— 65 —
KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
A
C505 1-102-228-00 CERAMIC 470pF 10% 500V
C506 1-106-383-00 MYLAR 0.047µF 10% 200V
C507 1-162-116-00 CERAMIC 680pF 10% 2KV
C508 1-102-228-00 CERAMIC 470pF 10% 500V
C509 1-162-116-00 CERAMIC 680pF 10% 2KV
C510 1-137-150-11 FILM 0.01µF 5% 100V
C511 1-117-652-11 FILM 22000pF 3% 1.2KV
(KV-32FV310/36FV310 ONLY)
C511 1-136-086-00 FILM 17000pF 1.2KV
(KV-27FV310/29FV310 ONLY)
C513 1-129-722-00 FILM 0.047µF 630V
(KV-27FV310/29FV310 ONLY)
C513 1-130-118-91 FILM 0.051µF 5% 400V
(KV-32FV310/36FV310 ONLY)
C514 1-109-844-11 FILM 0.68µF 5% 400V
(KV-27FV310/29FV310 ONLY)
C514 1-115-521-11 FILM 0.82µF 5% 250V
(KV-32FV310/36FV310 ONLY)
C515 1-104-987-11 MYLAR 0.001µF 5% 200V
C516 1-115-356-11 FILM 1.2µF 5% 250V
(KV-32FV310/36FV310 ONLY)
C516 1-115-521-11 FILM 0.82µF 5% 250V
(KV-27FV310/29FV310 ONLY)
C517 1-107-649-11 ELECT 2.2µF 20% 250V
C518 1-106-387-00 MYLAR 0.068µF 10% 200V
C519 1-102-244-00 CERAMIC 220pF 10% 500V
C520 1-164-646-11 CERAMIC 2200pF 10% 500V
C522 1-126-960-11 ELECT 1µF 20% 50V
C525 1-102-244-00 CERAMIC 220pF 10% 500V
C526 1-107-662-11 ELECT 22µF 20% 350V
C527 1-162-116-00 CERAMIC 680pF 10% 2KV
C528 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C529 1-128-551-11 ELECT 22µF 20% 63V
C530 1-130-475-00 MYLAR 0.0022µF 5% 50V
C531 1-126-965-91 ELECT 22µF 20% 50V
C532 1-126-965-91 ELECT 22µF 20% 50V
C534 1-126-967-11 ELECT 47µF 20% 50V
C535 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C537 1-126-941-11 ELECT 470µF 20% 25V
C539 1-126-941-11 ELECT 470µF 20% 25V
C540 1-131-867-51 ELECT 100µF 160V
C541 1-128-560-11 ELECT 22µF 20% 100V
C553 1-117-412-11 FILM 0.24µF 5% 250V
(KV-27FV310/29FV310 ONLY)
C553 1-117-661-11 FILM 0.15µF 5% 250V
(KV-32FV310/36FV310 ONLY)
C554 1-117-629-11 FILM 2700pF 3% 1.2KV
(KV-27FV310/29FV310 ONLY)
C554 1-117-635-11 FILM 4700pF 3% 1.2KV
(KV-32FV310/36FV310 ONLY)
C561 1-126-967-11 ELECT 47µF 20% 50V
C563 1-104-666-11 ELECT 220µF 20% 25V
C564 1-126-960-11 ELECT 1µF 20% 50V
C565 1-126-969-11 ELECT 220µF 20% 50V
C568 1-136-169-00 FILM 0.22µF 5% 50V
C571 1-126-942-61 ELECT 1000µF 20% 25V
C572 1-126-942-61 ELECT 1000µF 20% 25V
C590 1-126-964-11 ELECT 10µF 20% 50V
C1501 1-107-846-11 FILM 0.1µF 5% 400V
(KV-32FV310/36FV310 ONLY)
C6001 1-126-940-11 ELECT 330µF 20% 25V
C6002 1-126-947-11 ELECT 47µF 20% 35V
C6003 1-125-837-91 CERAMIC CHIP 1µF 10% 6.3V
C6005 1-126-768-11 ELECT 2200µF 20% 16V
CONNECTOR
* CN003 1-564-509-11 PLUG, CONNECTOR 6P
* CN006 1-564-506-11 PLUG, CONNECTOR 3P
* CN007 1-560-124-00 PLUG, CONNECTOR (2.5MM) 4P
CN306 1-764-611-11 CONNECTOR, BOARD TO BOARD 20P
* CN333 1-774-105-11 CONNECTOR, BOARD TO BOARD 15P
* CN501 1-580-798-11 CONNECTOR PIN (DY) 6P
* CN503 1-564-510-11 PLUG, CONNECTOR 7P
* CN504 1-564-509-11 PLUG, CONNECTOR 6P
* CN505 1-564-510-11 PLUG, CONNECTOR 7P
* CN590 1-564-507-11 PLUG, CONNECTOR 4P
CN600 1-695-915-11 TAB (CONTACT)
* CN3300 1-774-105-11 CONNECTOR, BOARD TO BOARD 15P
* CN3301 1-774-105-11 CONNECTOR, BOARD TO BOARD 15P
DIODE
D002 8-719-109-93 DIODE RD6.2ESB2
D004 8-719-921-44 DIODE MTZJ-5.1C
D005 8-719-110-17 DIODE RD10ESB2
D006 8-719-110-17 DIODE RD10ESB2
D007 8-719-404-50 DIODE MA111-TX
D008 8-719-404-50 DIODE MA111-TX
D009 8-719-982-22 DIODE MTZJ-30D
D010 8-719-109-93 DIODE RD6.2ESB2
