Sony STR-DE915 - Electrical Parts List - SUR, SUR-AUDIO, SW Components; Components for SUR, SUR-AUDIO, SW Boards

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 91 —
C395 1-126-967-11 ELECT 47uF 20% 16V
C396 1-164-070-11 CERAMIC 100PF 5% 50V
C397 1-162-294-31 CERAMIC 0.001uF 10% 50V
C401 1-128-547-11 ELECT 6800uF 20% 16V
C402 1-126-935-11 ELECT 470uF 20% 16V
C403 1-126-935-11 ELECT 470uF 20% 16V
C407 1-126-964-11 ELECT 10uF 20% 50V
C408 1-164-159-11 CERAMIC 0.1uF 50V
C409 1-130-495-00 MYLAR 0.1uF 5% 50V
C410 1-130-495-00 MYLAR 0.1uF 5% 50V
C457 1-126-964-11 ELECT 10uF 20% 50V
C458 1-164-159-11 CERAMIC 0.1uF 50V
C501 1-126-964-11 ELECT 10uF 20% 50V
C502 1-164-070-11 CERAMIC 100PF 5% 50V
C503 1-107-601-11 CERAMIC 33PF 5% 500V
C504 1-164-040-11 CERAMIC 4PF 0.25PF 50V
C505 1-126-933-11 ELECT 100uF 20% 16V
C551 1-126-964-11 ELECT 10uF 20% 50V
C552 1-164-070-11 CERAMIC 100PF 5% 50V
C553 1-107-601-11 CERAMIC 33PF 5% 500V
C554 1-164-040-11 CERAMIC 4PF 0.25PF 50V
C555 1-126-933-11 ELECT 100uF 20% 16V
C593 1-126-923-11 ELECT 220uF 20% 10V
C594 1-128-560-11 ELECT 22uF 20% 100V
C595 1-128-560-11 ELECT 22uF 20% 100V
C601 1-126-964-11 ELECT 10uF 20% 50V
C602 1-162-282-31 CERAMIC 100PF 10% 50V
C603 1-102-989-00 CERAMIC 68PF 5% 500V
C604 1-164-040-11 CERAMIC 4PF 0.25PF 50V
C605 1-126-967-11 ELECT 47uF 20% 16V
C606 1-102-989-00 CERAMIC 68PF 5% 500V
C607 1-126-964-11 ELECT 10uF 20% 50V
CC01 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC02 1-162-286-31 CERAMIC 220PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC03 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC04 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC05 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC06 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC07 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC08 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC51 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC52 1-162-286-31 CERAMIC 220PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC53 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC54 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC55 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC56 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC57 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
CC58 1-162-282-31 CERAMIC 100PF 10% 50V
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
< CONNECTOR >
CNP250 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CNP305 1-695-088-11 PIN, CONNECTOR (PC BOARD) 9P
CNP806 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P (V909/VE910)
CNS401 1-569-323-11 SOCKET, CONNECTOR 19P
CNS403 1-569-324-11 SOCKET, CONNECTOR 21P
CNS404 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CNS405 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CNS406 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
CNS501 1-770-404-11 HOUSING,CONNECTOR(PC BOARD)11P
CNS601 1-770-404-11 HOUSING,CONNECTOR(PC BOARD)11P
< DIODE >
D401 8-719-987-63 DIODE 1N4148M
D402 8-719-200-82 DIODE 11ES2
D403 8-719-200-82 DIODE 11ES2
< IC >
IC301 8-759-805-14 IC LC7822
IC302 8-759-636-74 IC M5218AP-22
IC304 8-759-636-74 IC M5218AP-22
IC401 8-759-231-53 IC TA7805S
IC402 8-759-231-53 IC TA7805S
IC501 8-759-326-52 IC uPC2581V
IC601 8-749-011-16 IC STK350-230
IC602 8-759-636-74 IC M5218AP-22
< JACK >
J301 1-774-725-11 JACK, PIN 2P (PHONO) (V909/VE910)
J302 1-766-394-11 JACK, PIN 6P (TAPE,DAT/MD IN)
J303 1-766-394-11 JACK, PIN 6P (DAT/MD OUT,CD,PHONO)
< TRANSISTOR >
Q401 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q410 8-729-620-05 TRANSISTOR 2SC2603-EF
Q411 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q451 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q503 8-729-422-57 TRANSISTOR UN4111
< RESISTOR >
R301 1-249-409-11 CARBON 220 5% 1/4W F
R302 1-249-441-11 CARBON 100K 5% 1/4W
R303 1-249-441-11 CARBON 100K 5% 1/4W
R304 1-249-416-11 CARBON 820 5% 1/4W F
R305 1-247-897-11 CARBON 560K 5% 1/4W
R306 1-249-437-11 CARBON 47K 5% 1/4W
R307 1-249-441-11 CARBON 100K 5% 1/4W
R308 1-247-807-31 CARBON 100 5% 1/4W
R309 1-249-417-11 CARBON 1K 5% 1/4W F
(V909/VE910)
R310 1-249-417-11 CARBON 1K 5% 1/4W F
R311 1-249-417-11 CARBON 1K 5% 1/4W F
R312 1-249-417-11 CARBON 1K 5% 1/4W F
R313 1-249-417-11 CARBON 1K 5% 1/4W F
R314 1-249-417-11 CARBON 1K 5% 1/4W F
SUR
