59
KV-27FA310/27FS120/29FA310/29FS120
KV-27FA310/27FS120/29FA310/29FS120
*
Items marked with an asterisk are not stocked since they
are seldom required for routine service. Expect some delay
when ordering these components.
RESISTORS
• All resistors are in ohms
• F : nonfl ammable
• All variable and adjustable resistors
have characteristic curve B, unless
otherwise noted.
REF. NO. PART NO. DESCRIPTION VALUES
The components in this manual identifi ed by the following
symbol:
indicate parts that have been carefully factory-
selected to satisfy regulations regarding X-ray radiation
for each set.
Should replacement be required for one of these
components, replace only with the value originally used.
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et
une marque
!
sont critiques pour la securite.
Ne les remplacer que par une piece portant le
numero specifi e.
When ordering parts by reference
number, please include the board name.
A
REF. NO. PART NO. DESCRIPTION VALUES
* A-1052-931-A A BOARD, COMPLETE
(KV-29FS120LS ONLY)
* A-1302-880-A A BOARD, COMPLETE
(KV-27FA310/29FA310LN ONLY)
* A-1302-954-A A BOARD, COMPLETE
(KV-29FA310LS ONLY)
* A-1302-967-A A BOARD, COMPLETE
(KV-27FS120/29FS120LN ONLY)
!
1-533-223-11 FUSE HOLDER 0A 0V
* 4-374-846-11 COVER, CAPACITOR, CAP TYPE
4-382-854-11 SCREW (M3X10), P, SW (+)
The high-voltage leads associated with the FBT on the A board are not included and
must be ordered separately. Order the following leads when requesting this A Board:
!
1-251-374-14 CAP ASSY, HIGH-VOLTAGE
!
1-900-803-22 WIRE ASSY, G2 LEAD
!
1-900-800-65 CONNECTOR ASSY, FOCUS LEAD
CAPACITOR
C003 1-162-919-11 CERAMIC CHIP 22pF 5% 50V
C004 1-162-923-11 CERAMIC CHIP 47pF 5% 50V
C005 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C006 1-126-942-61 ELECT 1000µF 20% 25V
C007 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
C008 1-126-956-91 ELECT 0.1µF 20% 50V
C009 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C010 1-126-960-11 ELECT 1µF 20% 50V
C011 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C012 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C014 1-126-960-11 ELECT 1µF 20% 50V
C015 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C019 1-126-956-91 ELECT 0.1µF 20% 50V
C021 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C022 1-126-964-11 ELECT 10µF 20% 50V
C023 1-126-935-11 ELECT 470µF 20% 16V
C033 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C041 1-126-964-11 ELECT 10µF 20% 50V
C047 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
C048 1-104-665-11 ELECT 100µF 20% 25V
C049 1-126-960-11 ELECT 1µF 20% 50V
C051 1-126-964-11 ELECT 10µF 20% 50V
C052 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C053 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
C054 1-126-960-11 ELECT 1µF 20% 50V
C056 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C057 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C064 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
C074 1-126-964-11 ELECT 10µF 20% 50V
C075 1-126-935-11 ELECT 470µF 20% 16V
C076 1-104-665-11 ELECT 100µF 20% 25V
C077 1-126-947-11 ELECT 47µF 20% 35V
C079 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C080 1-128-934-91 CERAMIC CHIP 0.33µF 20% 10V
C081 1-128-934-91 CERAMIC CHIP 0.33µF 20% 10V
C090 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C091 1-126-947-11 ELECT 47µF 20% 35V
C092 1-126-947-11 ELECT 47µF 20% 35V
C094 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C095 1-126-947-11 ELECT 47µF 20% 35V
C096 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C097 1-126-947-11 ELECT 47µF 20% 35V
C098 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C099 1-126-947-11 ELECT 47µF 20% 35V
C100 1-126-956-91 ELECT 0.1µF 20% 50V
C115 1-164-739-11 CERAMIC CHIP 560pF 5% 50V
C116 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C200 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C202 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C203 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
SECTION 7: ELECTRICAL PARTS LIST
A
