66
Function Setting Menu
Chapter 3 Menu
Function Switch
V Delay Sets whether or not to display in V delay ([Off] or On).
Note
The picture is not displayed in V delay in the following cases:
• When the input signal has no sync signal
• When the internal signal is displayed
• When Format of the Channel Configuration menu is set to HDMI or DisplayPort
• When Side by Side, Wipe, Butterfly or Blending is set to On
• When the captured frame is displayed
External Sync Sets whether or not to select external sync mode ([Off] or On) when the analog component
signal or analog RGB signal format is input.
When On is selected, the signal to be displayed is synchronized with the sync signal input to
the SYNC connector (External Sync).
When Off is selected, the signal to be displayed is synchronized with the sync signal included
in the signals being monitored (Internal Sync).
Notes
• When Component is set to YPbPr or RGB in Format of the Channel Configuration menu,
you can set the external sync.
• The external sync is not set in the following cases:
– When the internal signal is displayed
– When the captured frame is displayed
Comb Sets whether or not to use the comb filter (Off or [On]).
When Off is selected, the trap · band-pass filter (Trap/BPF) is selected.
You can select the type of comb filter in NTSC Comb Filter menu (page 58) of the Auxiliary
Setting menu.
Notes
• When Composite is set to Auto, NTSC, PAL or PAL-M in Format of the Channel
Configuration menu, you can set the comb filter.
• The comb filter is not set in the following cases:
– When the internal signal is displayed
– When the captured frame is displayed
Aperture Sets whether or not to function the aperture modification (Off or On).
[Off] (when the signal is displayed in Aspect Correction mode of the native display), [On]
(when the signal is displayed in mode other than Aspect Correction of the native display)
Note
When the HDMI/DisplayPort computer signal is input, the aperture modification does not
function.
Mono Sets whether or not to display in monochrome mode ([Off] or On).
Blue Only Sets whether or not to display only the blue signal as a monochrome picture after cutting the
red and green signals ([Off] or On).
R Off Sets whether or not to cut the red signal ([Off] or On).
G Off Sets whether or not to cut the green signal ([Off] or On).
B Off Sets whether or not to cut the blue signal ([Off] or On).
Chroma Up Sets whether or not to increase the chroma value by 12 dB ([Off] or On).
Note
The chroma value is not increased in the following cases:
• When the signal to be displayed is RGB or XYZ
• When the composite signal is automatically displayed in monochrome depending on the
color discrimination of the input adaptor
• When the internal signal is displayed
Interlace Sets whether or not to display in interlace mode ([Off] or On).
Notes
• Set Native Scan to On for the interlace display.
• The picture is not displayed in interlace mode in the following cases:
– When Side by Side, Wipe, Butterfly or Blending is set to On
– When Pixel Zoom is set to on
For details of this menu, see “Selecting Display Mode” on page 87.
Menu Function and operation ([ ]: factory setting)
To Next Page
