— 86 —
KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
C615 1-117-214-11 CERAMIC 0.001µF 10% 2KV
(KV-29FV310(S) ONLY)
C616 1-126-943-11 ELECT 2200µF 20% 25V
C617 1-123-024-21 ELECT 33µF 160V
C618 1-126-943-11 ELECT 2200µF 20% 25V
C619 1-117-214-11 CERAMIC 0.001µF 10% 2KV
(KV-29FV310(S) ONLY)
C620 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C621 1-128-717-11 ELECT 680µF 20% 250V
! C622 1-119-912-51 CERAMIC 0.001µF 20% 125V
C624 1-107-636-11 ELECT 10µF 20% 160V
C629 1-128-717-11 ELECT 680µF 20% 250V
C632 1-126-947-11 ELECT 47µF 20% 35V
C633 1-136-479-11 FILM 0.001µF 5% 100V
C634 1-126-964-11 ELECT 10µF 20% 50V
C635 1-126-963-11 ELECT 4.7µF 20% 50V
C637 1-136-165-00 FILM 0.1µF 5% 50V
C638 1-104-665-11 ELECT 100µF 20% 25V
C640 1-126-942-61 ELECT 1000µF 20% 25V
C642 1-126-969-11 ELECT 220µF 20% 50V
C643 1-136-165-00 FILM 0.1µF 5% 50V
C644 1-126-969-11 ELECT 220µF 20% 50V
C645 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C647 1-126-947-11 ELECT 47µF 20% 35V
C648 1-164-143-11 CERAMIC 0.001µF 10% 1KV
C649 1-164-143-11 CERAMIC 0.001µF 10% 1KV
C650 1-100-120-51 ELECT 1000µF 20% 35V
C651 1-126-942-61 ELECT 1000µF 20% 25V
C652 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
C653 1-126-960-11 ELECT 1µF 20% 50V
C656 1-161-964-91 CERAMIC 0.0047µF 250V
C658 1-161-964-91 CERAMIC 0.0047µF 250V
C665 1-126-942-61 ELECT 1000µF 20% 25V
C667 1-164-625-11 CERAMIC 680pF 10% 500V
C668 1-164-625-11 CERAMIC 680pF 10% 500V
C669 1-164-625-11 CERAMIC 680pF 10% 500V
C670 1-164-625-11 CERAMIC 680pF 10% 500V
C672 1-165-953-11 FILM 47000pF 3% 800V
C690 1-126-971-11 ELECT 470µF 20% 50V
C1401 1-126-965-91 ELECT 22µF 20% 50V
C1402 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C1403 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C1404 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C1405 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C1406 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C1407 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C1408 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C1411 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C1412 1-104-656-11 ELECT 2200µF 20% 6.3V
C1413 1-126-963-11 ELECT 4.7µF 20% 50V
C1420 1-126-960-11 ELECT 1µF 20% 50V
C1450 1-100-120-51 ELECT 1000µF 20% 35V
C1451 1-137-194-81 FILM 0.47µF 5% 50V
C1458 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
CONNECTOR
* CN503 1-573-963-11 PIN, CONNECTOR (PC BOARD)
* CN600 1-580-843-11 PIN, CONNECTOR (POWER)
* CN602 1-564-510-11 PLUG, CONNECTOR 7P
* CN603 1-695-915-11 TAB (CONTACT)
(KV-29FV310(S) ONLY)
* CN604 1-695-915-11 TAB (CONTACT)
(ALL EXCEPT KV-29FV310[S])
* CN612 1-580-843-11 PIN, CONNECTOR (POWER)
CN613 1-564-320-00 PIN, CONNECTOR(3.96MM PITCH) 2P
* CN1401 1-564-507-11 PLUG, CONNECTOR 4P
* CN1404 1-564-510-11 PLUG, CONNECTOR 7P
* CN1405 1-564-507-11 PLUG, CONNECTOR 4P
* CN1601 1-564-509-11 PLUG, CONNECTOR 6P
DIODE
D501 8-719-404-50 DIODE MA111-TX
D600 6-500-397-11 DIODE GBJ4J10B9
D601 8-719-511-40 DIODE S1VB40
D608 8-719-110-31 DIODE MTZJ-T-77-12C
D611 8-719-062-40 DIODE D4SBL20µF3
D612 8-719-068-00 DIODE ERC04-06SE
(ALL EXCEPT KV-29FV310[S])
D613 8-719-068-00 DIODE ERC04-06SE
(ALL EXCEPT KV-29FV310[S])
D614 8-719-057-52 DIODE EZ0150AV1
D615 8-719-062-40 DIODE D4SBL20µF3
D618 8-719-979-64 DIODE UF4005PKG23
D619 8-719-404-50 DIODE MA111-TX
D620 8-719-404-50 DIODE MA111-TX
D621 6-500-181-01 DIODE MA6D50
D624 8-719-510-12 DIODE D10SC4M
D625 8-719-510-02 DIODE D1NS4
D628 8-719-404-50 DIODE MA111-TX
