STR-DH730/DH830
64
Pin No. Pin Name I/O Description
56 NC - Not Used
57 V
DD_EXT
- Power supply pin (+3.3 V)
58 NC - Not Used
59 NC - Not Used
60 NC - Not Used
61 NC - Not Used
62 V
DD_INT
- Power supply pin (+1.2 V)
63 NC - Not Used
64 NC - Not Used
65 V
DD_INT
- Power supply pin (+1.2 V)
66 NC - Not Used
67 NC - Not Used
68 V
DD_INT
- Power supply pin (+1.2 V)
69 NC - Not Used
70
WDTRSTO O Watch dog timer reset out
71 NC - Not Used
72 V
DD_EXT
- Power supply pin (+3.3 V)
73 DAI_P07 O PCM audio signal output
74 DAI_P13 I PCM audio signal input
75 DAI_P19 I Bit clock (2.8224 MHz) signal input from PCM audio signal input
76 DAI_P01 I/O Digital applications interface
77 DAI_P02 I/O Digital applications interface
78 V
DD_INT
- Power supply pin (+1.2 V)
79 NC - Not Used
80 NC - Not Used
81 NC - Not Used
82 NC - Not Used
83 NC - Not Used
84 V
DD_EXT
- Power supply pin (+3.3 V)
85 V
DD_INT
- Power supply pin (+1.2 V)
86 DAI_P06 O PCM audio signal output
87 DAI_P05 - Not Used (Open)
88 DAI_P09 I/O Digital applications interface
89 DAI_P10 - Not Used (Open)
90 V
DD_INT
- Power supply pin (+1.2 V)
91 V
DD_EXT
- Power supply pin (+3.3 V)
92 DAI_P20 I Master clock signal input
93 V
DD_INT
- Power supply pin (+1.2 V)
94 DAI_P08 I/O Digital applications interface
95 DAI_P14 I PCM audio signal input
96 DAI_P04 - Not Used (Open)
97 DAI_P18 I L/R sampling clock (44.1 kHz) signal input from PCM audio signal input
98 DAI_P17 O Bit clock (2.8224 MHz) signal output for PCM audio signal output
99 DAI_P16 O L/R sampling clock (44.1 kHz) signal output for PCM audio signal output
100 DAI_P12 I PCM audio signal input from the A/D converter
101 DAI_P15 I PCM audio signal input
102 V
DD_INT
- Power supply pin (+1.2 V)
103 DAI_P11 I PCM audio signal (digital input) input
104 V
DD_EXT
- Power supply pin (+3.3 V)
105 V
DD_INT
- Power supply pin (+1.2 V)
106 BOOT_CFG2 I Boot confi guration select
107 V
DD_INT
- Power supply pin (+1.2 V)
108 AMI_ACK I Memory acknowledge
109 GND - Ground
110 THD_M O Thermal diode cathode
111 THD_P I Thermal diode anode
