KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
C911 1-126-933-11 ELECT 100µF 20% 16V
C912 1-126-933-11 ELECT 100µF 20% 16V
C913 1-102-074-00 CERAMIC 0.001µF 10% 50V
C914 1-130-491-00 MYLAR 0.047µF 5% 50V
C930 1-126-935-11 ELECT 470µF 20% 16V
C931 1-126-935-11 ELECT 470µF 20% 16V
CONNECTOR
* CN901 1-764-333-11 PIN, CONNECTOR(PCB)(V TYPE) 10P
* CN902 1-770-723-11 CONNECTOR, BOARD TO BOARD 8P
DIODE
D804 8-719-074-25 DIODE PG104R
D805 8-719-991-33 DIODE 1SS133T-77
D806 8-719-991-33 DIODE 1SS133T-77
D807 8-719-210-21 DIODE 11EQS04
D808 8-719-991-33 DIODE 1SS133T-77
D813 8-719-991-33 DIODE 1SS133T-77
D901 8-719-924-11 DIODE MTZJ-T-77-22
D902 8-719-924-11 DIODE MTZJ-T-77-22
D903 8-719-991-33 DIODE 1SS133T-77
D905 8-719-510-02 DIODE D1NS4
D906 8-719-404-50 DIODE MA111-TX
D907 8-719-404-50 DIODE MA111-TX
D908 8-719-404-50 DIODE MA111-TX
IC
IC801 6-701-598-01 IC UPC5023CS-184
CHIP CONDUCTOR
JR802 1-216-864-11 SHORT CHIP
JR803 1-216-864-11 SHORT CHIP
COIL
L801 1-406-989-21 INDUCTOR 10MH
L802 1-419-633-11 INDUCTOR 10MH
L803 1-412-529-81 INDUCTOR 22µH
L901 1-412-528-11 INDUCTOR 18µH
TRANSISTOR
Q805 6-550-106-01 TRANSISTOR KTB764
Q807 8-729-931-45 TRANSISTOR IRF614
Q808 6-550-106-01 TRANSISTOR KTB764
Q812 8-729-026-39 TRANSISTOR 2SA933AS-QT
Q901 8-729-053-87 TRANSISTOR KTC4370A
Q902 6-550-247-01 TRANSISTOR KTA1659A
Q903 8-729-422-27 TRANSISTOR 2SD601A-Q
Q904 8-729-422-27 TRANSISTOR 2SD601A-Q
Q905 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q906 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q907 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q908 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
RESISTOR
R809 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(KV-27FV310/29FV310 ONLY)
R809 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
(KV-32FV310/36FV310 ONLY)
R811 1-249-393-11 CARBON 10 5% 1/4W
R814 1-215-862-11 METAL OXIDE 68 5% 1W
(KV-32FV310/36FV310 ONLY)
R815 1-215-862-11 METAL OXIDE 68 5% 1W
R817 1-218-728-11 METAL CHIP 33K 0.50% 1/10W
(KV-32FV310/36FV310 ONLY)
R817 1-218-732-11 METAL CHIP 47K 0.50% 1/10W
(KV-27FV310/29FV310 ONLY)
R818 1-216-809-11 METAL CHIP 100 5% 1/10W
R819 1-216-841-11 METAL CHIP 47K 5% 1/10W
R820 1-216-837-11 METAL CHIP 22K 5% 1/10W
(KV-32FV310/36FV310 ONLY)
R820 1-216-839-11 METAL CHIP 33K 5% 1/10W
(KV-27FV310/29FV310 ONLY)
R821 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
(KV-27FV310/29FV310 ONLY)
R821 1-218-714-11 METAL CHIP 8.2K 0.50% 1/10W
(KV-32FV310/36FV310 ONLY)
R822 1-216-841-11 METAL CHIP 47K 5% 1/10W
R824 1-218-740-11 METAL CHIP 100K 0.50% 1/10W
R825 1-216-845-11 METAL CHIP 100K 5% 1/10W
R826 1-249-421-11 CARBON 2.2K 5% 1/4W
R827 1-218-708-11 METAL CHIP 4.7K 0.50% 1/10W
R828 1-218-728-11 METAL CHIP 33K 0.50% 1/10W
R829 1-216-853-11 METAL CHIP 470K 5% 1/10W
R833 1-218-710-11 METAL CHIP 5.6K 0.50% 1/10W
(KV-27FV310/29FV310 ONLY)
R833 1-218-712-11 METAL CHIP 6.8K 0.50% 1/10W
(KV-32FV310/36FV310 ONLY)
R834 1-218-700-11 METAL CHIP 2.2K 0.50% 1/10W
(KV-32FV310/36FV310 ONLY)
