Sony STR-DH730 - Page 59

STR-DH730/DH830
59
Pin No. Pin Name I/O Description
170, 171
VID_DATA_IN_12,
VID_DATA_IN_13
-
Not Used
172 RVDD_33
-
Power supply terminal (+3.3V)
173, 174
VID_DATA_IN_14,
VID_DATA_IN_15
-
Not Used
175 RVSS
-
Not Used
176 to
178
GPIO30 to GPIO32
-
Not Used
179 VDD_HP_33
-
Power supply terminal (+3.3V)
180 AUD_HP_OUT_L
-
Not Used
181 AUD_HP_OUT_R
-
Not Used
182 GND_HP
-
Ground terminal
183 AUD_OUT2_L
-
Not Used
184 AUD_OUT2_R
-
Not Used
185 AUD_OUT1_L
-
Not Used
186 AUD_OUT1_R
-
Not Used
187 VDD_AUD1_33
-
Power supply terminal (+3.3V)
188 LS_OUT_L
-
Not Used
189 LS_OUT_R
-
Not Used
190 LS_OUT_SW
-
Not Used
191 GND_AUD1
-
Ground terminal
192 VREFN
-
Ground terminal
193 VREFM
-
Not Used
194 VREFP
-
Not Used
195 VDD_AUD2_33
-
Power supply terminal (+3.3V)
196 AUD_IN_L4
-
Not Used
197 AUD_IN_R4
-
Not Used
198 AUD_IN_L3
-
Not Used
199 AUD_IN_R3
-
Not Used
200 AUD_IN_L2
-
Not Used
201 AUD_IN_R2
-
Not Used
202 AUD_IN_L1
-
Not Used
203 AUD_IN_R1
-
Not Used
204 AUD_MONO_IN
-
Not Used
205 GND_AUD2
-
Not Used
206 VDD_AUD_18
-
Power supply terminal (+1.8V)
207 GND_AUD_18
-
Ground terminal
208 VDD18_ABC_SC
-
Power supply terminal (+1.8V)
209 GND18_ABC_SC
-
Ground terminal
210 VDDA
-
Power supply terminal (+3.3V)
211 SIF_IN2
-
Not Used
212
GNDA
-
Ground terminal
213 SIF_RTN
-
Not Used
214 GNDA
-
Ground terminal
215 SIF_IN1
-
Not Used
216 VDDA
-
Power supply terminal (+3.3V)
217 SV1P
-
Not Used
218 VDDA
-
Power supply terminal (+3.3V)
219 A1P I Component video signal input from the video amplifi er
220 GNDA
-
Ground terminal
221 B1P I Component video signal input from the video amplifi er
222 GNDA
-
Ground terminal
223 C1P I Component video signal input from the video amplifi er
224 GNDA
-
Ground terminal
225 AN
-
Not Used
226 GNDA
-
Ground terminal
