Sony TRINITRON KV-DR29M39 - Page 102

– 120 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
R2204 1-216-073-91 RES-CHIP 10K 5% 1/10W
R2205 1-216-097-11 RES-CHIP 100K 5% 1/10W
R2206 1-216-117-00 RES-CHIP 680K 5% 1/10W
R2207 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R2208 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R2209 1-216-117-00 RES-CHIP 680K 5% 1/10W
R2210 1-216-089-91 RES-CHIP 47K 5% 1/10W
R2211 1-216-097-11 RES-CHIP 100K 5% 1/10W
R2212 1-216-073-91 RES-CHIP 10K 5% 1/10W
R2213 1-216-089-91 RES-CHIP 47K 5% 1/10W
R2214 1-216-089-91 RES-CHIP 47K 5% 1/10W
R2215 1-216-089-91 RES-CHIP 47K 5% 1/10W
R2602 1-215-882-00 METAL OXIDE 22 5% 2W
R2603 1-215-882-00 METAL OXIDE 22 5% 2W
R3001 1-216-017-91 RES-CHIP 47 5% 1/10W
R3002 1-216-017-91 RES-CHIP 47 5% 1/10W
R3003 1-216-017-91 RES-CHIP 47 5% 1/10W
R3004 1-216-017-91 RES-CHIP 47 5% 1/10W
R3005 1-216-017-91 RES-CHIP 47 5% 1/10W
R3006 1-216-025-11 RES-CHIP 100 5% 1/10W
R3007 1-216-089-91 RES-CHIP 47K 5% 1/10W
R3008 1-216-025-11 RES-CHIP 100 5% 1/10W
R3009 1-216-097-11 RES-CHIP 100K 5% 1/10W
R3010 1-208-806-11 METAL CHIP 10K 0.5% 1/10W
R3011 1-216-089-91 RES-CHIP 47K 5% 1/10W
R3012 1-216-097-11 RES-CHIP 100K 5% 1/10W
R3013 1-216-295-91 SHORT CHIP 0
R3014 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3015 1-216-295-91 SHORT CHIP 0
R3016 1-216-097-11 RES-CHIP 100K 5% 1/10W
R3017 1-216-025-11 RES-CHIP 100 5% 1/10W
R3018 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3019 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3020 1-216-089-91 RES-CHIP 47K 5% 1/10W
R3021 1-216-025-11 RES-CHIP 100 5% 1/10W
R3022 1-216-025-11 RES-CHIP 100 5% 1/10W
R3023 1-216-295-91 SHORT CHIP 0
R3024 1-216-295-91 SHORT CHIP 0
R3027 1-216-129-00 RES-CHIP 2.2M 5% 1/10W
R3031 1-216-025-11 RES-CHIP 100 5% 1/10W
R3033 1-216-041-00 RES-CHIP 470 5% 1/10W
R3034 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3035 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3036 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3044 1-216-041-00 RES-CHIP 470 5% 1/10W
R3047 1-216-017-91 RES-CHIP 47 5% 1/10W
R3048 1-216-017-91 RES-CHIP 47 5% 1/10W
R3053 1-216-041-00 RES-CHIP 470 5% 1/10W
R3076 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3300 1-216-043-91 RES-CHIP 560 5% 1/10W
(KV-DR29M39/M69/M89)
R3304 1-216-041-00 RES-CHIP 470 5% 1/10W
(KV-DR29M39/M69/M89)
R3320 1-216-073-91 RES-CHIP 10K 5% 1/10W
(KV-DR29M39/M69/M89)
R3323 1-216-025-11 RES-CHIP 100 5% 1/10W
(KV-DR29M39/M69/M89)
R3334 1-216-025-11 RES-CHIP 100 5% 1/10W
(KV-DR29M39/M69/M89)
R3362 1-216-025-11 RES-CHIP 100 5% 1/10W
(KV-DR29M39/M69/M89)
