STR-DH730/DH830
66
Pin No. Pin Name I/O Description
168 DATA13 I/O External data
169 V
DD_INT
- Power supply pin (+1.2 V)
170 DATA15 I/O External data
171
SDWE O SDRAM write enable
172
SDRAS O SDRAM row address strobe
173
RESET I System reset signal input from SYSTEM CONTROL IC
174 TMS - Not Used (Fixed at L)
175
SDCAS O SDRAM column address select
176 V
DD_INT
- Power supply pin (+1.2 V)
