KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
R834 1-218-706-11 METAL CHIP 3.9K 0.50% 1/10W
(KV-27FV310/29FV310 ONLY)
R837 1-218-714-11 METAL CHIP 8.2K 0.50% 1/10W
(KV-27FV310/29FV310 ONLY)
R840 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
(KV-27FV310/29FV310 ONLY)
R840 1-218-700-11 METAL CHIP 2.2K 0.50% 1/10W
(KV-32FV310/36FV310 ONLY)
R841 1-216-837-11 METAL CHIP 22K 5% 1/10W
(KV-27FV310/29FV310 ONLY)
R841 1-218-712-11 METAL CHIP 6.8K 0.50% 1/10W
(KV-32FV310/36FV310 ONLY)
R842 1-218-700-11 METAL CHIP 2.2K 0.50% 1/10W
R855 1-218-706-11 METAL CHIP 3.9K 0.50% 1/10W
(KV-32FV310/36FV310 ONLY)
R855 1-218-714-11 METAL CHIP 8.2K 0.50% 1/10W
(KV-27FV310/29FV310 ONLY)
R856 1-218-712-11 METAL CHIP 6.8K 0.50% 1/10W
(KV-27FV310/29FV310 ONLY)
R856 1-218-716-11 METAL CHIP 10K 0.50% 1/10W
(KV-32FV310/36FV310 ONLY)
R857 1-218-716-11 METAL CHIP 10K 0.50% 1/10W
(KV-32FV310/36FV310 ONLY)
R857 1-218-724-11 METAL CHIP 22K 0.50% 1/10W
R860 1-218-716-11 METAL CHIP 10K 0.50% 1/10W
R864 1-218-668-11 METAL CHIP 100 0.50% 1/10W
R866 1-249-438-11 CARBON 56K 5% 1/4W
R870 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R876 1-216-821-11 METAL CHIP 1K 5% 1/10W
R890 1-218-712-11 METAL CHIP 6.8K 0.50% 1/10W
(KV-32FV310/36FV310 ONLY)
R890 1-218-736-11 METAL CHIP 68K 0.50% 1/10W
(KV-27FV310/29FV310 ONLY)
R893 1-216-839-11 METAL CHIP 33K 5% 1/10W
R901 1-249-405-11 CARBON 100 5% 1/4W
R902 1-249-385-11 CARBON 2.2 5% 1/4W
R903 1-249-414-11 CARBON 560 5% 1/4W
R904 1-249-432-11 CARBON 18K 5% 1/4W
R905 1-249-421-11 CARBON 2.2K 5% 1/4W
R906 1-249-432-11 CARBON 18K 5% 1/4W
R907 1-249-385-11 CARBON 2.2 5% 1/4W
R908 1-249-414-11 CARBON 560 5% 1/4W
R909 1-260-316-51 CARBON 100 5% 1/2W
R910 1-215-915-11 METAL OXIDE 470 5% 3W
R911 1-215-405-00 METAL 220 1% 1/4W
R912 1-249-407-11 CARBON 150 5% 1/4W
R913 1-215-397-00 METAL 100 1% 1/4W
R914 1-249-416-11 CARBON 820 5% 1/4W
R915 1-249-425-11 CARBON 4.7K 5% 1/4W
R917 1-249-425-11 CARBON 4.7K 5% 1/4W
R918 1-249-401-11 CARBON 47 5% 1/4W
R919 1-249-401-11 CARBON 47 5% 1/4W
R921 1-249-429-11 CARBON 10K 5% 1/4W
R922 1-249-397-11 CARBON 22 5% 1/4W
R923 1-249-401-11 CARBON 47 5% 1/4W
R930 1-216-864-11 SHORT CHIP
R931 1-249-421-11 CARBON 2.2K 5% 1/4W
R932 1-218-696-11 METAL CHIP 1.5K 0.50% 1/10W
R933 1-216-864-11 SHORT CHIP
R935 1-249-405-11 CARBON 100 5% 1/4W
R938 1-216-864-11 SHORT CHIP
GK
* A-1404-844-A GK (VAR) BOARD, MOUNTED
(KV-27FV310/29FV310(N)/32FV310 ONLY)
* A-1404-956-A GK (VAR) BOARD, MOUNTED
(KV-36FV310 ONLY)
* A-1405-113-A GK (VAR) BOARD, MOUNTED
(KV-29FV310(S) ONLY)
1-533-223-11 FUSE HOLDER 0A 0V
* 4-374-846-11 COVER, CAPACITOR, CAP TYPE
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C501 1-165-529-11 MYLAR 0.22µF 10 275V
C600 1-117-703-11 CERAMIC 0.0047µF 250V
(KV-29FV310(S) ONLY)
!
C601 1-165-529-11 MYLAR 0.22µF 10 275V
C602 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
!
C603 1-165-529-11 MYLAR 0.22µF 10 275V
C604 1-164-625-11 CERAMIC 680pF 10% 500V
!
C608 1-119-912-51 CERAMIC 0.001µF 20% 125V
C609 1-164-625-11 CERAMIC 680pF 10% 500V
C613 1-117-214-11 CERAMIC 0.001µF 10% 2KV
(KV-29FV310(S) ONLY)
C614 1-117-214-11 CERAMIC 0.001µF 10% 2KV
(KV-29FV310(S) ONLY)
