Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
74
STR-KM7600
R738 1-216-841-11 METAL CHIP 47K 5% 1/10W
R739 1-216-845-11 METAL CHIP 100K 5% 1/10W
R740 1-216-845-11 METAL CHIP 100K 5% 1/10W
R741 1-216-845-11 METAL CHIP 100K 5% 1/10W
R742 1-216-845-11 METAL CHIP 100K 5% 1/10W
R743 1-216-845-11 METAL CHIP 100K 5% 1/10W
R744 1-216-845-11 METAL CHIP 100K 5% 1/10W
R745 1-216-845-11 METAL CHIP 100K 5% 1/10W
R746 1-216-833-11 METAL CHIP 10K 5% 1/10W
R747 1-216-077-91 METAL CHIP 15K 5% 1/10W
R748 1-216-079-00 METAL CHIP 18K 5% 1/10W
R749 1-216-835-11 METAL CHIP 15K 5% 1/10W
R750 1-216-835-11 METAL CHIP 15K 5% 1/10W
R751 1-216-835-11 METAL CHIP 15K 5% 1/10W
R752 1-216-845-11 METAL CHIP 100K 5% 1/10W
R753 1-216-845-11 METAL CHIP 100K 5% 1/10W
R754 1-216-845-11 METAL CHIP 100K 5% 1/10W
R755 1-216-843-11 METAL CHIP 68K 5% 1/10W
R756 1-216-864-11 SHORT CHIP 0
RR500 1-249-393-11 CARBON 10 5% 1/4W
RR501 1-249-393-11 CARBON 10 5% 1/4W
RR504 1-249-393-11 CARBON 10 5% 1/4W
RR505 1-249-393-11 CARBON 10 5% 1/4W
RR506 1-249-393-11 CARBON 10 5% 1/4W
RR507 1-249-393-11 CARBON 10 5% 1/4W
RR508 1-249-393-11 CARBON 10 5% 1/4W
< RELAY >
RY406 1-755-593-11 RELAY
RY421 1-755-170-11 RELAY (12V)
RY422 1-755-170-11 RELAY (12V)
RY423 1-755-170-11 RELAY (12V)
RY425 1-755-170-11 RELAY (12V)
RY441 1-755-267-11 RELAY
RY451 1-755-170-11 RELAY (12V)
< TERMINAL >
TB500 1-780-215-11 TERMINAL BOARD (SP) (4P)
(SPEAKERS FRONT)
TB502 1-694-785-11 TERMINAL BOARD (SPEAKERS SURROUND)
TB503 1-694-805-11 TERMINAL BOARD
(SPEAKERS CENTER, SURROUND BACK)
************************************************************
POWER KEY BOARD
****************
< SWITCH >
S110 1-771-410-21 SWITCH, TACTILE (
+/1
)
************************************************************
A-1660-444-A STANDBY DCDC BOARD, COMPLETE
(EXCEPT EA)
A-1660-445-A STANDBY DCDC BOARD, COMPLETE (EA)
*****************************
7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C911 1-130-777-00 MYLAR 0.1uF 5% 100V
C912 1-130-777-00 MYLAR 0.1uF 5% 100V
C914 1-126-942-61 ELECT 1000uF 20% 25V
C917 1-126-941-11 ELECT 470uF 20% 25V
C918 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C919 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C921 1-126-947-11 ELECT 47uF 20% 35V
C923 1-126-936-11 ELECT 3300uF 20% 16V
C924 1-126-960-11 ELECT 1uF 20% 50V
C925 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C926 1-126-942-61 ELECT 1000uF 20% 25V
C927 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C930 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C931 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C932 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C933 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C934 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C971 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C972 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C980 1-128-959-21 ELECT 1000uF 20% 35V
C981 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C982 1-128-950-21 ELECT 1000uF 20% 16V
C990 1-128-959-21 ELECT 1000uF 20% 35V
C991 1-126-944-11 ELECT 3300uF 20% 25V
C992 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C993 1-128-950-21 ELECT 1000uF 20% 16V
C994 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C995 1-126-947-11 ELECT 47uF 20% 35V
C998 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C999 1-126-947-11 ELECT 47uF 20% 35V
< CONNECTOR >
*
CN905 1-564-508-11 PLUG, CONNECTOR 5P
< CONNECTOR >
*
CNP904 1-564-507-11 PLUG, CONNECTOR 4P
0
CNP921 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P (EA)
CNP922 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
*
CNP923 1-565-792-11 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
D903 8-719-061-07 DIODE D5SBA60-F
D911 6-501-361-01 DIODE RB051LA-40TR
D913 8-719-053-18 DIODE 1SR154-400TE-25
D920 6-501-361-01 DIODE RB051LA-40TR
D921 6-501-361-01 DIODE RB051LA-40TR
D922 6-501-361-01 DIODE RB051LA-40TR
D923 6-501-361-01 DIODE RB051LA-40TR
D924 6-501-817-01 DIODE MA2J1110GLS0
D925 6-501-817-01 DIODE MA2J1110GLS0
D926 6-501-361-01 DIODE RB051LA-40TR
D927 6-501-817-01 DIODE MA2J1110GLS0
D980 6-502-218-01 DI RB060M-30TR
D991 6-501-361-01 DIODE RB051LA-40TR
D992 8-719-049-09 DIODE 1SS367-T3SONY
D993 8-719-049-09 DIODE 1SS367-T3SONY
D994 8-719-053-18 DIODE 1SR154-400TE-25
D995 6-501-712-01 DIODE MAZ8030G0LS0
< FUSE >
0
F901 1-523-086-11 FUSE 3.15A 250V
0
F902 1-523-086-11 FUSE 3.15A 250V
MAIN POWER KEY STANDBY DCDC
