MULTI CHANNEL AV RECEIVER

STR-DN1050/STR-DN850

Connecting devices with HDMI jacks

Connect devices to the receiver as illustrated below.

Before connecting cables, be sure to disconnect the AC power cord (mains lead).

If your device does not have an HDMI jack, see “Connecting devices with jacks other than HDMI jacks (for STR-

DN1050)” or “Connecting devices with jacks other than HDMI jacks (for STR-DN850).”

HDMI cable (not supplied)

Sony recommends that you use an HDMI-authorized cable or Sony HDMI cable.

Satellite tuner, cable TV tuner

PlayStation3

DVD recorder

Super Audio CD player, CD player

Blu-ray Disc player, DVD player
