STR-DH730/DH830
SECTION 7
ELECTRICAL PARTS LIST
A-1846-097-A DISPLAY BOARD, COMPLETE
***********************
< CAPACITOR >
C101 1-126-964-11 ELECT 10uF 20% 50V
C102 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C103 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C104 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C105 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C106 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C107 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C108 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C116 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C120 1-126-966-11 ELECT 33uF 20% 50V
C121 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C122 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C123 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C124 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C125 1-126-947-11 ELECT 47uF 20% 35V
C127 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C128 1-114-811-11 CERAMIC CHIP 0.0033uF 10% 50V
C129 1-114-811-11 CERAMIC CHIP 0.0033uF 10% 50V
C130 1-114-811-11 CERAMIC CHIP 0.0033uF 10% 50V
C131 1-114-811-11 CERAMIC CHIP 0.0033uF 10% 50V
C132 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C134 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C135 1-164-733-11 CERAMIC CHIP 820PF 10% 50V
C137 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C138 1-164-733-11 CERAMIC CHIP 820PF 10% 50V
C139 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C140 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C141 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
< CONNECTOR >
CN104 1-779-293-11 CONNECTOR, FFC (LIF (NON-ZIF)) 25P
< DIODE >
D100 6-503-015-01 DI DZ2J051M0L
D101 6-500-848-01 DIODE MC2840-T112-1
D102 6-500-848-01 DIODE MC2840-T112-1
D104 8-719-049-09 DIODE 1SS367-T3SONY
D105 8-719-049-09 DIODE 1SS367-T3SONY
D106 8-719-049-09 DIODE 1SS367-T3SONY
D107 8-719-049-09 DIODE 1SS367-T3SONY
D108 8-719-053-18 DIODE 1SR154-400TE-25
< FUSE >
F100 1-523-132-31 FUSE 1A 50V
< FERRITE BEAD >
FB100 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC100 6-701-729-01 IC PT6315
IC101 6-600-768-01 IC PNA4823M03S0
IC102 8-759-710-97 IC NJM4565M-D
< JACK >
J100 1-819-189-11 PIN JACK 3P (VIDEO 2 IN)
< JUMPER RESISTOR >
JR100 1-216-864-11 SHORT CHIP 0
JR101 1-216-296-11 SHORT CHIP 0
JR102 1-216-864-11 SHORT CHIP 0
JR103 1-216-864-11 SHORT CHIP 0
JR104 1-216-296-11 SHORT CHIP 0
JR105 1-216-864-11 SHORT CHIP 0
JR106 1-216-864-11 SHORT CHIP 0
JR107 1-216-864-11 SHORT CHIP 0
JR108 1-216-864-11 SHORT CHIP 0
JR109 1-211-950-11 SHORT CHIP 0
JR110 1-216-864-11 SHORT CHIP 0
JR111 1-216-864-11 SHORT CHIP 0
JR112 1-216-864-11 SHORT CHIP 0
JR113 1-216-864-11 SHORT CHIP 0
JR114 1-216-864-11 SHORT CHIP 0
JR115 1-216-864-11 SHORT CHIP 0
JR116 1-216-864-11 SHORT CHIP 0
JR117 1-216-296-11 SHORT CHIP 0
JR118 1-216-296-11 SHORT CHIP 0
JR119 1-216-296-11 SHORT CHIP 0
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• Items marked “
*
” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AUS : Australian model
CND : Canadian model
ECE : Continental European, East
European and Russian models
The components identified by mark
0
or dotted line with mark
0
are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifi é.
The components identifi ed by mark
9
con-
tain confi dential information.
Strictly follow the instructions whenever
the components are repaired and/or re-
placed.
Les composants identifi és par la marque
9
contiennent des informations confi denti-
elles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est rem-
placé et / ou réparé.
DISPLAY
To Next Page
