KV-27FA310/27FS120/29FA310/29FS120
KV-27FA310/27FS120/29FA310/29FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
R615 1-202-933-61 FUSIBLE 0.1 10% 1/2W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R616 1-216-821-11 METAL CHIP 1K 5% 1/10W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R617 1-216-821-11 METAL CHIP 1K 5% 1/10W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R619 1-249-389-11 CARBON 4.7 5% 1/4W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R620 1-216-353-00 METAL OXIDE 2.2 5% 1W
R625 1-249-413-11 CARBON 470 5% 1/4W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R626 1-218-716-11 METAL CHIP 10K 0.50% 1/10W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R627 1-215-481-00 METAL 330K 1% 1/4W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R628 1-260-131-11 CEMENTED 470K 5% 1/2W
(KV-29FS120LS/29FA310LS ONLY)
R629 1-215-481-00 METAL 330K 1% 1/4W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R630 1-215-481-00 METAL 330K 1% 1/4W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R631 1-218-718-11 METAL CHIP 12K 0.50% 1/10W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R632 1-216-809-11 METAL CHIP 100 5% 1/10W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R634 1-215-905-11 METAL OXIDE 10 5% 3W
R640 1-249-417-11 CARBON 1K 5% 1/4W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R641 1-202-968-11 CEMENTED 1.2 5% 10W
(KV-29FS120LS/29FA310LS ONLY)
R641 1-240-262-11 CEMENTED 0.68 5% 10W
(KV-27FS120/29FA310LN/29FS120LN ONLY)
R647 1-216-811-11 METAL CHIP 150 5% 1/10W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R650 1-249-415-11 CARBON 680 5% 1/4W
R651 1-249-441-11 CARBON 100K 5% 1/4W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R652 1-249-441-11 CARBON 100K 5% 1/4W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R658 1-249-393-11 CARBON 10 5% 1/4W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R659 1-249-393-11 CARBON 10 5% 1/4W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R660 1-216-833-11 METAL CHIP 10K 5% 1/10W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R667 1-216-833-11 METAL CHIP 10K 5% 1/10W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R668 1-249-418-11 CARBON 1.2K 5% 1/4W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R670 1-216-833-11 METAL CHIP 10K 5% 1/10W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R671 1-243-979-71 METAL OXIDE 0.1 5% 2W
(KV-27FS120/29FS120LN/29FS120LS ONLY)
R680 1-216-864-11 SHORT CHIP
R687 1-202-968-11 CEMENTED 1.2 5% 10W
(KV-29FS120LS/29FA310LS ONLY)
R687 1-240-262-11 CEMENTED 0.68 5% 10W
(KV-27FS120/29FA310LN/29FS120LN ONLY)
!
R699 1-218-265-11 METAL CHIP 8.2M 5% 1W
(KV-29FS120LS/29FA310LS ONLY)
R801 1-218-716-11 METAL CHIP 10K 0.50% 1/10W
R802 1-218-714-11 METAL CHIP 8.2K 0.50% 1/10W
R803 1-218-719-11 METAL CHIP 13K 0.50% 1/10W
R812 1-218-716-11 METAL CHIP 10K 0.50% 1/10W
R813 1-218-716-11 METAL CHIP 10K 0.50% 1/10W
R814 1-218-736-11 METAL CHIP 68K 0.50% 1/10W
R815 1-218-732-11 METAL CHIP 47K 0.50% 1/10W
R850 1-215-453-00 METAL 22K 1% 1/4W
!
R851 1-216-821-11 METAL CHIP 1K 5% 1/10W
R852 1-218-889-11 METAL CHIP 56K 0.50% 1/10W
R862 1-216-813-11 METAL CHIP 220 5% 1/10W
R890 1-216-843-11 METAL CHIP 68K 5% 1/10W
R893 1-216-864-11 SHORT CHIP
R901 1-218-714-11 METAL CHIP 8.2K 0.50% 1/10W
RELAY
RY501 1-755-198-11 RELAY, AC POWER
!
RY600 1-755-395-11 RELAY (AC POWER)
SWITCH
SW515 1-572-707-11 SWITCH, LEVER
TRANSFORMER
T505 1-433-836-11 TRANSFORMER, HORIZONTAL DRIVE
!
T510 1-437-610-11 TRANSFORMER, FERRITE (PMT)
!
T511 1-433-850-11 TRANSFORMER, HORIZONTAL LINEAR
