Sony TRINITRON KV-DR29M39 - Page 99

– 117 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
D8312 8-719-158-35 RD9.1S-B (KV-DR29M39/M69/M89)
D8312 8-719-069-60 UDZSTE-179.1B (KV-DR29M63)
D8313 8-719-158-35 RD9.1S-B (KV-DR29M39/M69/M89)
D8313 8-719-069-60 UDZSTE-179.1B (KV-DR29M63)
D8314 8-719-158-35 RD9.1S-B (KV-DR29M39/M69/M89)
D8314 8-719-069-60 UDZSTE-179.1B (KV-DR29M63)
D8315 8-719-158-35 RD9.1S-B (KV-DR29M39/M69/M89)
D8315 8-719-069-60 UDZSTE-179.1B (KV-DR29M63)
D8316 8-719-158-35 RD9.1S-B (KV-DR29M39/M69/M89)
D8316 8-719-069-60 UDZSTE-179.1B (KV-DR29M63)
D8320 8-719-158-35 RD9.1S-B (KV-DR29M39/M69/M89)
D8320 8-719-069-60 UDZSTE-179.1B (KV-DR29M63)
D8321 8-719-069-60 UDZSTE-179.1B (KV-DR29M63)
D8321 8-719-158-35 RD9.1S-B (KV-DR29M39/M69/M89)
D8322 8-719-158-35 RD9.1S-B (KV-DR29M39/M69/M89)
D8322 8-719-069-60 UDZSTE-179.1B (KV-DR29M63)
D8323 8-719-158-35 RD9.1S-B (KV-DR29M39/M69/M89)
D8323 8-719-069-60 UDZSTE-179.1B (KV-DR29M63)
D8324 8-719-158-35 RD9.1S-B (KV-DR29M39/M69/M89)
D8324 8-719-069-60 UDZSTE-179.1B (KV-DR29M63)
D8325 8-719-158-35 RD9.1S-B (KV-DR29M39/M69/M89)
D8325 8-719-069-60 UDZSTE-179.1B (KV-DR29M63)
D8331 8-719-041-97 MA113-(TX)
<FERRITE BEAD>
FB002 1-414-233-22 FERRITE 0UH
FB003 1-414-233-22 FERRITE 0UH
FB004 1-414-233-22 FERRITE 0UH
FB005 1-414-233-22 FERRITE 0UH
FB006 1-414-233-22 FERRITE 0UH
FB008 1-414-233-22 FERRITE 0UH
FB1300 1-216-295-91 SHORT CHIP 0 (KV-DR29M39/M69/M89)
FB4301 1-216-295-91 SHORT CHIP 0
FB4302 1-216-295-91 SHORT CHIP 0
FB4303 1-216-295-91 SHORT CHIP 0
<FILTER>
FL001 1-236-071-11 ENCAPSULATED COMPONENT
FL8301 1-236-071-11 ENCAPSULATED COMPONENT
FL8303 1-236-071-11 ENCAPSULATED COMPONENT
FL8304 1-236-071-11 ENCAPSULATED COMPONENT
FL8305 1-236-071-11 ENCAPSULATED COMPONENT
FL8311 1-236-071-11 ENCAPSULATED COMPONENT
FL8312 1-236-071-11 ENCAPSULATED COMPONENT
<IC>
IC001 8-752-932-01 IC CXP750096-046Q
IC002 8-759-663-29 MM1476AF(TP)
IC003 8-759-641-86 BR24C16F-E2 (KV-DR29M39/M69/M89)
IC003 8-759-699-33 M24C16-MN6T(A) (KV-DR29M63)
IC100 8-759-042-02 S-80743AL-A7-S
IC1200 8-759-100-96 UPC4558G2
IC1203 8-759-100-96 UPC4558G2
IC1204 8-759-690-61 AN7583Z
IC1205 8-759-711-10 NJU4066BM
IC1207 6-702-145-01 IC NJW1139GK1-TE2
IC2200 8-759-745-64 NJM4560M
IC2600 8-759-095-63 PQ09RF2
IC2601 8-759-065-07 PQ05RF2
IC2603 8-759-460-72 BA033FP-E2
IC3001 8-752-093-84 CXA2151Q
IC3002 8-759-677-02 BU4053BCF-E2
IC3003 8-759-548-56 M52055FP
IC4301 8-752-100-25 CXA2150AQ
IC4302 8-759-708-05 NJM78L05A
IC4304 8-759-135-80 UPC358C
IC8302 8-752-080-04 CXA2069Q
IC8306 8-752-099-05 IC CXA2163AQ-T6
IC8309 8-759-337-26 MM1115XFBE
IC8310 8-759-542-15 TDA9178
IC8312 8-759-485-79 TC7SET08FU(TE85L
<JACK>
J8301 1-784-646-11 TERMINAL, S
J8302 1-778-387-11 JACK BLOCK, PIN 12P
<CHIP CONDUCTOR>
JR001 1-216-295-91 SHORT CHIP 0
JR102 1-216-295-91 SHORT CHIP 0
JR107 1-216-295-91 SHORT CHIP 0
JR109 1-216-295-91 SHORT CHIP 0 (KV-DR29M89)
JR1214 1-216-295-91 SHORT CHIP 0
JR1219 1-216-295-91 SHORT CHIP 0
JR1301 1-216-295-91 SHORT CHIP 0 (KV-DR29M39/M69/M89)
JR1303 1-216-295-91 SHORT CHIP 0 (KV-DR29M39/M69/M89)
JR4301 1-216-295-91 SHORT CHIP 0
JR8301 1-216-295-91 SHORT CHIP 0
JR8302 1-216-295-91 SHORT CHIP 0
<COIL>
L001 1-414-856-11 INDUCTOR 10UH
L002 1-414-856-11 INDUCTOR 10UH
L003 1-414-751-11 INDUCTOR 1UH
L005 1-414-856-11 INDUCTOR 10UH
L006 1-414-856-11 INDUCTOR 10UH
L101 1-414-856-11 INDUCTOR 10UH
L102 1-414-856-11 INDUCTOR 10UH
L103 1-414-856-11 INDUCTOR 10UH
L104 1-414-856-11 INDUCTOR 10UH
L105 1-414-856-11 INDUCTOR 10UH
L1200 1-414-856-11 INDUCTOR 10UH
L1201 1-414-856-11 INDUCTOR 10UH
L1300 1-414-856-11 INDUCTOR 10UH
(KV-DR29M39/M69/M89)
L3001 1-469-555-21 INDUCTOR 10UH
L3002 1-412-029-11 INDUCTOR 10UH
L3003 1-412-029-11 INDUCTOR 10UH
L3302 1-414-856-11 INDUCTOR 10UH
(KV-DR29M39/M69/M89)
L3303 1-414-856-11 INDUCTOR 10UH
(KV-DR29M39/M69/M89)
L3304 1-414-856-11 INDUCTOR 10UH
(KV-DR29M39/M69/M89)
L3305 1-414-856-11 INDUCTOR 10UH
(KV-DR29M39/M69/M89)
L3306 1-414-856-11 INDUCTOR 10UH
(KV-DR29M39/M69/M89)
L4301 1-412-029-11 INDUCTOR 10UH
A