R3374 1-216-295-91 SHORT CHIP 0 (KV-DR29M39/M69/M89)
R4301 1-216-025-11 RES-CHIP 100 5% 1/10W
R4302 1-216-025-11 RES-CHIP 100 5% 1/10W
R4303 1-216-133-91 RES-CHIP 3.3M 5% 1/10W
R4304 1-208-798-11 METAL CHIP 4.7K 0.5% 1/10W
R4305 1-216-025-11 RES-CHIP 100 5% 1/10W
R4306 1-216-025-11 RES-CHIP 100 5% 1/10W
R4307 1-216-025-11 RES-CHIP 100 5% 1/10W
R4308 1-216-025-11 RES-CHIP 100 5% 1/10W
R4309 1-208-806-11 METAL CHIP 10K 0.5% 1/10W
R4310 1-216-077-91 RES-CHIP 15K 5% 1/10W
R4311 1-216-049-11 RES-CHIP 1K 5% 1/10W
R4314 1-216-113-00 RES-CHIP 470K 5% 1/10W
R4315 1-216-025-11 RES-CHIP 100 5% 1/10W
R4316 1-216-097-11 RES-CHIP 100K 5% 1/10W
R4317 1-216-025-11 RES-CHIP 100 5% 1/10W
R4318 1-216-121-11 RES-CHIP 1M 5% 1/10W
R4319 1-216-113-00 RES-CHIP 470K 5% 1/10W
R4320 1-216-025-11 RES-CHIP 100 5% 1/10W
R4321 1-216-059-00 RES-CHIP 2.7K 5% 1/10W
R4322 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R4323 1-216-085-91 RES-CHIP 33K 5% 1/10W
R4324 1-216-073-91 RES-CHIP 10K 5% 1/10W
R4325 1-216-025-11 RES-CHIP 100 5% 1/10W
R4326 1-216-025-11 RES-CHIP 100 5% 1/10W
R4327 1-216-025-11 RES-CHIP 100 5% 1/10W
R4328 1-216-025-11 RES-CHIP 100 5% 1/10W
R4329 1-216-025-11 RES-CHIP 100 5% 1/10W
R4330 1-216-025-11 RES-CHIP 100 5% 1/10W
R4332 1-216-295-91 SHORT CHIP 0
R4339 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R4343 1-218-760-11 METAL CHIP 220K 0.5% 1/10W
R4344 1-216-129-00 RES-CHIP 2.2M 5% 1/10W
R4345 1-208-796-11 METAL CHIP 3.9K 0.5% 1/10W
R4346 1-216-097-11 RES-CHIP 100K 5% 1/10W
R4347 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R4349 1-216-081-00 RES-CHIP 22K 5% 1/10W
R4350 1-216-295-91 SHORT CHIP 0
R4351 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R4352 1-208-798-11 METAL CHIP 4.7K 0.5% 1/10W
R4353 1-208-804-11 METAL CHIP 8.2K 0.5% 1/10W
R4354 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R4355 1-208-806-11 METAL CHIP 10K 0.5% 1/10W
R4356 1-208-790-11 METAL CHIP 2.2K 0.5% 1/10W
R4357 1-216-045-00 RES-CHIP 680 5% 1/10W
R4359 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R4361 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R4362 1-216-025-11 RES-CHIP 100 5% 1/10W
R4363 1-216-295-91 SHORT CHIP 0
R4365 1-216-085-91 RES-CHIP 33K 5% 1/10W
R4375 1-216-049-11 RES-CHIP 1K 5% 1/10W
R4376 1-208-814-91 METAL CHIP 22K 0.5% 1/10W
R4379 1-216-025-11 RES-CHIP 100 5% 1/10W
R4380 1-216-025-11 RES-CHIP 100 5% 1/10W
R4381 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R4382 1-216-073-91 RES-CHIP 10K 5% 1/10W
R4383 1-216-025-11 RES-CHIP 100 5% 1/10W
R4384 1-216-017-91 RES-CHIP 47 5% 1/10W
R4385 1-216-017-91 RES-CHIP 47 5% 1/10W
R4386 1-216-017-91 RES-CHIP 47 5% 1/10W
