MULTI CHANNEL AV RECEIVER

STR-DN1050/STR-DN850

A test tone is output from a different speaker than the speaker displayed on the TV screen.

The speaker pattern setup is incorrect. Make sure that the speaker connections and the speaker pattern match

correctly.
