MULTI CHANNEL AV RECEIVER

STR-DN1050/STR-DN850

Front panel (STR-DN1050)

1. (on/standby)

2. SPEAKERS

3. CONNECTION PAIRING BLUETOOTH

Operates the BLUETOOTH function.

4. TUNER PRESET +/–

5. NFC sensor

6. A.F.D./2CH, MOVIE, MUSIC

7. Display panel

8. DISPLAY

9. ZONE CONTROL, ZONE POWER

10. DIMMER

Adjusts the brightness of the display panel in 3 levels.

11. Remote control sensor

Receives signals from remote control.

12. PURE DIRECT

The indicator above the button lights up when the Pure Direct function is activated.

13. MASTER VOLUME

14. INPUT SELECTOR

15. HDMI/MHL (VIDEO 2 IN) jack

16. (USB) port

17. AUTO CAL MIC jack
