive signal (for front speaker B) output terminal
48 SR-A RY O Relay drive signal (for surround speaker A) output terminal Not used
49 NC — Not used
50 F-A RY O Relay drive signal (for front speaker A) output terminal
51 SHIFT O Serial data transfer clock signal output to the PCM/PWM processor
52 SCDT O Serial data output to the PCM/PWM processor
53 SR-B RY O Relay drive signal (for surround speaker B) output terminal Not used
54 C RY O Relay drive signal (for center speaker) output terminal Not used
To Next Page
