Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 90 —
D705 8-719-987-63 DIODE 1N4148M
D706 8-719-987-63 DIODE 1N4148M
D707 8-719-002-06 DIODE UZL-18L
D749 8-719-987-63 DIODE 1N4148M
< JACK >
J501 1-770-377-31 JACK, PIN 1P (WOOFER)
< COIL >
L601 1-411-906-11 COIL, AIR-CORE (V909/VE910)
L601 1-420-872-00 COIL, AIR-CORE (DE915)
L701 1-411-906-11 COIL, AIR-CORE (V909/VE910)
L701 1-420-872-00 COIL, AIR-CORE (DE915)
L751 1-411-906-11 COIL, AIR-CORE (V909/VE910)
L751 1-420-872-00 COIL, AIR-CORE (DE915)
< TRANSISTOR >
Q544 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q609 8-729-281-53 TRANSISTOR 2SC1815-GR
Q610 8-729-900-63 TRANSISTOR DTA124ES
Q611 8-729-900-63 TRANSISTOR DTA124ES
Q645 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q709 8-729-281-53 TRANSISTOR 2SC1815-GR
Q710 8-729-900-63 TRANSISTOR DTA124ES
Q745 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q748 8-729-209-15 TRANSISTOR 2SD2012
< RESISTOR >
R543 1-249-429-11 CARBON 10K 5% 1/4W
R544 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R545 1-249-393-11 CARBON 10 5% 1/4W F
R546 1-249-425-11 CARBON 4.7K 5% 1/4W F
R629 1-247-866-11 CARBON 30K 5% 1/4W
R630 1-249-421-11 CARBON 2.2K 5% 1/4W F
R631 1-249-433-11 CARBON 22K 5% 1/4W
R632 1-249-433-11 CARBON 22K 5% 1/4W
! R633 1-249-393-11 CARBON 10 5% 1/4W F
! R634 1-249-389-11 CARBON 4.7 5% 1/4W F
R635 1-249-431-11 CARBON 15K 5% 1/4W
R647 1-249-429-11 CARBON 10K 5% 1/4W
R648 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R649 1-249-393-11 CARBON 10 5% 1/4W F
R729 1-247-866-11 CARBON 30K 5% 1/4W
R730 1-249-421-11 CARBON 2.2K 5% 1/4W F
R731 1-249-433-11 CARBON 22K 5% 1/4W
! R733 1-249-393-11 CARBON 10 5% 1/4W F
! R734 1-249-389-11 CARBON 4.7 5% 1/4W F
R735 1-249-431-11 CARBON 15K 5% 1/4W
R737 1-249-429-11 CARBON 10K 5% 1/4W
R738 1-247-887-00 CARBON 220K 5% 1/4W
R746 1-249-417-11 CARBON 1K 5% 1/4W F
R747 1-249-429-11 CARBON 10K 5% 1/4W
R748 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R749 1-249-393-11 CARBON 10 5% 1/4W F
! R783 1-249-393-11 CARBON 10 5% 1/4W F
! R784 1-249-389-11 CARBON 4.7 5% 1/4W F
R787 1-249-429-11 CARBON 10K 5% 1/4W
R788 1-247-887-00 CARBON 220K 5% 1/4W
< RELAY >
RY503 1-515-793-11 RELAY
RY601 1-515-920-11 RELAY (24V)
RY701 1-515-920-11 RELAY (24V)
< SWITCH >
S501 1-692-196-11 SWITCH, SLIDE (IMP SELECTOR)(DE915)
< TERMINAL >
TM501 1-537-881-11 TERMINAL BOARD (6P)
(SURROUND SPEAKERS)
************************************************************
* 1-665-775-11 SP SW BOARD
***********
< CONNECTOR >
* CNS101 1-695-808-11 CONNECTOR, PC BOARD 8P
< DIODE >
D152 8-719-987-63 DIODE 1N4148M
D153 8-719-987-63 DIODE 1N4148M
< SWITCH >
S136 1-762-751-11 SWITCH, TACTILE (DPC MODE)
S152 1-554-118-00 SWITCH, PUSH (1 KEY) (POWER)(V909/VE910)
S155 1-762-268-11 SWITCH, ROTARY (SPEAKERS)
************************************************************
* A-4398-236-A SUR BOARD, COMPLETE (VE910:AEP,UK,G,
******************** AED,EE)
* A-4398-266-A SUR BOARD, COMPLETE (DE915:US,CND,PX)
********************
* A-4398-279-A SUR BOARD, COMPLETE (V909/VE910:E,SP,
******************** MY)
* A-4398-287-A SUR BOARD, COMPLETE (DE915:AUS)
********************
< CAPACITOR >
C301 1-126-963-11 ELECT 4.7uF 20% 50V
C302 1-162-282-31 CERAMIC 100PF 10% 50V
C303 1-126-967-11 ELECT 47uF 20% 16V
C304 1-130-480-00 MYLAR 0.0056uF 5% 50V
C305 1-106-347-00 MYLAR 1500PF 5% 200V
C306 1-126-960-11 ELECT 1uF 20% 50V
C307 1-164-159-11 CERAMIC 0.1uF 50V
C351 1-126-963-11 ELECT 4.7uF 20% 50V
C352 1-162-282-31 CERAMIC 100PF 10% 50V
C353 1-126-967-11 ELECT 47uF 20% 16V
C354 1-130-480-00 MYLAR 0.0056uF 5% 50V
C355 1-106-347-00 MYLAR 1500PF 5% 200V
C356 1-126-960-11 ELECT 1uF 20% 50V
C357 1-164-159-11 CERAMIC 0.1uF 50V
C394 1-126-967-11 ELECT 47uF 20% 16V
SP (2F) SP SW SUR
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
