Sony TRINITRON KV-27FA310 - Page 76

76
KV-27FA310/27FS120/29FA310/29FS120
KV-27FA310/27FS120/29FA310/29FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
RESISTOR
R1001 1-249-427-11 CARBON 6.8K 5% 1/4W
R1002 1-249-421-11 CARBON 2.2K 5% 1/4W
R1003 1-249-419-11 CARBON 1.5K 5% 1/4W
R2008 1-249-427-11 CARBON 6.8K 5% 1/4W
R2009 1-249-421-11 CARBON 2.2K 5% 1/4W
R2010 1-249-416-11 CARBON 820 5% 1/4W
R2011 1-249-415-11 CARBON 680 5% 1/4W
R2235 1-249-409-11 CARBON 220 5% 1/4W
R2236 1-249-441-11 CARBON 100K 5% 1/4W
R2237 1-249-409-11 CARBON 220 5% 1/4W
R2238 1-249-441-11 CARBON 100K 5% 1/4W
R2240 1-247-804-11 CARBON 75 5% 1/4W
SWITCH
S1007 1-762-816-11 SWITCH, TACTILE
S1008 1-762-816-11 SWITCH, TACTILE
S2001 1-692-431-21 SWITCH, TACTILE
S2002 1-692-431-21 SWITCH, TACTILE
S2003 1-692-431-21 SWITCH, TACTILE
S2004 1-692-431-21 SWITCH, TACTILE
S2005 1-692-431-21 SWITCH, TACTILE
K
* A-1410-921-A K BOARD, MOUNTED
(KV-27FA310/29FA310 ONLY)
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C2401 1-130-495-00 MYLAR 0.1µF 5% 50V
C2402 1-130-495-00 MYLAR 0.1µF 5% 50V
C2403 1-126-964-11 ELECT 10µF 20% 50V
C2404 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C2405 1-126-965-91 ELECT 22µF 20% 50V
C2406 1-126-964-11 ELECT 10µF 20% 50V
C2407 1-126-964-11 ELECT 10µF 20% 50V
C2408 1-162-969-11 CERAMIC CHIP 0.0068µF 10% 25V
C2410 1-126-969-11 ELECT 220µF 20% 50V
C2411 1-126-965-91 ELECT 22µF 20% 50V
C2412 1-137-194-81 FILM 0.47µF 5% 50V
C2413 1-100-120-51 ELECT 1000µF 20% 35V
C2414 1-126-963-11 ELECT 4.7µF 20% 50V
C2415 1-126-967-11 ELECT 47µF 20% 50V
C2416 1-164-172-11 CERAMIC CHIP 0.0056µF 10% 25V
C2417 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C2418 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C2419 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C2420 1-126-959-11 ELECT 0.47µF 20% 50V
C2421 1-126-959-11 ELECT 0.47µF 20% 50V
C2422 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C2423 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
C2424 1-162-969-11 CERAMIC CHIP 0.0068µF 10% 25V
C2425 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2426 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C2427 1-126-947-11 ELECT 47µF 20% 35V
C2428 1-126-943-11 ELECT 2200µF 20% 25V
C2429 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2430 1-126-960-11 ELECT 1µF 20% 50V
C2431 1-126-963-11 ELECT 4.7µF 20% 50V
C2432 1-126-963-11 ELECT 4.7µF 20% 50V
C2433 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C2434 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2435 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2436 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2437 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2438 1-164-227-11 CERAMIC CHIP 0.022µF 10% 25V
C2439 1-164-227-11 CERAMIC CHIP 0.022µF 10% 25V
C2440 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2441 1-115-412-11 CERAMIC CHIP 680pF 5% 25V
C2442 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
C2443 1-115-412-11 CERAMIC CHIP 680pF 5% 25V
C2444 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
C2445 1-126-965-91 ELECT 22µF 20% 50V
C2446 1-130-495-00 MYLAR 0.1µF 5% 50V
C2447 1-130-495-00 MYLAR 0.1µF 5% 50V
C2448 1-137-190-91 FILM 0.22µF 5% 50V
C2449 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
C2450 1-126-963-11 ELECT 4.7µF 20% 50V
C2451 1-162-967-11 CERAMIC CHIP 0.0033µF 10% 50V
C2452 1-164-677-11 CERAMIC CHIP 0.033µF 10% 16V
C2453 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C2454 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2455 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2456 1-126-963-11 ELECT 4.7µF 20% 50V
C2457 1-126-963-11 ELECT 4.7µF 20% 50V
K
HU
