Sony TRINITRON KV-27FA310 - Page 79

79
KV-27FA310/27FS120/29FA310/29FS120
KV-27FA310/27FS120/29FA310/29FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
R2498 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2499 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2500 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R2501 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2502 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2503 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2504 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2505 1-216-841-11 METAL CHIP 47K 5% 1/10W
R2507 1-216-809-11 METAL CHIP 100 5% 1/10W
R2519 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2520 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2521 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2522 1-216-841-11 METAL CHIP 47K 5% 1/10W
R2523 1-216-841-11 METAL CHIP 47K 5% 1/10W
R2524 1-216-864-11 SHORT CHIP
V
* A-1410-924-A V BOARD, MOUNTED
CAPACITOR
C2801 1-128-578-11 ELECT 1µF 20% 100V
C2802 1-126-964-11 ELECT 10µF 20% 50V
C2803 1-137-378-11 MYLAR 0.22µF 5% 50V
C2804 1-137-378-11 MYLAR 0.22µF 5% 50V
C2805 1-129-745-61 FILM 0.033µF 5% 400V
C2808 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C2809 1-128-934-91 CERAMIC CHIP 0.33µF 20% 10V
C2810 1-130-495-00 MYLAR 0.1µF 5% 50V
C2811 1-129-725-00 FILM 0.082µF 5% 400V
C2812 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C2813 1-126-933-11 ELECT 100µF 20% 16V
C2821 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C2823 1-130-967-00 FILM 0.0027µF 5% 50V
C2824 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
C2826 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C2862 1-126-964-11 ELECT 10µF 20% 50V
CONNECTOR
* CN2901 1-564-507-11 PLUG, CONNECTOR 4P
* CN2902 1-770-723-11 CONNECTOR, BOARD TO BOARD 8P
* CN2903 1-564-506-11 PLUG, CONNECTOR 3P
DIODE
D2801 8-719-109-89 DIODE RD5.6ESB2
D2802 8-719-991-33 DIODE 1SS133T-77
D2804 8-719-302-43 DIODE EL1Z
D2805 8-719-991-33 DIODE 1SS133T-77
D2806 8-719-991-33 DIODE 1SS133T-77
D2807 8-719-210-21 DIODE 11EQS04
D2808 8-719-991-33 DIODE 1SS133T-77
D2813 8-719-991-33 DIODE 1SS133T-77
IC
IC2801 6-701-598-01 IC UPC5023CS-184
COIL
L2801 1-406-989-21 INDUCTOR 10MH
L2802 1-419-633-11 INDUCTOR 10MH
L2803 1-412-529-11 INDUCTOR 22µH
TRANSISTOR
Q2801 8-729-422-27 TRANSISTOR 2SD601A-Q
Q2802 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q2803 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q2804 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q2805 6-550-106-01 TRANSISTOR KTB764
Q2807 8-729-931-45 TRANSISTOR IRF614
Q2808 6-550-106-01 TRANSISTOR KTB764
Q2812 8-729-026-39 TRANSISTOR 2SA933AS-QT
RESISTOR
R2800 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2801 1-216-841-11 METAL CHIP 47K 5% 1/10W
R2802 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2803 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2804 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2805 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R2807 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R2808 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2809 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2811 1-249-393-11 CARBON 10 5% 1/4W
V
K
