Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
7575
STR-KM7600
< FERRITE BEAD >
FB900 1-414-671-22 INDUCTOR, FERRITE BEAD
FB901 1-414-671-22 INDUCTOR, FERRITE BEAD
< HOLDER, FUSE >
FH920 1-533-217-41 HOLDER, FUSE (EXCEPT EA)
FH921 1-533-217-41 HOLDER, FUSE (EXCEPT EA)
< IC >
IC910 6-712-294-01 IC KIA7807API-U/PF
IC911 6-708-737-01 IC KIA78D05PI (EXCEPT EA)
IC980 8-759-474-09 IC SI-8050S-LF1101
IC990 8-759-659-28 IC SI-8033S
IC991 6-713-873-01 IC MM1665ATRE
IC992 6-713-034-01 IC KIA7812API-U/PF
< JACK >
J920 1-820-056-11 SMALL TYPE JACK (SYSTEM CONTROL OUT)
J921 1-820-056-11 SMALL TYPE JACK (SYSTEM CONTROL OUT)
< COIL >
L980 1-456-545-11 INDUCTOR 100uH
L981 1-457-508-21 INDUCTOR 0.1mH
L990 1-456-545-11 INDUCTOR 100uH
L992 1-457-508-21 INDUCTOR 0.1mH
< TRANSISTOR >
Q920 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q921 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q922 8-729-106-60 TRANSISTOR 2SB1115A-YQ
Q923 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R920 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R921 1-216-837-11 METAL CHIP 22K 5% 1/10W
R922 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R923 1-216-841-11 METAL CHIP 47K 5% 1/10W
R924 1-216-837-11 METAL CHIP 22K 5% 1/10W
R925 1-216-841-11 METAL CHIP 47K 5% 1/10W
R926 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R927 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R928 1-216-841-11 METAL CHIP 47K 5% 1/10W
R929 1-249-381-11 CARBON 1 5% 1/4W
R980 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R981 1-216-819-11 METAL CHIP 680 5% 1/10W
R982 1-216-817-11 METAL CHIP 470 5% 1/10W
R990 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R991 1-216-819-11 METAL CHIP 680 5% 1/10W
R992 1-216-817-11 METAL CHIP 470 5% 1/10W
R993 1-216-833-11 METAL CHIP 10K 5% 1/10W
R994 1-215-882-00 METAL OXIDE 22 5% 2W
R995 1-215-882-00 METAL OXIDE 22 5% 2W
< RELAY >
RY920 1-755-541-11 RELAY
< TRANSFORMER >
0
T921 1-437-314-11 TRANSFORMER, POWER (SUB) (EA)
0
T924 1-437-313-11 TRANSFORMER, POWER (SUB) (EXCEPT EA)
************************************************************
THERMAL SENSOR BOARD
**********************
< CAPACITOR >
C250 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C251 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C252 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< DIODE >
D250 6-502-968-01 DI DZ2J062M0L
< IC >
IC250 6-710-072-01 IC LM61CIZ/LFT2
IC251 6-710-072-01 IC LM61CIZ/LFT2
< RESISTOR >
R250 1-216-809-11 METAL CHIP 100 5% 1/10W
************************************************************
A-1701-988-A VIDEO BOARD, COMPLETE
*********************
< CAPACITOR >
C200 1-126-947-11 ELECT 47uF 20% 35V
C201 1-100-385-91 CERAMIC CHIP 0.47uF 25V
C203 1-100-385-91 CERAMIC CHIP 0.47uF 25V
C204 1-126-947-11 ELECT 47uF 20% 35V
C205 1-126-964-11 ELECT 10uF 20% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-126-964-11 ELECT 10uF 20% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C211 1-126-964-11 ELECT 10uF 20% 50V
C212 1-126-964-11 ELECT 10uF 20% 50V
C213 1-126-964-11 ELECT 10uF 20% 50V
C214 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C216 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C218 1-126-964-11 ELECT 10uF 20% 50V
C219 1-126-964-11 ELECT 10uF 20% 50V
C220 1-126-964-11 ELECT 10uF 20% 50V
C222 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C224 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C226 1-126-964-11 ELECT 10uF 20% 50V
C227 1-126-964-11 ELECT 10uF 20% 50V
C228 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN202 1-770-408-11 CONNECTOR, BOARD TO BOARD 14P
*
CNP201 1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D210 6-501-817-01 DIODE MA2J1110GLS0
D211 6-501-817-01 DIODE MA2J1110GLS0
< IC >
IC201 6-711-998-01 IC KIA7905PI
IC202 6-713-031-01 IC KIA7805API-U/PF
STANDBY DCDC
VIDEO
THERMAL SENSOR
