— 82 —
KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
! R8016 1-247-843-11 CARBON 3.3K 5% 1/4W
! R8017 1-218-857-11 METAL CHIP 2.7K 0.50% 1/10W
(KV-27FV310/29FV310 ONLY)
! R8017 1-218-858-11 METAL CHIP 3K 0.50% 1/10W
(KV-32FV310/36FV310 ONLY)
! R8019 1-218-895-11 METAL CHIP 100K 0.50% 1/10W
R8020 1-216-833-11 METAL CHIP 10K 5% 1/10W
! R8021 1-218-847-11 METAL CHIP 1K 0.50% 1/10W
(KV-32FV310/36FV310 ONLY)
! R8021 1-218-877-11 METAL CHIP 18K 0.50% 1/10W
(KV-27FV310/29FV310 ONLY)
R8022 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8024 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8027 1-218-891-11 METAL CHIP 68K 0.50% 1/10W
R8029 1-218-891-11 METAL CHIP 68K 0.50% 1/10W
R8030 1-218-895-11 METAL CHIP 100K 0.50% 1/10W
R8031 1-218-895-11 METAL CHIP 100K 0.50% 1/10W
R8034 1-216-857-11 METAL CHIP 1M 5% 1/10W
! R8035 1-218-861-11 METAL CHIP 3.9K 0.50% 1/10W
! R8036 1-215-421-00 METAL 1K 1% 1/4W
! R8037 1-215-447-00 METAL 12K 1% 1/4W
! R8038 1-215-447-00 METAL 12K 1% 1/4W
! R8039 1-215-447-00 METAL 12K 1% 1/4W
! R8040 1-215-433-00 METAL 3.3K 1% 1/4W
(KV-32FV310/36FV310 ONLY)
! R8040 1-215-443-00 METAL 8.2K 1% 1/4W
(KV-27FV310/29FV310 ONLY)
R8041 1-216-864-11 SHORT CHIP
! R8043 1-215-447-00 METAL 12K 1% 1/4W
R8045 1-216-857-11 METAL CHIP 1M 5% 1/10W
! R8046 1-218-843-11 METAL CHIP 680 0.50% 1/10W
(KV-27FV310/29FV310 ONLY)
! R8046 1-218-847-11 METAL CHIP 1K 0.50% 1/10W
(KV-32FV310/36FV310 ONLY)
R8049 1-218-823-11 METAL CHIP 100 0.50% 1/10W
R8050 1-211-981-11 METAL CHIP 33 0.50% 1/10W
! R8051 1-202-933-61 FUSIBLE 0.1 10% 1/2W
! R8052 1-218-873-11 METAL CHIP 12K 0.50% 1/10W
(KV-32FV310/36FV310 ONLY)
! R8052 1-218-887-11 METAL CHIP 47K 0.50% 1/10W
(KV-27FV310/29FV310 ONLY)
R8054 1-245-478-21 METAL 470K 1% 1/4W
R8055 1-245-478-21 METAL 470K 1% 1/4W
R8056 1-218-869-11 METAL CHIP 8.2K 0.50% 1/10W
R8057 1-218-874-11 METAL CHIP 13K 0.50% 1/10W
R8058 1-249-393-11 CARBON 10 5% 1/4W
R8059 1-216-864-11 SHORT CHIP
R8060 1-216-817-11 METAL CHIP 470 5% 1/10W
R8061 1-249-393-11 CARBON 10 5% 1/4W
R8062 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8063 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8066 1-216-821-11 METAL CHIP 1K 5% 1/10W
R8069 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R8070 1-243-979-71 METAL OXIDE 0.1 5% 2W
! R8072 1-249-377-11 CARBON 0.47 5% 1/4W
R8076 1-240-931-91 METAL 330 5% 0.5W
! R8078 1-218-897-11 METAL CHIP 120K 0.50% 1/10W
! R8079 1-249-431-11 CARBON 15K 5% 1/4W
! R8082 1-216-863-11 METAL CHIP 3.3M 5% 1/10W
R8085 1-219-749-91 METAL 10K 5% 1/2W
R8086 1-219-751-91 METAL 47K 5% 1/2W
R8087 1-216-864-11 SHORT CHIP
R8088 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8090 1-216-833-11 METAL CHIP 10K 5% 1/10W
! R8091 1-215-485-00 METAL 470K 1% 1/4W
! R8095 1-215-485-00 METAL 470K 1% 1/4W
R8096 1-216-864-11 SHORT CHIP
R8097 1-216-797-11 METAL CHIP 10 5% 1/10W
R8106 1-249-377-11 CARBON 0.47 5% 1/4W
R8135 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W
R8136 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R8137 1-216-821-11 METAL CHIP 1K 5% 1/10W
R8138 1-216-857-11 METAL CHIP 1M 5% 1/10W
R8144 1-216-849-11 METAL CHIP 220K 5% 1/10W
R8145 1-216-841-11 METAL CHIP 47K 5% 1/10W
R8146 1-216-821-11 METAL CHIP 1K 5% 1/10W
R8158 1-216-809-11 METAL CHIP 100 5% 1/10W
R8159 1-216-834-11 METAL CHIP 12K 5% 1/10W
R8160 1-216-853-11 METAL CHIP 470K 5% 1/10W
R8161 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W
R8200 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8203 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8206 1-216-817-11 METAL CHIP 470 5% 1/10W
R8301 1-216-837-11 METAL CHIP 22K 5% 1/10W
R8303 1-216-821-11 METAL CHIP 1K 5% 1/10W
R8304 1-218-853-11 METAL CHIP 1.8K 0.50% 1/10W
R8305 1-218-865-11 METAL CHIP 5.6K 0.50% 1/10W
R8401 1-249-429-11 CARBON 10K 5% 1/4W
