Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DH730/DH830
8585
D720 6-502-961-01 DI DA2J10100L
D761 6-502-961-01 DI DA2J10100L
D770 6-502-961-01 DI DA2J10100L
D811 6-502-961-01 DI DA2J10100L
D820 6-502-961-01 DI DA2J10100L
D861 6-502-961-01 DI DA2J10100L
D870 6-502-961-01 DI DA2J10100L
D910 8-719-053-18 DIODE 1SR154-400TE-25
D911 8-719-053-18 DIODE 1SR154-400TE-25
D912 8-719-053-18 DIODE 1SR154-400TE-25
D913 8-719-053-18 DIODE 1SR154-400TE-25
D920 6-502-961-01 DI DA2J10100L
D921 8-719-061-07 DIODE D5SBA60-F
< EARTH TERMINAL >
ET300 1-537-738-21 TERMINAL, GROUND
< FUSE >
0 F910 1-523-085-11 FUSE 2.5A 250V
0 F911 1-523-085-11 FUSE 2.5A 250V
0 F912 1-523-080-11 FUSE 6.3A 250V
0 F913 1-523-080-11 FUSE 6.3A 250V
< IC >
IC350 6-712-294-01 IC KIA7807API-U/PF
IC352 6-712-295-01 IC KIA7907PI
IC400 6-716-394-01 IC BD3470KS2
IC501 6-715-582-01 IC STK350-630TS-E
IC601 6-715-582-01 IC STK350-630TS-E
IC701 6-715-582-01 IC STK350-630TS-E
IC801 6-715-582-01 IC STK350-630TS-E
< JACK >
J401 1-774-411-11 JACK, PIN 6P (SAT/CATV AUDIO IN, VIDEO1
AUDIO IN, VIDEO1 AUDIO OUT)
J405 1-774-785-11 JACK, PIN 1P (SUBWOOFER AUDIO OUT)
J409 1-794-981-11 JACK, PIN 4P
(TV AUDIO IN, SA-CD/CD AUDIO IN)
< JUMPER RESISTOR >
JR601 1-216-864-11 SHORT CHIP 0
JR602 1-216-864-11 SHORT CHIP 0
JR603 1-216-296-11 SHORT CHIP 0
JR604 1-216-864-11 SHORT CHIP 0
JR605 1-216-864-11 SHORT CHIP 0
JR606 1-216-296-11 SHORT CHIP 0
JR607 1-216-296-11 SHORT CHIP 0
JR608 1-216-864-11 SHORT CHIP 0
JR609 1-216-864-11 SHORT CHIP 0
JR700 1-216-864-11 SHORT CHIP 0
JR701 1-216-864-11 SHORT CHIP 0
JR706 1-216-864-11 SHORT CHIP 0
JR707 1-216-296-11 SHORT CHIP 0
< COIL >
* L489 1-400-973-21 INDUCTOR (EMI FERRITE)
* L499 1-400-973-21 INDUCTOR (EMI FERRITE)
L550 1-420-872-52 COIL, AIR-CORE
L560 1-216-295-91 SHORT CHIP 0
L561 1-216-295-91 SHORT CHIP 0
L601 1-216-295-91 SHORT CHIP 0
L602 1-216-295-91 SHORT CHIP 0
L628 1-420-872-52 COIL, AIR-CORE
L651 1-216-295-91 SHORT CHIP 0
L652 1-216-295-91 SHORT CHIP 0
L678 1-420-872-52 COIL, AIR-CORE
* L701 1-400-973-21 INDUCTOR (EMI FERRITE)
* L702 1-400-973-21 INDUCTOR (EMI FERRITE)
L728 1-420-872-52 COIL, AIR-CORE
* L751 1-400-973-21 INDUCTOR (EMI FERRITE)
* L752 1-400-973-21 INDUCTOR (EMI FERRITE)
L778 1-420-872-52 COIL, AIR-CORE
L801 1-216-295-91 SHORT CHIP 0
L802 1-216-295-91 SHORT CHIP 0
L828 1-420-872-52 COIL, AIR-CORE
L851 1-216-295-91 SHORT CHIP 0
L852 1-216-295-91 SHORT CHIP 0
L878 1-420-872-52 COIL, AIR-CORE
< TRANSISTOR >
Q301 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q320 6-550-327-01 TR 2SA1514KT146S
Q321 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q323 6-550-327-01 TR 2SA1514KT146S
Q324 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q325 8-729-271-31 TRANSISTOR 2SC2713-G
Q350 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q355 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q360 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q365 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q375 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q550 6-550-327-01 TR 2SA1514KT146S
Q551 8-729-216-22 TRANSISTOR 2SA1162-G
Q552 8-729-922-39 TRANSISTOR 2SD2144S-V
Q555 6-550-327-01 TR 2SA1514KT146S
Q601 8-729-216-22 TRANSISTOR 2SA1162-G
Q602 8-729-922-39 TRANSISTOR 2SD2144S-V
Q611 6-550-327-01 TR 2SA1514KT146S
Q612 6-550-327-01 TR 2SA1514KT146S
Q651 8-729-216-22 TRANSISTOR 2SA1162-G
Q652 8-729-922-39 TRANSISTOR 2SD2144S-V
Q661 6-550-327-01 TR 2SA1514KT146S
Q662 6-550-327-01 TR 2SA1514KT146S
Q701 8-729-216-22 TRANSISTOR 2SA1162-G
Q702 8-729-922-39 TRANSISTOR 2SD2144S-V
Q711 6-550-327-01 TR 2SA1514KT146S
Q712 6-550-327-01 TR 2SA1514KT146S
Q751 8-729-216-22 TRANSISTOR 2SA1162-G
Q752 8-729-922-39 TRANSISTOR 2SD2144S-V
Q761 6-550-327-01 TR 2SA1514KT146S
Q762 6-550-327-01 TR 2SA1514KT146S
Q801 8-729-216-22 TRANSISTOR 2SA1162-G
Q802 8-729-922-39 TRANSISTOR 2SD2144S-V
Q811 6-550-327-01 TR 2SA1514KT146S
Q812 6-550-327-01 TR 2SA1514KT146S
Q851 8-729-216-22 TRANSISTOR 2SA1162-G
Q852 8-729-922-39 TRANSISTOR 2SD2144S-V
Q861 6-550-327-01 TR 2SA1514KT146S
Q862 6-550-327-01 TR 2SA1514KT146S
Q920 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
MAIN
