Sony TRINITRON KV-DR29M39 - Page 100

– 118 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
Q4341 8-729-010-25 MSD601-RT1
Q8301 8-729-010-05 MSB709-RT1
Q8302 8-729-010-25 MSD601-RT1
Q8303 8-729-010-25 MSD601-RT1
Q8304 8-729-010-25 MSD601-RT1
Q8305 8-729-010-05 MSB709-RT1
Q8306 8-729-010-25 MSD601-RT1
Q8307 8-729-010-25 MSD601-RT1
Q8310 8-729-010-25 MSD601-RT1
Q8319 8-729-010-05 MSB709-RT1
Q8320 8-729-010-05 MSB709-RT1
Q8321 8-729-010-05 MSB709-RT1
Q8326 8-729-010-25 MSD601-RT1
Q8327 8-729-421-19 UN2213
Q8328 8-729-421-19 UN2213
Q8329 8-729-010-25 MSD601-RT1
Q8330 8-729-010-25 MSD601-RT1
Q8331 8-729-010-25 MSD601-RT1
Q8332 8-729-010-25 MSD601-RT1
Q8333 8-729-010-25 MSD601-RT1
Q8334 8-729-010-25 MSD601-RT1
Q8335 8-729-010-25 MSD601-RT1
Q8336 8-729-010-25 MSD601-RT1
Q8351 8-729-010-25 MSD601-RT1
Q8352 8-729-010-05 MSB709-RT1
Q8361 8-729-010-25 MSD601-RT1
Q8362 8-729-010-25 MSD601-RT1
Q8363 8-729-010-25 MSD601-RT1
Q8364 8-729-010-05 MSB709-RT1
Q8365 8-729-010-25 MSD601-RT1
<RESISTOR>
R001 1-216-033-00 RES-CHIP 220 5% 1/10W
R002 1-216-033-00 RES-CHIP 220 5% 1/10W
R004 1-216-295-91 SHORT CHIP 0
R005 1-216-295-91 SHORT CHIP 0
R006 1-216-029-00 RES-CHIP 150 5% 1/10W
R010 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R011 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R012 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R013 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R014 1-216-025-11 RES-CHIP 100 5% 1/10W
R015 1-216-025-11 RES-CHIP 100 5% 1/10W
R016 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R017 1-216-049-11 RES-CHIP 1K 5% 1/10W
R018 1-216-045-00 RES-CHIP 680 5% 1/10W
R019 1-216-049-11 RES-CHIP 1K 5% 1/10W
R020 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R022 1-216-033-00 RES-CHIP 220 5% 1/10W
R023 1-216-025-11 RES-CHIP 100 5% 1/10W
R024 1-216-063-91 RES-CHIP 3.9K 5% 1/10W
R025 1-216-049-11 RES-CHIP 1K 5% 1/10W
R026 1-216-049-11 RES-CHIP 1K 5% 1/10W
R027 1-216-049-11 RES-CHIP 1K 5% 1/10W
R028 1-216-049-11 RES-CHIP 1K 5% 1/10W
R029 1-216-049-11 RES-CHIP 1K 5% 1/10W
R031 1-216-033-00 RES-CHIP 220 5% 1/10W
R032 1-216-049-11 RES-CHIP 1K 5% 1/10W
R033 1-216-033-00 RES-CHIP 220 5% 1/10W
R035 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
L4302 1-412-029-11 INDUCTOR 10UH
L4303 1-412-029-11 INDUCTOR 10UH
L4304 1-412-029-11 INDUCTOR 10UH
L4305 1-412-029-11 INDUCTOR 10UH
L4306 1-412-029-11 INDUCTOR 10UH
L4307 1-412-029-11 INDUCTOR 10UH
<IC LINK>
PS1201 1-533-597-41 LINK, IC
<TRANSISTOR>
Q001 8-729-010-05 MSB709-RT1
Q002 8-729-010-25 MSD601-RT1
Q003 8-729-010-25 MSD601-RT1
Q004 8-729-010-25 MSD601-RT1
Q101 8-729-010-05 MSB709-RT1
Q301 8-729-010-05 MSB709-RT1
Q302 8-729-010-05 MSB709-RT1
Q313 8-729-010-25 MSD601-RT1
Q1203 8-729-027-44 DTC114TKA-T146
Q1204 8-729-224-62 2SK246-GR
Q1205 8-729-230-49 2SC2712-YG (KV-DR29M39/M69/M89)
Q1205 8-729-422-27 2SD601A-Q (KV-DR29M63)
Q1206 8-729-230-49 2SC2712-YG (KV-DR29M39/M69/M89)
Q1206 8-729-422-27 2SD601A-Q (KV-DR29M63)
Q1207 8-729-010-05 MSB709-RT1
Q1208 8-729-027-44 DTC114TKA-T146
Q1209 8-729-027-44 DTC114TKA-T146
Q1210 8-729-027-44 DTC114TKA-T146
Q2200 8-729-027-56 DTC143TKA-T146
Q2201 8-729-027-56 DTC143TKA-T146
Q3001 8-729-102-07 2SC2223-F13
Q3002 8-729-102-07 2SC2223-F13
Q3003 8-729-102-07 2SC2223-F13
Q3014 8-729-010-05 MSB709-RT1
Q3015 8-729-102-07 2SC2223-F13
Q3018 8-729-102-07 2SC2223-F13
Q3023 8-729-102-07 2SC2223-F13
Q3300 8-729-010-05 MSB709-RT1 (KV-DR29M39/M69/M89)
Q4301 8-729-010-25 MSD601-RT1
Q4305 8-729-010-25 MSD601-RT1
Q4306 8-729-216-22 2SA1162-G
Q4307 8-729-010-25 MSD601-RT1
Q4308 8-729-216-22 2SA1162-G
Q4309 8-729-216-22 2SA1162-G
Q4310 8-729-010-25 MSD601-RT1
Q4314 8-729-421-19 UN2213
Q4315 8-729-010-25 MSD601-RT1
Q4316 8-729-216-22 2SA1162-G
Q4317 8-729-216-22 2SA1162-G
Q4318 8-729-216-22 2SA1162-G
Q4319 8-729-216-22 2SA1162-G
Q4320 8-729-010-25 MSD601-RT1
Q4321 8-729-216-22 2SA1162-G
Q4330 8-729-216-22 2SA1162-G
Q4335 8-729-216-22 2SA1162-G
Q4336 8-729-216-22 2SA1162-G
Q4337 8-729-216-22 2SA1162-G
Q4340 8-729-010-25 MSD601-RT1
A
