KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
A component identifi ed by this symbol indicates that it
has been carefully factory-selected to satisfy regulations
regarding X-ray radiation. Should replacement be required,
replace only with the value originally used.
R8404 1-216-837-11 METAL CHIP 22K 5% 1/10W
R8405 1-216-841-11 METAL CHIP 47K 5% 1/10W
R8408 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R8420 1-249-433-11 CARBON 22K 5% 1/4W
R8421 1-249-433-11 CARBON 22K 5% 1/4W
R8422 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8423 1-216-840-11 METAL CHIP 39K 5% 1/10W
R8424 1-216-840-11 METAL CHIP 39K 5% 1/10W
R8425 1-216-840-11 METAL CHIP 39K 5% 1/10W
R8426 1-216-817-11 METAL CHIP 470 5% 1/10W
R8427 1-216-817-11 METAL CHIP 470 5% 1/10W
R8428 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R8429 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R8430 1-218-847-11 METAL CHIP 1K 0.50% 1/10W
R8431 1-218-843-11 METAL CHIP 680 0.50% 1/10W
R8432 1-216-864-11 SHORT CHIP
R8434 1-218-895-11 METAL CHIP 100K 0.50% 1/10W
R8488 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R8541 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R8542 1-215-921-11 METAL OXIDE 4.7K 5% 3W
(KV-32FV310/36FV310 ONLY)
R8542 1-216-486-00 METAL OXIDE 8.2K 5% 3W
(KV-27FV310/29FV310 ONLY)
R8548 1-215-921-11 METAL OXIDE 4.7K 5% 3W
(KV-32FV310/36FV310 ONLY)
R8548 1-216-486-00 METAL OXIDE 8.2K 5% 3W
(KV-27FV310/29FV310 ONLY)
R8554 1-215-876-00 METAL OXIDE 15K 5% 1W
(KV-27FV310/29FV310 ONLY)
R8554 1-215-894-11 METAL OXIDE 2.2K 5% 2W
(KV-32FV310/36FV310 ONLY)
R8555 1-249-441-11 CARBON 100K 5% 1/4W
R8556 1-249-441-11 CARBON 100K 5% 1/4W
R8557 1-249-441-11 CARBON 100K 5% 1/4W
R8560 1-215-922-11 METAL OXIDE 6.8K 5% 3W
VARIABLE RESISTOR
X!
RV8002 1-225-627-91 RES, VAR, ADJ, CERMET 2K
SPARK GAP
SG8002 1-517-499-21 GAP, SPARK
TRANSFORMER
!
T8001 1-453-387-21 FBT ASSY NX-6020//M3J4
(KV-27FV310/29FV310/32FV310 ONLY)
!
T8001 1-453-389-31 FBT ASSY NX-6020//M3C4
(KV-36FV310 ONLY)
T8504 1-433-533-12 TRANSFORMER, FERRITE (DFT)
V
* A-1404-848-A V (VAR) BOARD, MOUNTED
(KV-27FV310/29FV310 ONLY)
* A-1404-895-A V (VAR) BOARD, MOUNTED
(KV-32FV310 ONLY)
* A-1404-955-A V (VAR) BOARD, MOUNTED
(KV-36FV310 ONLY)
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C802 1-126-964-11 ELECT 10µF 20% 50V
C803 1-137-378-11 MYLAR 0.22µF 5% 50V
C804 1-137-378-11 MYLAR 0.22µF 5% 50V
C805 1-131-985-21 FILM 0.033µF 5% 250V
C808 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C809 1-128-934-91 CERAMIC CHIP 0.33µF 20% 10V
C810 1-130-495-00 MYLAR 0.1µF 5% 50V
C811 1-129-725-00 FILM 0.082µF 5% 400V
C812 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C813 1-126-933-11 ELECT 100µF 20% 16V
C821 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C823 1-130-967-00 FILM 0.0027µF 5% 50V
C824 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
C826 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C862 1-126-964-11 ELECT 10µF 20% 50V
C901 1-107-667-11 ELECT 2.2µF 20% 400V
C902 1-107-364-11 MYLAR 0.01µF 10% 200V
C903 1-126-935-11 ELECT 470µF 20% 16V
C904 1-130-471-00 MYLAR 0.001µF 5% 50V
C905 1-107-364-11 MYLAR 0.01µF 10% 200V
C906 1-130-471-00 MYLAR 0.001µF 5% 50V
C907 1-107-963-11 ELECT 33µF 20% 250V
C908 1-126-935-11 ELECT 470µF 20% 16V
C909 1-104-999-11 MYLAR 0.1µF 5% 200V
C910 1-104-999-11 MYLAR 0.1µF 5% 200V
D
V
