Sony STR-DH730 - D-VIDEO Board Components

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DH730/DH830
7777
R2825 1-218-933-11 METAL CHIP 22 5% 1/16W
R2826 1-218-933-11 METAL CHIP 22 5% 1/16W
R2829 1-218-945-11 METAL CHIP 220 5% 1/16W
R2831 1-218-945-11 METAL CHIP 220 5% 1/16W
R2834 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2835 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2837 1-218-933-11 METAL CHIP 22 5% 1/16W
R2838 1-218-933-11 METAL CHIP 22 5% 1/16W
R2839 1-218-933-11 METAL CHIP 22 5% 1/16W
R2840 1-218-933-11 METAL CHIP 22 5% 1/16W
R2841 1-218-945-11 METAL CHIP 220 5% 1/16W
R2842 1-218-933-11 METAL CHIP 22 5% 1/16W
R2843 1-218-933-11 METAL CHIP 22 5% 1/16W
R2844 1-218-933-11 METAL CHIP 22 5% 1/16W
R2846 1-218-933-11 METAL CHIP 22 5% 1/16W
R2847 1-218-947-11 METAL CHIP 330 5% 1/16W
R2849 1-218-947-11 METAL CHIP 330 5% 1/16W
R2850 1-218-933-11 METAL CHIP 22 5% 1/16W
R2851 1-218-933-11 METAL CHIP 22 5% 1/16W
R2852 1-218-933-11 METAL CHIP 22 5% 1/16W
R2853 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R2854 1-218-990-81 SHORT CHIP 0
R2855 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R2856 1-218-989-11 METAL CHIP 1M 5% 1/16W
R2857 1-218-941-81 METAL CHIP 100 5% 1/16W
R2858 1-218-941-81 METAL CHIP 100 5% 1/16W
R2860 1-208-675-11 METAL CHIP 470 0.5% 1/16W
R2861 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2863 1-218-933-11 METAL CHIP 22 5% 1/16W
R2864 1-218-933-11 METAL CHIP 22 5% 1/16W
R2865 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2866 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2867 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2868 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R2872 1-218-933-11 METAL CHIP 22 5% 1/16W
R2873 1-218-933-11 METAL CHIP 22 5% 1/16W
R2875 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2876 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2878 1-218-933-11 METAL CHIP 22 5% 1/16W
R2879 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2880 1-218-933-11 METAL CHIP 22 5% 1/16W
R2881 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R2882 1-218-933-11 METAL CHIP 22 5% 1/16W
R2886 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R2889 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R2891 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2892 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2895 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2897 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2898 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2899 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2901 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2906 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2910 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2914 1-218-949-11 METAL CHIP 470 5% 1/16W
R2915 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2917 1-218-941-81 METAL CHIP 100 5% 1/16W
R2918 1-218-941-81 METAL CHIP 100 5% 1/16W
R2919 1-218-941-81 METAL CHIP 100 5% 1/16W
R2920 1-218-941-81 METAL CHIP 100 5% 1/16W
R2921 1-218-941-81 METAL CHIP 100 5% 1/16W
R2923 1-218-941-81 METAL CHIP 100 5% 1/16W
R2925 1-218-937-11 METAL CHIP 47 5% 1/16W
R2928 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R2929 1-218-941-81 METAL CHIP 100 5% 1/16W
R2930 1-216-890-11 METAL CHIP 100 5% 1/10W
R2931 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2932 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2933 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2939 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2940 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2941 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R2946 1-218-990-81 SHORT CHIP 0
R2947 1-218-990-81 SHORT CHIP 0
R2948 1-218-990-81 SHORT CHIP 0
R2949 1-218-990-81 SHORT CHIP 0
R2951 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2952 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2953 1-218-941-81 METAL CHIP 100 5% 1/16W
R2957 1-218-941-81 METAL CHIP 100 5% 1/16W
R2958 1-218-941-81 METAL CHIP 100 5% 1/16W
R2959 1-218-941-81 METAL CHIP 100 5% 1/16W
R2960 1-218-941-81 METAL CHIP 100 5% 1/16W
R2969 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2971 1-216-864-11 SHORT CHIP 0
R2972 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R2973 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB2102 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2103 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2104 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2105 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2106 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2107 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2109 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2119 1-234-372-11 RES, NETWORK 100 (1005X4)
< VIBRATOR >
X2101 1-781-646-21 VIBRATOR, CERAMIC
X2800 1-814-242-11 VIBRATOR, CRYSTAL 25MHZ
X2801 1-814-350-11 QUARTZ CRYSTAL UNITS
************************************************************
9 A-1842-612-A D-VIDEO BOARD, COMPLETE (for SERVICE)
***********************
< CAPACITOR >
C1500 1-112-796-11 ELECT CHIP 47uF 20% 25V
C1501 1-112-796-11 ELECT CHIP 47uF 20% 25V
C1502 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C1503 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C1510 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1511 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1512 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C1513 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C1514 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1515 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C1517 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C1519 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1520 1-128-396-11 ELECT CHIP 470uF 20% 10V
D-VIDEODIGITAL
