Sony STR-DH730 - Tuner1 and USB Board Components

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DH730/DH830
90
< FILTER >
FL101 1-236-711-21 FILTER, BAND PASS
< IC >
IC101 6-717-980-01 IC RZ5B801-0001E2 (CND, US)
IC101 6-717-981-01 IC RZ5B801-0002E2 (AUS, ECE)
IC102 6-715-134-01 IC MM3404A33URE
< JUMPER RESISTOR >
JR101 1-216-864-11 SHORT CHIP 0
JR102 1-216-296-11 SHORT CHIP 0
JR105 1-216-296-11 SHORT CHIP 0
JR106 1-216-864-11 SHORT CHIP 0
JR109 1-216-296-11 SHORT CHIP 0
JR112 1-216-296-11 SHORT CHIP 0
< COIL >
L101 1-457-998-11 COIL, AM ANTENNA
L103 1-414-576-41 INDUCTOR 47nH
L104 1-481-330-21 INDUCTOR 220nH
L105 1-481-523-11 INDUCTOR 4.7uH
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R103 1-216-801-11 METAL CHIP 22 5% 1/10W
R104 1-216-864-11 SHORT CHIP 0
R105 1-216-801-11 METAL CHIP 22 5% 1/10W
R106 1-216-809-11 METAL CHIP 100 5% 1/10W
R107 1-216-809-11 METAL CHIP 100 5% 1/10W
R108 1-216-296-11 SHORT CHIP 0
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-833-11 METAL CHIP 10K 5% 1/10W
R113 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X101 1-767-317-11 VIBRATOR, CRYSTAL
*************************************************************
A-1849-982-A USB BOARD, COMPLETE
********************
< CAPACITOR >
C4101 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4102 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C4109 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4110 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4111 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4112 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4113 1-164-847-11 CERAMIC CHIP 7PF 0.5PF 50V
C4114 1-164-847-11 CERAMIC CHIP 7PF 0.5PF 50V
C4115 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4116 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4117 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4118 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4119 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C4120 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C4121 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4127 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C4128 1-135-177-21 TANTAL. CHIP 1uF 10% 25V
C4129 1-124-779-00 ELECT CHIP 10uF 20% 16V
C4130 1-128-993-21 ELECT CHIP 22uF 20% 10V
C4131 1-164-862-81 CERAMIC CHIP 33PF 5% 50V
C4132 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4133 1-164-862-81 CERAMIC CHIP 33PF 5% 50V
C4134 1-128-993-21 ELECT CHIP 22uF 20% 10V
C4135 1-135-177-21 TANTAL. CHIP 1uF 10% 25V
C4136 1-128-994-21 ELECT CHIP 47uF 20% 10V
C4137 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C4138 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C4155 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C4156 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4157 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
C4158 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4159 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C4161 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4162 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C4163 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4164 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C4165 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C4166 1-128-390-11 ELECT CHIP 220uF 20% 6.3V
C4167 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4168 1-128-394-11 ELECT CHIP 220uF 20% 10V
C4169 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4181 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C4182 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C4183 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C4184 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C4185 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4186 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN4101 1-573-290-21 PIN, CONNECTOR (1.5MM) (SMD) 4P
< DIODE >
D4101 6-502-967-01 DI DZ2J06200L
D4102 6-502-967-01 DI DZ2J06200L
D4103 6-502-967-01 DI DZ2J06200L
D4104 6-500-848-01 DIODE MC2840-T112-1
D4105 6-500-848-01 DIODE MC2840-T112-1
D4121 6-502-961-01 DI DA2J10100L
D4160 6-502-961-01 DI DA2J10100L
D4161 8-719-049-09 DIODE 1SS367-T3SONY
D4162 8-719-049-09 DIODE 1SS367-T3SONY
VD4120 1-811-155-11 ELEMENT, ESD PROTECT
VD4121 1-811-155-11 ELEMENT, ESD PROTECT
VD4170 1-811-155-11 ELEMENT, ESD PROTECT
VD4171 1-811-155-11 ELEMENT, ESD PROTECT
< EARTH TERMINAL >
* ET4100 1-780-408-11 TERMINAL, LUG
< FERRITE BEAD >
FB4100 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB4101 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB4102 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB4161 1-481-218-21 FERRITE, EMI (SMD) (1608)
USBTUNER1
