No image from an MHL-compatible source device.

Check the settings of your device. For details, refer to the operating instructions of your device.

Check that the device is connected via an MHL cable to the HDMI/MHL (VIDEO 2 IN) (*1), HDMI VIDEO 1 IN (MHL)

(*1) or HDMI VIDEO IN (MHL) (*2) jacks.

For STR-DN1050 only

For STR-DN850 only
