40
Menus
Using the Setup Menu
Caption
Vision
Closed-
Captioning
Allows you to select from three closed caption modes for programs that are
broadcast with closed captioning.
Use the
F or f
buttons
to highlight one of the following options, then press
to select it.
Off:
Caption Vision is not activated.
CC1, 2, 3, 4:
Displays printed dialogue and sound effects of a program.
Text1, 2, 3, 4:
Displays network/station information.
Info Banner Displays the name of the current program and its remaining time (if
available) when you change the channel or press the DISPLAY button. Use
the
F or f buttons to highlight one of the following options: On, Off. Then
press .
Video Label
Label
connected
equipment
Allows you to identify the video components connected to the TV: VHS,
DVD, etc. When you press TV/VIDEO to switch inputs, the Video Label
appears on-screen.
1 Press the
F or f
buttons
to highlight the input you want to label and
press .
2 Press the
F or f
buttons
to highlight a label and press .
3
Press G to
return to the Setup menu or press
to exit.
Tilt
Correction
Use the
F or f buttons to set the tilt of the picture from –5 to +5, then press
to activate.
Language Display all menus in the language of your choice.
Use the
F or f buttons to select from one of the following options: English,
Español (Spanish) and Français (French). Then press .
16:9
Enhanced
Provides enhanced picture resolution for wide-screen sources such as DVD.
This is only available when the TV is in Video mode.
Caption Vision
:
Off
16:9 Enhancement : Off
Video Label
Info Banner : Off
Language
:
English
Setup
Tilt Correction
Move
Select
End
To access the Setup menu, use the following steps:
To Display To Highlight To Select
Press f to highlight an option; then press .
To Next Page
