– 119 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
R036 1-216-033-00 RES-CHIP 220 5% 1/10W
R037 1-216-033-00 RES-CHIP 220 5% 1/10W
R038 1-216-045-00 RES-CHIP 680 5% 1/10W
R039 1-216-025-11 RES-CHIP 100 5% 1/10W
R040 1-216-033-00 RES-CHIP 220 5% 1/10W
R041 1-216-025-11 RES-CHIP 100 5% 1/10W
R042 1-216-295-91 SHORT CHIP 0
R043 1-216-025-11 RES-CHIP 100 5% 1/10W
R044 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R045 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R046 1-216-033-00 RES-CHIP 220 5% 1/10W
R047 1-216-033-00 RES-CHIP 220 5% 1/10W
R048 1-216-073-91 RES-CHIP 10K 5% 1/10W
R051 1-216-049-11 RES-CHIP 1K 5% 1/10W
R052 1-216-049-11 RES-CHIP 1K 5% 1/10W
R053 1-216-049-11 RES-CHIP 1K 5% 1/10W
R054 1-216-049-11 RES-CHIP 1K 5% 1/10W
R057 1-216-025-11 RES-CHIP 100 5% 1/10W
R059 1-216-073-91 RES-CHIP 10K 5% 1/10W
R061 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R065 1-216-045-00 RES-CHIP 680 5% 1/10W
R067 1-216-049-11 RES-CHIP 1K 5% 1/10W
R068 1-216-073-91 RES-CHIP 10K 5% 1/10W
R070 1-216-033-00 RES-CHIP 220 5% 1/10W
R071 1-216-025-11 RES-CHIP 100 5% 1/10W
R072 1-216-025-11 RES-CHIP 100 5% 1/10W
R073 1-216-055-00 RES-CHIP 1.8K 5% 1/10W
R074 1-216-055-00 RES-CHIP 1.8K 5% 1/10W
R075 1-216-055-00 RES-CHIP 1.8K 5% 1/10W
R076 1-216-295-91 SHORT CHIP 0
R077 1-216-025-11 RES-CHIP 100 5% 1/10W
R078 1-216-295-91 SHORT CHIP 0
R079 1-216-025-11 RES-CHIP 100 5% 1/10W
R080 1-216-063-91 RES-CHIP 3.9K 5% 1/10W
R081 1-216-025-11 RES-CHIP 100 5% 1/10W
R082 1-216-041-00 RES-CHIP 470 5% 1/10W
R083 1-216-049-11 RES-CHIP 1K 5% 1/10W
R084 1-216-049-11 RES-CHIP 1K 5% 1/10W
R085 1-208-798-11 METAL CHIP 4.7K 0.5% 1/10W
R086 1-216-073-91 RES-CHIP 10K 5% 1/10W
R087 1-216-033-00 RES-CHIP 220 5% 1/10W
R101 1-216-025-11 RES-CHIP 100 5% 1/10W
R102 1-216-025-11 RES-CHIP 100 5% 1/10W
R105 1-216-295-91 SHORT CHIP 0
R109 1-216-041-00 RES-CHIP 470 5% 1/10W
R110 1-216-043-91 RES-CHIP 560 5% 1/10W
R111 1-216-025-11 RES-CHIP 100 5% 1/10W
R112 1-216-025-11 RES-CHIP 100 5% 1/10W
R123 1-216-025-11 RES-CHIP 100 5% 1/10W
R124 1-216-025-11 RES-CHIP 100 5% 1/10W
R301 1-216-113-00 RES-CHIP 470K 5% 1/10W
R302 1-216-089-91 RES-CHIP 47K 5% 1/10W
R303 1-216-089-91 RES-CHIP 47K 5% 1/10W
R304 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1200 1-216-060-00 RES-CHIP 3K 5% 1/10W
R1201 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R1202 1-216-060-00 RES-CHIP 3K 5% 1/10W
R1203 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1204 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1205 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1206 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1207 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R1217 1-216-077-91 RES-CHIP 15K 5% 1/10W
R1218 1-216-077-91 RES-CHIP 15K 5% 1/10W
R1219 1-216-081-00 RES-CHIP 22K 5% 1/10W
R1220 1-216-081-00 RES-CHIP 22K 5% 1/10W
R1221 1-216-079-00 RES-CHIP 18K 5% 1/10W
R1222 1-216-079-00 RES-CHIP 18K 5% 1/10W
R1223 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1224 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1225 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R1227 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R1228 1-249-405-11 CARBON 100 5% 1/4W
R1229 1-249-405-11 CARBON 100 5% 1/4W
R1230 1-249-405-11 CARBON 100 5% 1/4W
R1231 1-216-295-91 SHORT CHIP 0
R1232 1-216-081-00 RES-CHIP 22K 5% 1/10W
R1233 1-216-093-91 RES-CHIP 68K 5% 1/10W
R1234 1-216-097-11 RES-CHIP 100K 5% 1/10W
R1235 1-216-093-91 RES-CHIP 68K 5% 1/10W
R1236 1-216-081-00 RES-CHIP 22K 5% 1/10W
R1237 1-216-097-11 RES-CHIP 100K 5% 1/10W
R1238 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1239 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1240 1-216-041-00 RES-CHIP 470 5% 1/10W
R1241 1-216-295-91 SHORT CHIP 0
R1242 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R1243 1-216-097-11 RES-CHIP 100K 5% 1/10W
R1244 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1245 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1246 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R1247 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1248 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R1249 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R1250 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R1251 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R1252 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1253 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R1254 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R1256 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R1257 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R1258 1-216-081-00 RES-CHIP 22K 5% 1/10W
R1259 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1260 1-216-041-00 RES-CHIP 470 5% 1/10W
R1262 1-249-389-11 CARBON 4.7 5% 1/4W
R1263 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1265 1-249-397-11 CARBON 22 5% 1/4W
R1268 1-249-397-11 CARBON 22 5% 1/4W
R1269 1-216-025-11 RES-CHIP 100 5% 1/10W
R1270 1-216-025-11 RES-CHIP 100 5% 1/10W
R1271 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1272 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1273 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1274 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1275 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1276 1-216-073-91 RES-CHIP 10K 5% 1/10W
R2200 1-216-021-00 RES-CHIP 68 5% 1/10W
R2201 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R2202 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R2203 1-216-021-00 RES-CHIP 68 5% 1/10W
