— 66 —
KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
D100 8-719-929-15 DIODE HZS9.1NB2
D101 8-719-929-15 DIODE HZS9.1NB2
D102 8-719-109-85 DIODE RD5.1ESB2
D110 8-719-991-33 DIODE 1SS133T-77
D111 8-719-109-93 DIODE RD6.2ESB2
D112 8-719-109-93 DIODE RD6.2ESB2
D113 8-719-921-44 DIODE MTZJ-5.1C
D200 8-719-929-15 DIODE HZS9.1NB2
D201 8-719-929-15 DIODE HZS9.1NB2
D209 8-719-929-15 DIODE HZS9.1NB2
D210 8-719-929-15 DIODE HZS9.1NB2
D211 8-719-929-15 DIODE HZS9.1NB2
D212 8-719-929-15 DIODE HZS9.1NB2
D213 8-719-929-15 DIODE HZS9.1NB2
D217 8-719-929-15 DIODE HZS9.1NB2
D218 8-719-929-15 DIODE HZS9.1NB2
D219 8-719-929-15 DIODE HZS9.1NB2
D302 8-719-981-99 DIODE MTZJ-3.3
D303 8-719-929-15 DIODE HZS9.1NB2
D304 8-719-921-44 DIODE MTZJ-5.1C
D305 8-719-108-12 DIODE RD9.1EW
D306 8-719-929-15 DIODE HZS9.1NB2
D307 8-719-929-15 DIODE HZS9.1NB2
D308 8-719-929-15 DIODE HZS9.1NB2
D309 8-719-110-17 DIODE RD10ESB2
D310 8-719-110-17 DIODE RD10ESB2
D311 8-719-110-17 DIODE RD10ESB2
D312 8-719-929-15 DIODE HZS9.1NB2
D313 8-719-108-12 DIODE RD9.1EW
D314 8-719-108-12 DIODE RD9.1EW
D315 8-719-110-17 DIODE RD10ESB2
D316 8-719-110-17 DIODE RD10ESB2
D317 8-719-110-17 DIODE RD10ESB2
D320 8-719-991-33 DIODE 1SS133T-77
D401 8-719-923-60 DIODE MTZJ-T-77-9.1A
D402 8-719-923-60 DIODE MTZJ-T-77-9.1A
D412 8-719-404-50 DIODE MA111-TX
D413 8-719-921-63 DIODE MTZJ-7.5B
D415 8-719-991-33 DIODE 1SS133T-77
D501 8-719-109-89 DIODE RD5.6ESB2
D502 8-719-081-00 DIODE BY228/A52A/
D503 8-719-081-00 DIODE BY228/A52A/
D504 6-500-485-01 DIODE FR305G-EB
D505 8-719-908-03 DIODE GP08D
D506 8-719-908-03 DIODE GP08D
D507 8-719-991-33 DIODE 1SS133T-77
D508 8-719-991-33 DIODE 1SS133T-77
D515 8-719-075-41 DIODE PR1004GT
D516 8-719-991-33 DIODE 1SS133T-77
D518 8-719-991-33 DIODE 1SS133T-77
D520 8-719-991-33 DIODE 1SS133T-77
D521 8-719-921-63 DIODE MTZJ-7.5B
D522 8-719-991-33 DIODE 1SS133T-77
D523 8-719-109-69 DIODE RD3.6ESB2
D524 8-719-109-97 DIODE RD6.8ESB2
D530 6-500-531-01 DIODE P6154R
D531 6-500-531-01 DIODE P6154R
D534 8-719-074-25 DIODE PG104R
D535 8-719-404-50 DIODE MA111-TX
D536 1-216-864-11 SHORT CHIP
D561 8-719-075-33 DIODE 1N4003GA
D580 8-719-991-33 DIODE 1SS133T-77
D590 8-719-991-33 DIODE 1SS133T-77
FERRITE BEAD
FB501 1-410-397-21 FERRITE 1.1µH
FB502 1-410-397-21 FERRITE 1.1µH
FB503 1-410-397-21 FERRITE 1.1µH
FB505 1-410-397-21 FERRITE 1.1µH
IC
IC001 6-803-010-01 IC M306V5ME-110SP
IC002 6-701-929-01 IC BD4743G-TR
IC003 8-759-641-86 IC BR24C16F-E2
IC301 8-752-100-49 IC CXA2154AS
IC303 8-759-443-11 IC NJM2283M-TE1
IC400 6-703-190-01 IC NJW1134AGK1-TE2
IC405 6-701-105-01 IC NJM2750M-TE2
IC501 8-759-700-07 IC NJM2903M
IC561 8-759-696-71 IC STV9379A
(KV-32FV310/36FV310 ONLY)
IC561 8-759-980-58 IC TDA8172
(KV-27FV310/29FV310 ONLY)
IC6008 6-701-752-01 IC NJM2930F05B
JACK
J201 1-794-119-11 TERMINAL BLOCK, S 4P
J203 1-794-118-11 JACK BLOCK, PIN 3P
J204 1-794-118-11 JACK BLOCK, PIN 3P
A
