— 81 —
KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
D8023 8-719-109-85 DIODE RD5.1ESB2
D8024 8-719-109-93 DIODE RD6.2ESB2
D8026 8-719-404-50 DIODE MA111-TX
D8030 8-719-083-66 DIODE UDZSTE-1718B
D8034 8-719-109-85 DIODE RD5.1ESB2
D8140 8-719-404-50 DIODE MA111-TX
D8301 8-719-069-54 DIODE UDZSTE-175.1B
D8400 8-719-991-33 DIODE 1SS133T-77
D8510 8-719-081-93 DIODE 1N4937/23
D8511 8-719-970-87 DIODE ERA38-06
D8512 8-719-970-87 DIODE ERA38-06
D8513 8-719-110-41 DIODE RD15ESB2
FERRITE BEAD
FB8001 1-412-911-11 FERRITE 0µH
FB8002 1-412-911-11 FERRITE 0µH
FB8504 1-410-397-21 FERRITE 1.1µH
IC
!
IC8001 8-759-700-07 IC NJM2903M
IC8002 8-759-670-30 IC MCZ3001D
!
IC8004 8-759-701-01 IC NJM2904M
!
IC8005 8-759-198-31 IC UPC1093J-1-T
IC8006 8-759-700-07 IC NJM2903M
!
IC8104 8-759-586-17 IC TL1431CZ-AP
IC8401 6-704-065-01 IC TFA9844J
IC8402 8-759-100-96 IC UPC4558G2
CHIP CONDUCTOR
JR8002 1-216-864-11 SHORT CHIP
JR8005 1-216-864-11 SHORT CHIP
JR8006 1-216-864-11 SHORT CHIP
JR8007 1-216-864-11 SHORT CHIP
JR8008 1-216-864-11 SHORT CHIP
JR8009 1-216-864-11 SHORT CHIP
JR8010 1-216-864-11 SHORT CHIP
JR8011 1-216-864-11 SHORT CHIP
JR8012 1-216-864-11 SHORT CHIP
JR8100 1-216-864-11 SHORT CHIP
JR8101 1-216-864-11 SHORT CHIP
JR8102 1-216-864-11 SHORT CHIP
JR8103 1-216-864-11 SHORT CHIP
COIL
L8001 1-414-189-31 INDUCTOR 100µH
L8002 1-428-950-11 INDUCTOR 125µH
L8504 1-406-677-11 INDUCTOR 10MH
L8600 1-406-977-21 INDUCTOR 100µH
PHOTO COUPLER
PH8001 8-749-016-81 PHOTO COUPLER PC123Y22
!
PH8003 8-749-016-81 PHOTO COUPLER PC123Y22
!
PH8004 8-749-016-81 PHOTO COUPLER PC123Y22
IC LINK
PS8401 1-576-337-21 IC LINK 2.7A 50V
TRANSISTOR
Q8003 8-729-422-27 TRANSISTOR 2SD601A-Q
Q8004 8-729-422-27 TRANSISTOR 2SD601A-Q
Q8007 8-729-422-27 TRANSISTOR 2SD601A-Q
Q8008 8-729-422-27 TRANSISTOR 2SD601A-Q
Q8011 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q8013 8-729-052-32 TRANSISTOR IRFIB7N50A-LF31
Q8014 8-729-052-32 TRANSISTOR IRFIB7N50A-LF31
Q8021 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q8028 8-729-422-27 TRANSISTOR 2SD601A-Q
Q8034 8-729-422-27 TRANSISTOR 2SD601A-Q
Q8035 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q8400 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8401 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8507 8-729-043-95 TRANSISTOR 2SC3840(3)
RESISTOR
R8001 1-216-809-11 METAL CHIP 100 5% 1/10W
R8002 1-249-417-11 CARBON 1K 5% 1/4W
R8003 1-216-837-11 METAL CHIP 22K 5% 1/10W
R8004 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R8005 1-216-837-11 METAL CHIP 22K 5% 1/10W
R8006 1-219-512-11 METAL 2.2M 5% 1/2W
R8007 1-219-512-11 METAL 2.2M 5% 1/2W
!
R8009 1-218-877-11 METAL CHIP 18K 0.5% 1/10W
(KV-27FV310/29FV310 ONLY)
R8011 1-216-849-11 METAL CHIP 220K 5% 1/10W
R8012 1-249-419-11 CARBON 1.5K 5% 1/4W
R8013 1-216-833-11 METAL CHIP 10K 5% 1/10W
!
R8014 1-218-847-11 METAL CHIP 1K 0.50% 1/10W
!
R8015 1-218-855-11 METAL CHIP 2.2K 0.50% 1/10W
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
D
