Sony STR-DE915 - Page 52

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 92 —
R315 1-249-437-11 CARBON 47K 5% 1/4W
R351 1-249-409-11 CARBON 220 5% 1/4W F
R352 1-249-441-11 CARBON 100K 5% 1/4W
R353 1-249-441-11 CARBON 100K 5% 1/4W
R354 1-249-416-11 CARBON 820 5% 1/4W F
R355 1-247-897-11 CARBON 560K 5% 1/4W
R356 1-249-437-11 CARBON 47K 5% 1/4W
R357 1-249-441-11 CARBON 100K 5% 1/4W
R358 1-247-807-31 CARBON 100 5% 1/4W
R359 1-249-417-11 CARBON 1K 5% 1/4W F
(V909/VE910)
R360 1-249-417-11 CARBON 1K 5% 1/4W F
R361 1-249-417-11 CARBON 1K 5% 1/4W F
R362 1-249-417-11 CARBON 1K 5% 1/4W F
R363 1-249-417-11 CARBON 1K 5% 1/4W F
R394 1-247-807-31 CARBON 100 5% 1/4W
R395 1-247-807-31 CARBON 100 5% 1/4W
R396 1-249-417-11 CARBON 1K 5% 1/4W F
R397 1-249-425-11 CARBON 4.7K 5% 1/4W F
R412 1-249-425-11 CARBON 4.7K 5% 1/4W F
R449 1-249-425-11 CARBON 4.7K 5% 1/4W F
R450 1-249-441-11 CARBON 100K 5% 1/4W
R462 1-249-425-11 CARBON 4.7K 5% 1/4W F
R483 1-249-441-11 CARBON 100K 5% 1/4W
R484 1-249-429-11 CARBON 10K 5% 1/4W
R486 1-249-437-11 CARBON 47K 5% 1/4W
R490 1-249-433-11 CARBON 22K 5% 1/4W
(DE915)
R491 1-249-429-11 CARBON 10K 5% 1/4W
(DE915)
R492 1-249-416-11 CARBON 820 5% 1/4W F
(DE915)
R501 1-249-417-11 CARBON 1K 5% 1/4W F
R502 1-249-439-11 CARBON 68K 5% 1/4W
R503 1-249-439-11 CARBON 68K 5% 1/4W
R504 1-247-820-11 CARBON 360 5% 1/4W
(V909/VE910)
R504 1-249-411-11 CARBON 330 5% 1/4W
(DE915)
R551 1-249-417-11 CARBON 1K 5% 1/4W F
R552 1-249-439-11 CARBON 68K 5% 1/4W
R553 1-249-439-11 CARBON 68K 5% 1/4W
R554 1-247-820-11 CARBON 360 5% 1/4W
(V909/VE910)
R554 1-249-411-11 CARBON 330 5% 1/4W
(DE915)
R590 1-249-417-11 CARBON 1K 5% 1/4W F
! R592 1-249-381-11 CARBON 1 5% 1/4W F
! R593 1-249-381-11 CARBON 1 5% 1/4W F
R601 1-249-417-11 CARBON 1K 5% 1/4W F
R602 1-249-439-11 CARBON 68K 5% 1/4W
R603 1-249-406-11 CARBON 120 5% 1/4W F
(V909/VE910)
R603 1-247-807-31 CARBON 100 5% 1/4W
(DE915)
R604 1-249-439-11 CARBON 68K 5% 1/4W
R605 1-249-413-11 CARBON 470 5% 1/4W F
R606 1-249-439-11 CARBON 68K 5% 1/4W
R607 1-249-417-11 CARBON 1K 5% 1/4W F
R608 1-249-431-11 CARBON 15K 5% 1/4W
RR01 1-249-418-11 CARBON 1.2K 5% 1/4W F
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
RR51 1-249-418-11 CARBON 1.2K 5% 1/4W F
(DE915:AUS/VE910:AEP,UK,G,AED,EE)
< RELAY >
RY401 1-515-614-11 RELAY
< TERMINAL >
TM401 1-694-266-11 TERMINAL BOARD, ANT (ANTENNA)
(DE915:AUS)
TM401 1-694-265-11 TERMINAL BOARD, ANT (ANTENNA)
(DE915:US,CND,PX)
< TUNER >
TU401 1-693-377-11 TUNER (DE915:AUS)
TU401 1-233-592-11 ENCAPSULATED COMPONENT
(DE915:US,CND,PX)
************************************************************
* 1-665-776-11 SUR-AUDIO (2F) BOARD
*****************
< CONNECTOR >
CNP302 1-695-088-11 PIN, CONNECTOR (PC BOARD) 9P
CNS303 1-695-093-11 SOCKET, CONNECTOR 9P
************************************************************
* 1-665-780-11 SW BOARD
********
< CONNECTOR >
CNP103 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
< RESISTOR >
R169 1-249-411-11 CARBON 330 5% 1/4W
R170 1-249-413-11 CARBON 470 5% 1/4W F
R171 1-249-415-11 CARBON 680 5% 1/4W F
R172 1-249-417-11 CARBON 1K 5% 1/4W F
R173 1-249-419-11 CARBON 1.5K 5% 1/4W F
R174 1-249-421-11 CARBON 2.2K 5% 1/4W F
R175 1-249-425-11 CARBON 4.7K 5% 1/4W F
R176 1-249-411-11 CARBON 330 5% 1/4W
R177 1-249-413-11 CARBON 470 5% 1/4W F
R178 1-249-415-11 CARBON 680 5% 1/4W F
R179 1-249-417-11 CARBON 1K 5% 1/4W F
R180 1-249-419-11 CARBON 1.5K 5% 1/4W F
R181 1-249-421-11 CARBON 2.2K 5% 1/4W F
R182 1-249-411-11 CARBON 330 5% 1/4W
R183 1-249-413-11 CARBON 470 5% 1/4W F
R184 1-249-415-11 CARBON 680 5% 1/4W F
R185 1-249-417-11 CARBON 1K 5% 1/4W F
R186 1-249-419-11 CARBON 1.5K 5% 1/4W F
R187 1-249-421-11 CARBON 2.2K 5% 1/4W F
SUR SUR-AUDIO (2F) SW
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
