94
* 1-665-774-11 VOLUME BOARD
************
< CONNECTOR >
CNP102 1-770-388-11 PIN, CONNECTOR (PC BOARD) 4P
CNS402 1-569-323-11 SOCKET, CONNECTOR 19P
< RESISTOR >
R499 1-249-411-11 CARBON 330 5% 1/4W
< VARIABLE RESISTOR >
RV401 1-225-445-11 RES, VAR, CARBON 100KX6
(MASTER VOLUME)
************************************************************
MISCELLANEOUS
*************
19 1-773-174-11 WIRE (FLAT TYPE) (21 CORE)(46cm)
20 1-773-057-11 WIRE (FLAT TYPE) (17 CORE)
22 1-773-107-11 WIRE (FLAT TYPE) (19 CORE)(17cm)
57 1-773-116-11 WIRE (FLAT TYPE) (19 CORE)(23cm)
58 1-773-174-11 WIRE (FLAT TYPE) (21 CORE)(9cm)
! 60 1-696-847-11 CORD, POWER (AUS)
! 60 1-769-743-11 CORD, POWER (US,CND)
! 60 1-769-744-11 CORD, POWER (EXCEPT US,CND,AUS,CH)
! 60 1-782-464-21 CORD, POWER (CH)
! 69 1-569-008-11 ADAPTOR, CONVERSION 2P (E,PX)
! 70 1-770-019-11 ADAPTOR, CONVERSION 3P (UK)
! CNJ909 1-251-416-11 OUTLET, AC (AC OUTLET) (AUS)
! CNJ909 1-526-794-11 OUTLET, AC (EXCEPT US,CND,AUS,PX,CH)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-475-134-11 REMOTE COMMANDER (RM-P501)
1-501-374-11 ANTENNA, LOOP (DE915)
1-501-594-11 ANTENNA (FM) (DE915:AUS)
1-777-172-11 CORD, CONNECTION (DE915:US,CND)
3-703-044-26 LABEL, CAUTION (DE915:US,CND)
3-810-765-11 MANUAL,COMMONNESS INSTRUCTION
(ENGLISH)(DE915:US)
3-810-765-21 MANUAL,COMMONNESS INSTRUCTION
(ENGLISH,FRENCH,GERMAN,SPANISH,DUTCH,
SWEDISH,ITALIAN,PORTUGUESE,CHINESE)
(DE915)
3-860-516-11 MANUAL, INSTRUCTION (ENGLISH)
(DE915:US,AUS)
3-860-516-21 MANUAL, INSTRUCTION (FRENCH)
(DE915:CND)
3-860-516-31 MANUAL, INSTRUCTION (ENGLISH)
(DE915:PX)
3-861-329-11 MANUAL, INSTRUCTION
(ENGLISH/FRENCH/DUTCH/SWEDISH)
(VE910:AEP,UK,AED,EE)
3-861-329-21 MANUAL, INSTRUCTION
(GERMAN,SPANISH,ITALIAN,PORTUGUESE)
(VE910:AEP,UK,G,AED,EE)
3-861-329-41 MANUAL, INSTRUCTION (ENGLISH/CHINESE)
(VE910:E,SP,MY)
3-861-329-51 MANUAL, INSTRUCTION
(ENGLISH/CHINESE) (V909)
4-983-536-01 COVER, BATTERY (for RM-P501)
************************************************************
*************
HARDWARE LIST
*************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 TT(B)
#2 7-685-872-09 SCREW +BVTT 3X8 (S)
#3 7-685-881-09 SCREW +BVTT 4X8 (S)
VOLUME
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
Ver 1.1 2001.07
