Sony STR-DE915 - Electrical Parts List - SW, Video, Volume Components; Components for SW, Video, Volume Boards

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 93 —
< SWITCH >
S101 1-762-751-11 SWITCH, TACTILE (1) (DE915)
S102 1-762-751-11 SWITCH, TACTILE (4) (DE915)
S103 1-762-751-11 SWITCH, TACTILE (7) (DE915)
S104 1-762-751-11 SWITCH, TACTILE (0) (DE915)
S105 1-762-751-11 SWITCH, TACTILE (DIRECT PASS)
S106 1-762-751-11 SWITCH, TACTILE (GENRE)
S107 1-762-751-11 SWITCH, TACTILE (SET UP)
S108 1-762-751-11 SWITCH, TACTILE (MODE)
S109 1-762-751-11 SWITCH, TACTILE (2) (DE915)
S110 1-762-751-11 SWITCH, TACTILE (5) (DE915)
S111 1-762-751-11 SWITCH, TACTILE (8) (DE915)
S112 1-762-751-11 SWITCH, TACTILE (DIRECT) (DE915)
S113 1-762-751-11 SWITCH, TACTILE (AUDIO FUNC <)
S114 1-762-751-11 SWITCH, TACTILE (SOUND FIELD)
S115 1-762-751-11 SWITCH, TACTILE (AUDIO FUNC >)
S116 1-762-751-11 SWITCH, TACTILE (3) (DE915)
S117 1-762-751-11 SWITCH, TACTILE (6) (DE915)
S118 1-762-751-11 SWITCH, TACTILE (9) (DE915)
S119 1-762-751-11 SWITCH, TACTILE (SHIFT) (DE915)
S120 1-762-751-11 SWITCH, TACTILE (VIDEO FUNC <)
S121 1-762-751-11 SWITCH, TACTILE (INPUT MODE)
S122 1-762-751-11 SWITCH, TACTILE (VIDEO FUNC >)
************************************************************
* 1-665-777-11 VIDEO (3) BOARD
*************
< CAPACITOR >
C299 1-164-159-11 CERAMIC 0.1uF 50V
< JACK >
J299 1-764-190-11 JACK, PIN 3P (VIDEO 3 INPUT) (V909/VE910)
J299 1-779-868-11 JACK, PIN 3P (VIDEO 3 INPUT) (DE915)
< RESISTOR >
R297 1-249-403-11 CARBON 68 5% 1/4W F
(V909/VE910)
R298 1-249-403-11 CARBON 68 5% 1/4W F
(V909/VE910)
R299 1-249-403-11 CARBON 68 5% 1/4W F
R316 1-249-417-11 CARBON 1K 5% 1/4W F
R366 1-249-417-11 CARBON 1K 5% 1/4W F
************************************************************
* 1-665-784-11 VIDEO BOARD
***********
< CAPACITOR >
C253 1-126-960-11 ELECT 1uF 20% 50V
C256 1-126-960-11 ELECT 1uF 20% 50V
C258 1-126-960-11 ELECT 1uF 20% 50V
C262 1-126-960-11 ELECT 1uF 20% 50V
C264 1-126-964-11 ELECT 10uF 20% 50V
C265 1-126-964-11 ELECT 10uF 20% 50V
C266 1-126-964-11 ELECT 10uF 20% 50V
C267 1-126-960-11 ELECT 1uF 20% 50V
< IC >
IC211 8-759-061-95 IC SN761200
< CONNECTOR >
CNS215 1-695-092-11 SOCKET, CONNECTOR 7P
< JACK >
J209 1-766-400-11 JACK, PIN 2P (VIDEO 2)
J210 1-766-399-11 JACK, PIN 3P (VIDEO 1,MONITOR)
J211 1-766-400-11 JACK, PIN 2P (VIDEO 3)
< TRANSISTOR >
Q214 8-729-620-05 TRANSISTOR 2SC2603-EF
Q215 8-729-620-05 TRANSISTOR 2SC2603-EF
Q216 8-729-620-05 TRANSISTOR 2SC2603-EF
Q217 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q218 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q219 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R207 1-249-409-11 CARBON 220 5% 1/4W F
R266 1-249-403-11 CARBON 68 5% 1/4W F
R268 1-249-403-11 CARBON 68 5% 1/4W F
R269 1-249-403-11 CARBON 68 5% 1/4W F
R270 1-249-426-11 CARBON 5.6K 5% 1/4W
R271 1-249-426-11 CARBON 5.6K 5% 1/4W
R272 1-249-426-11 CARBON 5.6K 5% 1/4W
R274 1-249-403-11 CARBON 68 5% 1/4W F
R275 1-249-403-11 CARBON 68 5% 1/4W F
R276 1-249-419-11 CARBON 1.5K 5% 1/4W F
R277 1-249-419-11 CARBON 1.5K 5% 1/4W F
R278 1-249-419-11 CARBON 1.5K 5% 1/4W F
R279 1-249-403-11 CARBON 68 5% 1/4W F
R280 1-249-403-11 CARBON 68 5% 1/4W F
R281 1-249-403-11 CARBON 68 5% 1/4W F
R282 1-249-403-11 CARBON 68 5% 1/4W F
R283 1-249-403-11 CARBON 68 5% 1/4W F
R288 1-249-430-11 CARBON 12K 5% 1/4W
R289 1-249-430-11 CARBON 12K 5% 1/4W
R290 1-249-430-11 CARBON 12K 5% 1/4W
R2009 1-249-409-11 CARBON 220 5% 1/4W F
R2010 1-249-409-11 CARBON 220 5% 1/4W F
************************************************************
* 1-665-788-11 VOL SEL BOARD (DE915:PX/VE910:E)
**************
< CONNECTOR >
CNP910 1-564-321-00 PIN, CONNECTOR 2P (DE915:PX/VE910:E)
* CNP911 1-564-687-11 PIN, CONNECTOR 3P (DE915:PX/VE910:E)
* CNP912 1-564-687-11 PIN, CONNECTOR 3P (DE915:PX/VE910:E)
< SWITCH >
! S902 1-571-437-11 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR) (DE915:PX/VE910:E)
************************************************************
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
SW VIDEO (3) VIDEO VOL SEL
